Windows XP Embedded SP2 / Installation Manual Ausgabe 05/2011 Edition
2 Scope of delivery
A media standard package is available for installing the Windows XP Embedded SP2 operating
system. It contains different CDs/DVDs for the machine types.
CAUTION
It is imperative that the installation CD/DVD from the standard package for the relevant
computer type is used to install the operating system on a machine/Vision computer.
Operation system media package 70x eXP V1.0, item no. 00388544-01
– Software BOOT DVD CPU 627 V1.0
– Software BOOT DVD CPU 627B/827B V1
– Software CD "SIPLACE XP embedded Configurator"
– Ghost OEM Corporate License
– Installation Manual "Operation System Windows XP Embedded SP2",
(item no. 00196737-04)
– Packaging
Software WIN eXP Runtime, item no. 03053899-01
– eXP Sticker
– MS-WIN eXP Runtime Sticker
– MS-WIN eXP Runtime License
– Montagehinweis Embedded System License 01
– MS-WIN eXP Runtime EULA
Overview Machines – Computer types
X2 X3 X4 X4I SX1/SX2 SX4 D-series
DSIMATIC BoxPC 627,
two-computer operation
X X X X
SIMATIC BoxPC 627B,
two-computer operation
X X X X
SIMATIC BoxPC 627B,
one-computer operation
X X
SIMATIC BoxPC 827B,
one-computer operation
X X X X X
The Windows XP Embedded operation system is supported in the following combinations:
– BoxPC 627: X-series placement machines
– BoxPC 627B: SX1/SX2 and D-series placement machines
– BoxPC 827B: SX4 placement machines
6
Windows XP Embedded SP2 / Installation Manual Ausgabe 05/2011 Edition
3 Prerequisites for installation
3.1 Software components
Standard package Software SIPLACE Station as of version 605.03 SP1:
SR 605.03 SP1, item no. 00140001-06 or
Standard package Software SIPLACE Station as of version 704.01:
SR 704.01, item no. 00388544-01
3.2 Hardware components of the computer system for the
machine/Vision computer
3.2.1 SIPLACE X- and SX-series hardware components
3.2.1.1 Machine/Vision computer (in two-computer operation)
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M 760 / 2 GHz
RAM 1 GB
Hard disk Yes
External DVD drive Yes (1 per machine)
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 3-1: Machine/Vision computer hardware SIPLACE X-series
Name SIMATIC Box PC 627B
CPU / clock frequency Core 2 Duo T7400 / 2,16 GHz
RAM 1 GB
Harddisk Yes
External DVD drive Yes (1 per machine)
Internal DVD drive No
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 3-2: Machine/Vision computer hardware SIPLACE X-series
7
Windows XP Embedded SP2 / Installation Manual Ausgabe 05/2011 Edition
3.2.1.2 Machine/Vision computer (in one-computer operation)
Name SIMATIC Box PC 627B
CPU / clock frequency Core 2 Duo T7400 / 2,16 GHz
RAM 1 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 1
USB interfaces and
external USB hub
Yes
Network 2x 100 MBit
Table 3-3: Machine/Vision computer hardware SIPLACE SX1/2
Name SIMATIC Box PC 827B
CPU / clock frequency Core 2 Duo T7400 / 2,16 GHz
RAM 2 GB
Harddisk Yes
External DVD drive No
Internal DVD drive Yes
Serial interfaces 1
USB interfaces Yes
External USB hub Yes (X-series) / No (SX4)
Network 2x 100 MBit
Table 3-4: Machine/Vision computer hardware SIPLACE X-series and SX4
