Station Software 709.0 / Installation Manual Ausgabe 11/2015 Edition
14
4 Requirements
4.1 Software Components of SIPLACE Series X, X S, SX, DX, CA and
TX
4.1.1 Station
The station only uses one of the following operating system configurations on the machine
computer and Coplan computer/feeder computer:
– Microsoft Windows Embedded Standard 7 (WES7, 32-bit or 64-bit)
The station computer has to be equipped with at least 2 GB memory with WES 7, 32-bit and 4 GB
memory with WES7, 64-bit respectively. If necessary, station computers in the field have to be
exchanged or upgraded with a memory extension. Please refer to the Technical Information
TI2014-09E04.
4.1.2 Machine Components
The following versions of other machine components are required for the station software to
function correctly:
SIPLACE station software SIPLACE Vision SIPLACE Pro
Version 709.0 Version 531 Version 13.0
CAUTION
The functional statuses of the station computer, Vision computer and SIPLACE Pro
Station Software 709.0 / Installation Manual Ausgabe 11/2015 Edition
15
4.1.3 Embedded Software
4.1.3.1 Composition of the File Name
1..6 7 8 9 10 11 12 13 14 15 16 17 18 19
Sub-
system
name
Sepa-
rator
Variant ID Hard-
ware ID
1)
Target
2)
Version Release . File type
See table
in section
4.1.3.2
_ 0 = no
variant
00
0 = BIOS 00
H
00
H
. HEX
_ A =
Variant
(SOKO)
…
1 = App 1 … … . JED
_ ... 99 2 = App 2 FF
H
FF
H
. BHX
Table 4-1: Composition of the file name
1)
Change compared with old file name (from one to 2 digits)
2)
Extended to second CAN
Station Software 709.0 / Installation Manual Ausgabe 11/2015 Edition
16
4.1.3.2 Comparison of Old and New Names of the Subsystems
Old subsystem name
(<70x)
New subsystem name
(70x)
Name
A AXIALL General axes (including free axis),
excluding DP axes of the C&P20A head
B COMTAB Component table
C VHSAXS Star axis of C&P20A head
E IOMODU CAN I/O module
F (Replaced by AXIALL) Free axis
G TAPCUT Tape cutter
H VHSHED C&P20A head
I TWIHED Twin Head
J VHSAXD DP axis of C&P20A head
L TWIAPR / VHSAPR Pressure regulation valve
(Twin Head / C&P20 head)
M MTCHNG MTC
N ---
O ---
P TWIAXZ Z-axis, Twin Head
Q ---
R TWIAXD DP axis, Twin Head
T CONVEY PCB conveyor
U FEEDER Feeder
V ILLUMI Vision
W VHSAXZ Z-axis, C&P20A head
X GANAXX X-axis
Y GANAXY Y-axis
--- CCPAPR
1)
Pressure regulation valve, CPP head
--- CPPAVA
1)
Valve cluster, CPP head
--- CPPAXD
1)
DP axis, CPP head
--- CPPHED
1)
CPP head
--- CPPSCO
1)
Component sensor
