1.1.4 Preparatory Work Prior to Putting the Line Computer Into Service
NOTE
To prevent the UNIX system and the LC software from being destroyed in the event of a power failure while
the computer is in operation, the power switch provided on the SIPLACE tower has been deactivated so that
the computer can only be switched on via the UPS. Therefore, all connections to the UPS (see Fig. 1.1.1)
must be completed prior to operating the computer.
PROCEDURE
● Prior to the initial operation of the devices, check that the setting of the mains voltage selector
switch located on the rear of the computer corresponds to the line voltage prevailing at the site
and, if required, adjust the switch to the correct line voltage.
● Plug power cable into UPS (see Fig. 1.1.1) and connect to mains.
● Switch on UPS at power switch (see Fig. 1.1.1) and allow unit to be charged for 24 hours, if requi-
red (see note, page 1 - 3).
● Switch off UPS.
● Connect keyboard and mouse to computer.
● Connect computer and UPS with power cable.
● Connect monitor and UPS with power cable.
● Connect monitor and computer by means of video cable.
● Switch on UPS using power switch.
● Switch on monitor using power switch.
CAUTION !
The computer should only be switched on if an LC software has already been installed or if the installation of
the LC software will be carried out immediately afterwards (see section 1.2.3) since a proper ’shutdown’ will
not be possible without the "root password".
1 Hardware / Software Installation User Manual Line Computer UNIX
1.1 Hardware Installation Software Version 501.xx 01/99 Issue
1 - 6
User Manual Line Computer UNIX 1 Hardware / Software Installation
Software Version 501.xx 01/99 Issue 1.2 Software Installation
1 - 7
1.2 Software Installation
1.2.1 General
NOTE
Prerequisite for the installation of the line computer software is that the SCO OpenServer 5.0.4 operating
system has been properly installed.
The installation of the operating system is performed at Siemens, PL EA V 1.
The installation of the LC software is performed using a CD-ROM. The number of entries to be made during
the installation procedure depends upon the fact whether an initial installation or the installation of a new version
of the LC software is being performed or whether the computer is equipped with a second LAN card (see Note,
page 1 - 12).
NOTE
When loading a new version of the LC software, the master data existing on the line computer are retained.
This shortens the installation procedure as entries concerning the stations can be dispensed with.
The following devices are required for the installation of the LC software:
- Boot disk for Pentium-based computer PCD5H item no. 00342137-01
(Pentium 90 - 133 MHz)
or
- Boot disk for Pentium-based computer M5 / M6 / M7 item no. 00342139-01
(Pentium >
166 MHz)
- Installation diskette item no. 00342141-01
- CD-ROM with LC Software Version 501.xx item no. 00342136-01
