Page HANWHA TECHWIN 277 DECAN L2 Axis Sensor Board (4/6) NO. P ART NO. P ART NAME Q'TY Old No. Supply Supply L T Reference 1 AM03-010810B CAB LE ASSY -FDR_UNLOCK_ SEN_J3R 1 2 AM03-010794A CABLE ASSY -AXIO_CAN_FDR_ U…
Page
HANWHA TECHWIN
276
DECAN
L2
Axis Sensor Board (4/6)
Page
HANWHA TECHWIN
277
DECAN
L2
Axis Sensor Board (4/6)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-010810B CABLE ASSY-FDR_UNLOCK_SEN_J3R 1
2 AM03-010794A CABLE ASSY-AXIO_CAN_FDR_UL_J3R-J8L 1
3 AM03-010811B CABLE ASSY-FDR_UNLOCK_SEN_J8L 1
4 J90831285A FDR_UNLOCK_LEFT_CABLE_ASSY SM33-CS034-1 1
5 J90831286C FDR_UNLOCK_RIGHT_CABLE_ASSY 1
Page
HANWHA TECHWIN
278
DECAN
L2
Axis Sensor Board (5/6)
