NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-012624A CABLE ASSY-BS12_BW12_CMD_AXIO 1
2 AM03-012616A CABLE ASSY-CONV_BELT1_MOT_PW_EXT 1
3 AM03-003578B CABLE ASSY-CONV_BELT1_MOTOR_PW 1
4 J90831439B CONV_BELT1_STEP_MOTOR_ASSY 1
5 AM03-012619A CABLE ASSY-CV_BELT2_MOT_PW_EXT 1
6 AM03-003904B CABLE ASSY-CONV_BELT2_MOTOR_PW 1
7 J90831440B CONV_BELT2_STEP_MOTOR_ASSY 1
8 AM03-012618A CABLE ASSY-WORK_BELT1_MOT_PW_EXT 1
9 AM03-003582B CABLE ASSY-WORK_BELT1_MOT_PW 1
10 J90831432B WORK_BELT1_STEP_MOTOR_ASSY 1
11 AM03-012621A CABLE ASSY-WORK_BELT2_MOT_PW_EXT 1
12 AM03-003908B CABLE ASSY-WORK_BELT2_MOT_PW 1
13 J90831441B WORK_BELT2_STEP_MOTOR_ASSY 1
