Windows XP Embedded SP2 / Installation Manual Ausgabe 05/2011 Edition
1 Overview
This installation manual provides instructions on installing the Windows XP Embedded SP2
operating system for the machine computer and (optionally) for the Vision computer with station
software as of the 605.03 SP1 version for D-series placement machines in one-computer operation
or as of the 704 version.
It contains information on the scope of delivery and requirements for successful installation.
NOTICE
The Windows XP Embedded operating system is only used for new installations. On
upgrading to a higher station software version, there will be no operating system change
from Windows XP Professional to Windows XP Embedded.
5
Windows XP Embedded SP2 / Installation Manual Ausgabe 05/2011 Edition
2 Scope of delivery
A media standard package is available for installing the Windows XP Embedded SP2 operating
system. It contains different CDs/DVDs for the machine types.
CAUTION
It is imperative that the installation CD/DVD from the standard package for the relevant
computer type is used to install the operating system on a machine/Vision computer.
Operation system media package 70x eXP V1.0, item no. 00388544-01
– Software BOOT DVD CPU 627 V1.0
– Software BOOT DVD CPU 627B/827B V1
– Software CD "SIPLACE XP embedded Configurator"
– Ghost OEM Corporate License
– Installation Manual "Operation System Windows XP Embedded SP2",
(item no. 00196737-04)
– Packaging
Software WIN eXP Runtime, item no. 03053899-01
– eXP Sticker
– MS-WIN eXP Runtime Sticker
– MS-WIN eXP Runtime License
– Montagehinweis Embedded System License 01
– MS-WIN eXP Runtime EULA
Overview Machines – Computer types
X2 X3 X4 X4I SX1/SX2 SX4 D-series
DSIMATIC BoxPC 627,
two-computer operation
X X X X
SIMATIC BoxPC 627B,
two-computer operation
X X X X
SIMATIC BoxPC 627B,
one-computer operation
X X
SIMATIC BoxPC 827B,
one-computer operation
X X X X X
The Windows XP Embedded operation system is supported in the following combinations:
– BoxPC 627: X-series placement machines
– BoxPC 627B: SX1/SX2 and D-series placement machines
– BoxPC 827B: SX4 placement machines
6
