PCB Barcode V2.0 SP2 / Installation Manual Ausgabe 03/2012 Edition

Contents

1 Brief Description 5

1.1 Safety Instructions ...............................................................................................5

1.1.1 Conventions for the Use of Safety Instructions....................................................5

2 Scope of Delivery 6

3 Prerequisites 7

4 Installing PCB Barcode 8

4.1 Installing PCB Barcode Hardware .......................................................................8

4.1.1 X-Series Placement Machines in One-Computer Operation ...............................8

4.1.2 X-series Placement Machines in Two-Computer Operation................................9

4.1.3 SX1/SX2- and DX1/DX2-Series Placement Machines ......................................10

4.1.4 SX4- and DX4-Series Placement Machines ......................................................10

4.2 Installing PCB Barcode Software.......................................................................11

4.3 Reading out Dongle ID ......................................................................................13

4.4 Troubleshooting .................................................................................................14

5 Testing PCB Barcode 17

PCB Barcode V2.0 SP2 / Installation Manual Ausgabe 03/2012 Edition

1 Brief Description

This installation manual provides instructions on installing the PCB Barcode V2.0 SP2 on the

SIPLACE

X-, SX- and DX-series placement machines. It contains information on the scope of

delivery and requirements for successful installation.

After installation, the PCB Barcode mode can be used at the station.

1.1 Safety Instructions

DANGER

Nonobservance of these safety instructions may cause injury to personnel and

damage to the machine!

► Please observe the safety instructions in the user manual of the relevant machine

for all work!

1.1.1 Conventions for the Use of Safety Instructions

This manual contains notes that must be observed to guarantee your personal safety and to avoid

damage to equipment. These notes are highlighted by warning triangles and are indicated as

follows according to the level of risk:

DANGER

Definition

For the purposes of this manual, this indicates that fatal or severe injuries or

considerable damage to property will occur if this hazard warning is not observed.

WARNUNG

Definition

For the purposes of this manual, this indicates that fatal or severe injuries or

considerable damage to equipment may occur if these warning instructions are not

followed.

CAUTION

Definition

For the purposes of this manual, this indicates that minor injuries or damage to property

may occur if this caution is not observed.

NOTICE

Definition

For the purposes of this manual, this note provides information about the product or

indicates a part of the manual that requires particular attention.
