System Requirements
Supported Hardware
34 SIPLACE Setup Center 7.1
Station software
SIPLACE Setup Center supports the following station software versions:
Pre-setup unit for X and SX tables
The pre-setup unit for X and SX tables (docking station) requires the following:
4.4
4.4 Supported Hardware
Supported Hardware
Supported barcode readers
▪ Datalogic DRAGON
TM
M101 (1D barcode scanner)
▪ Datalogic DRAGON
TM
M131 (1D barcode scanner)
▪ Datalogic PowerScan® M8300 (1D barcode scanner)
▪ Datalogic PowerScan® M8500 (2D barcode scanner)
▪ Datalogic PowerScan® BT8300 (1D barcode scanner)
▪ Datalogic PowerScan® M9500 (1D/2D barcode scanner)
▪ Symbol MC70 Pocket PC (2D barcode scanner)
▪ Motorola MC70 Pocket PC (2D barcode scanner)
▪ Motorola MC75 Pocket PC (2D barcode scanner)
▪ Motorola MC3090 Pocket PC (1D barcode scanner or 2D barcode scanner)
▪ Motorola MC3190 Pocket PC (1D barcode scanner or 2D barcode scanner)
Forced setup verification Unforced setup verification
407.05 Hotfix 9
505.05 SP2 Hotfix 3
605.03 SP5
10x.x,
401.x, 402.x, 403.x, 406.x
407.05 Hotfix 9 (recommended)
408.x
501.x, 502.x, 503.x, 504.x
505.05 SP2 HF3 (recommended)
60x.x
703.xx or higher 70x.x
CAN bus connection X docking station SX docking station
CAN bus PCI card
▪ Sontheim PCI CAN driver
7.4.14.0 or higher version (on
the product CD)
or
CIN box
▪ Sontheim CIN driver 2.8.4.48
or higher version (on the
product CD)
▪ Hardware 0.05
–BIOS firmware 02.00 or
higher
– Application firmware
04.4A or higher
(The firmware files are on the sta-
tion software CD 707.0 or high-
er).
▪ Hardware 0.06 or 0.08
– BIOS firmware 00.0C or
higher
– Application firmware
01.C6 or higher
or
▪ Hardware 0.0A or 0.0C
– BIOS firmware 00.0D or
higher
– Application firmware
01.C6 or higher
(The firmware files are on the sta-
tion software CD 707.0 or high-
er).
System Requirements
Supported Hardware
SIPLACE Setup Center 7.1 35
Supported barcode types
▪ Datalogic 1D barcode scanner:
– Automatic recognition of all standard linear codes and linear GS1 DataBar ™ codes.
– Code 16K; Code 49; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar
Stacked Omnidirectional
▪ Datalogic 2D barcode scanner:
– Automatic recognition of all standard linear codes and linear GS1 DataBar ™ codes.
– Aztec Code; Aztec Mesas; Data Matrix; MaxiCode; QR Code; Post Codes; Australian Post; Brit-
ish Post; Canadian Post; China Post; Japanese Post; KIX Post; Korea Post; Planet Code; Post-
net; Royal Mail; Code (RM4SCC) ; EAN/JAN Composites; GS1 DataBar Composites; GS1
DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional;
MacroPDF; MicroPDF417; PDF417; UPC A/E Composites
▪ Symbol / Motorola 2D barcode scanner:
– AusPostal, Aztec, Chinese_2of5, Codabar, Code11, Code128, Code39, Code93, Composite
AB, Composite C, D2of5, Datamatrix, DutschPostal, EAN13, EAN8, I2of5, JapPostal,
Korean_3of5, MaixiCode, MicroPDF, MicroQR, MSI, PDF417, QRCode, RSS14, RSSExp,
RSSLim TLC39, Trioptic39, UKPostal, UPCA, UPCE0, UPCE1, US4State, US4State_FICS, US-
Planet, USPostnet, WebCode
Supported machines
Machine
SIPLACE 80 F4, F4-6, S20; F5, F5 HM, S23
SIPLACE S25 HM, S27 HM, HS50, HS 50+, HS60, HF,
HF3
SIPLACE X2, X3, X4; D1, D2, D3, D4
SIPLACE CF, CS
SIPLACE X2, X3, X4, X4I
SIPLACE SX1, SX2, SX4, SX1 V2, SX2 V2
SIPLACE DX1, DX2, DX4
SIPLACE X4i S, X4 S, X3 S, X2 S
SIPLACE X4i S micron, X4 S micron
SIPLACE CA
SIPLACE E
NOTICE
Restrictions
Please note that the programming system SIPLACE Pro and the Setup Center station package
may limit this selection.
System Requirements
Supported Hardware
36 SIPLACE Setup Center 7.1
Supported feeder types
Feeder types
▪ All WPC types
▪ MTC 1 & 2
▪ All waffle-pack trays
▪ All standard SIPLACE tape feeders
▪ All standard SIPLACE linear feeders
▪ SIPLACE X adapters
▪ Special feeders (Road Runner, Road Runner
XLF, Multi Stick Feeder: IPTE MSF 60 AX and
IPTE MSF XL80 AX; LED Feeder TE und LED
Feeder HS)
▪ SIPLACE JTF-S, JTF-M and JTF-MW
NOTICE
Restrictions
Please note that the programming system SIPLACE Pro and the hardware used may limit this
selection.
