Scope of Delivery
Languages
32 SIPLACE Setup Center 7.1
System Requirements
Computers
SIPLACE Setup Center 7.1 33
4
4 System Requirements
System Requirements
4.1
4.1 Computers
Computers
4.2
4.2 Resource Requirements
Resource Requirements
4.3
4.3 Supported Software
Supported Software
Programming system
SIPLACE Setup Center supports the following version in online and offline mode:
NOTICE
NTFS partitioning
SIPLACE Setup Center requires a NTFS partitioning for installation. FAT or FAT32 file systems
are not supported.
Installation of SIPLACE Setup Center onto a FAT partitioning will be interrupted by the setup
program.
NOTICE
Licence Manager 3.0
SIPLACE Setup Center 7.1 requires license manager 3.0 for operation.
Depending on the selected function, one or more licenses are required for operating Setup
Center.
NOTICE
System requirements
The system requirements (supported operating system and database variants) and an over-
view of mutually compatible products can be found in the Assembly Instructions SIPLACE Sup-
port Media 2.1, item no [00117951-xx].
NOTICE
The size of the database server depends on the amount of the packaging unit data.
► Large data amounts require a higher server performance.
Hard Disk Main Memory
▪ Windows approx. 2500 MB
▪ Program files approx. 90 MB
▪ Database = number of recorded batches x 1
KB
▪ Windows approx. 200 MB
▪ SQL Server with Setup Center database ap-
prox. 150 MB
▪ Setup Center GUI approx. 100 MB
SIPLACE Pro Interface version SIPLACE Pro Desk version
5.0 SP1, 5.2, 6.0, 7.0,8.0, 9.2, 9.3 ,10.0, 10.1, 11.x,
12.0 and 12.1
5.0 SP1, 5.2, 6.0, 7.0, 8.0, 9.2 , 9.3, 10.0, 10.1,
11.x, 12.0 and 12.1
System Requirements
Supported Hardware
34 SIPLACE Setup Center 7.1
Station software
SIPLACE Setup Center supports the following station software versions:
Pre-setup unit for X and SX tables
The pre-setup unit for X and SX tables (docking station) requires the following:
4.4
4.4 Supported Hardware
Supported Hardware
Supported barcode readers
▪ Datalogic DRAGON
TM
M101 (1D barcode scanner)
▪ Datalogic DRAGON
TM
M131 (1D barcode scanner)
▪ Datalogic PowerScan® M8300 (1D barcode scanner)
▪ Datalogic PowerScan® M8500 (2D barcode scanner)
▪ Datalogic PowerScan® BT8300 (1D barcode scanner)
▪ Datalogic PowerScan® M9500 (1D/2D barcode scanner)
▪ Symbol MC70 Pocket PC (2D barcode scanner)
▪ Motorola MC70 Pocket PC (2D barcode scanner)
▪ Motorola MC75 Pocket PC (2D barcode scanner)
▪ Motorola MC3090 Pocket PC (1D barcode scanner or 2D barcode scanner)
▪ Motorola MC3190 Pocket PC (1D barcode scanner or 2D barcode scanner)
Forced setup verification Unforced setup verification
407.05 Hotfix 9
505.05 SP2 Hotfix 3
605.03 SP5
10x.x,
401.x, 402.x, 403.x, 406.x
407.05 Hotfix 9 (recommended)
408.x
501.x, 502.x, 503.x, 504.x
505.05 SP2 HF3 (recommended)
60x.x
703.xx or higher 70x.x
CAN bus connection X docking station SX docking station
CAN bus PCI card
▪ Sontheim PCI CAN driver
7.4.14.0 or higher version (on
the product CD)
or
CIN box
▪ Sontheim CIN driver 2.8.4.48
or higher version (on the
product CD)
▪ Hardware 0.05
–BIOS firmware 02.00 or
higher
– Application firmware
04.4A or higher
(The firmware files are on the sta-
tion software CD 707.0 or high-
er).
▪ Hardware 0.06 or 0.08
– BIOS firmware 00.0C or
higher
– Application firmware
01.C6 or higher
or
▪ Hardware 0.0A or 0.0C
– BIOS firmware 00.0D or
higher
– Application firmware
01.C6 or higher
(The firmware files are on the sta-
tion software CD 707.0 or high-
er).
