ASM: Stencils from the global No. 1
Design:
■ Process & design knowhow of
experts
■ Five Center of competence for
layout testing
■ Proven stencil design libraries
■ Global information exchange
of experts
Materials:
■ Standard stainless steel
■ Fine grain SS
■ Nickel blanks
■ Nickel E-form
■ Plastic material (PumpPrint)
Auxilary:
■ Coatings
■ RFID tags
■ Frames
■ Support toolings
Production technology:
■ Laser cutting
■ E-form technology
■ Welding or micro milling
steps
■ Various coating
technologies
The four elements
for a perfect stencil
ASM is the world’s largest manufacturer of stencils for industrial
printing applications as a result of the high quality and reliability of our
products and services. All of ASM’s factories and partners in the global
stencil network operate with the same materials, the same equipment,
and in accordance with strictly certified procedures. This enables us to
supply our customers quickly and with consistently high quality – no
matter where they may be located.
Consulting
The worldwide network of ASM oces, service centers and
partners guarantees close proximity, quick responses, and fast,
competent help on site.
Application support
Only ASM as the global SMT technology leader can oer printing
process expertise with this depth and quality. In our ve SMT
Centers of Competence (CoCs) spread around the world we
provide application support, check designs, oer improvement
workshops, and simulate and test specic printing processes
in a realistic environment. Our experts stand by you in person
or remotely, and always in close contact with your local ASM
partners.
Convenient ordering, fast delivery
You can place your orders the way your prefer – the classic
way via your local representative or electronically via the ASM
Web Shop that is open 24/7. Either way, we guarantee speedy
shipment – up to our Premium Rush Service with its 4-hour
delivery time.
DFM HealthCheck
With this pioneering process, state-of-the-art expert system
and big data technologies are used to run virtual prints in order
to analyze your stencil data, identify critical areas, and make
concrete proposals for optimized printing process settings. Based
on this information, you can print right away, eliminating the need
for time-wasting NPI test runs.
4
|
Process Support Products
|
ASM: Stencils from the global No. 1
ASM Stencil network
AMERICAS
■ Memphis (US)
■ Guadalajara (Mexico)
EUROPE
■ Györ (Hungary)
■ Bad Vilbel (Germany)
■ Oirschot (Netherlands)
■ Weymouth (England)
ASIA
■ Singapore
ASM direct support
Stencil partner network
ASM stencil operations
Real-life SMT lines in the SMT Centers of Competence are used
to provide application support and run tests including SPI analysis.
Tests in labs featuring modern equipment confirm
the high quality of ASM stencils.
5
DEK Fine Grain stencils
DEK Fine Grain stencils can be used with the DEK Mesh-
mounted frames, DEK VectorGuard
TM
Classic and DEK
VectorGuard
TM
High Tension frame systems. Fine grain stainless
steel stencils provide smoother laser-cut aperture walls for
improved paste release and better material transfer efficiency.
A cost-effective alternative to nickel, fine grain stainless steel is
ideal for challenging dimensions and high-density assemblies.
Achieving a finer grain of stainless steel, DEK Fine Grain stencils
provide superior paste release and a smoother stencil surface.
DEK Stencil solutions – stencil
technical specification
ASM LASER CUT STENCIL
Standard stainless
steel
Laser cut nickel Fine grain stainless
steel
Standard
E-form nickel
Platinum
E-form stencil
Material type 304 PHD
Nickel Fine grain SS Hard nickel Hard nickel
Material hardness (HV) ≥370 >470+ ≥370 500 +/-50 500 +/-50
Grain size (µm) 16-25 1 ≤ 2 1 0.6
Thickness available (µm) 80-250 100-175 80-250 75- 200 20-230
Thickness tolerance 4% 7% <2% 10% <5%
Area ratio window >0.66 >0.6 >0.55 >0.5 >0.5
Sheet width max 690 mm 584 mm 610 mm 610 mm 584 mm
Apertures size tolerance ±5 µm ±5 µm ±5 µm ±10 µm ±4 µm
6
|
