PCB Barco de V2.0 S P4 / Ins tallation Manual Ausgabe 03/2013 E dition 5 1 Brief D escri pt ion This ins tallation m anual pro vides instr uctions on install ing the PC B Barcode V 2. 0 SP 4 on the SIPLAC E ® X- , SX - a…
PCB Barcode V2.0 SP4 / Installation Manual Ausgabe 03/2013 Edition
5
1 Brief Description
This installation manual provides instructions on installing the PCB Barcode V2.0 SP4 on the
SIPLACE
®
X-, SX- and DX-series placement machines. It contains information on the scope of
delivery and requirements for successful installation.
After installation, the PCB Barcode mode can be used at the station.
PCB Barcode V2.0 SP4 / Installation Manual Ausgabe 03/2013 Edition
6
1.1 Safety Instructions
DANGER
Nonobservance of these safety instructions may cause injury to personnel and
damage to the machine!
► Please observe the safety instructions in the user manual
of the relevant machine
for all work!
1.1.1 Conventions for the Use of Safety Instructions
This manual contains notes that must be observed to guarantee your personal safety and to avoid
damage to equipment. These notes are highlighted by warning triangles and are indicated as
follows according to the level of risk:
DANGER
Definition
For the purposes of this manual, this indicates that fatal or severe injuries or
considerable damage to property will occur if this hazard warning is not observed.
WARNUNG
Definition
For the purposes of this manual, this indicates that fatal or severe injuries or
considerable damage to equipment may occur if these warning instructions are not
followed.
CAUTION
Definition
For the purposes of this manual, this indicates that minor injuries or damage to property
may occur if this caution is not observed.
NOTICE
Definition
For the purposes of this manual, this note provides information about the product or
indicates a part of the manual that requires particular attention.
