GENERAL INSTRUCTIONS FOR USE

Requirements of the operating personnel

The appliance may only be operated and maintained by persons who are of legal age

and have been instructed accordingly. Personnel who are to be trained, instructed or

who are undergoing general training may only work with the appliance under the con-

tinuous supervision of an experienced person. Repairs may only be performed by qua-



Changes and alterations

No unauthorised changes or alterations may be made to the appliance. No parts

may be added or inserted which have not been approved by the manufacturer.

          -

ty losing its validity and the appliance must no longer be operated. The manufac-

turer is not liable for any damage, danger or injuries that result from unauthorised

changes or alterations, or from non-observance of the regulations in this manual.

Behaviour in case of malfunctions and irregularities



irregularities,malfunctions or damage, immediately take the appliance out of service

and inform your superior.

Switching off the appliance in an emergency

Push the On/Off switch on the control panel and

disconnect power plug. This disconnects the ap-

pliance from the power supply at all poles.

Applied directives and standards

ICO und HCP

X 

Directive of the council for harmonisation of the laws of the member states on elec-

tromagnetic compatibility. Standards complied with:

DIN EN 61326-1:2013-07 EN 61326-1:2013

X 

Directive of the council on harmonisation of the laws of member states relating to

electrical equipment designed for use within certain voltage limits. Standards com-

plied with:

DIN EN 61010-1:2011-07 EN 61010-1:2010

DIN EN 61010-2-010:2015-05 EN 61010-2-010:2014





ICOmed

X 



Intended use

HCPxx

ICOxx

ICOxxmed

Humidity chambers may be used exclusively for temperature and

climate testing of materials and substances in the context of the pro-



CO2 incubators ICO are intended for incubation of cell cultures or

similar.

CO2 incubators ICOmed are intended for incubation of cell cultures

or similar.



unify legal provisions of the member states concerning medical de-

vices)

The CO2 incubator ICOmed is used to generate and maintain cons-

tant ambient conditions for the in-vitro fertilisation (IVF) application

-

gotes in special culture dishes for IVF application as well as for gene

expression and the biosynthesis of RNA and proteins.

Improper use

Any other use is improper and may result in hazards and damage. The appliance is

not explosion-proof (does not comply with the German occupational health and safety

regulation VBG 24). The appliance may only be loaded with materials and substances

which cannot form any toxic or explosive vapours at the set temperature and which

cannot explode, burst or ignite. The appliance may not be used for the drying, evapora-

tion and burning-in of paints or similar materials, the solvents of which could form an

explosive mixture when combined with air. If there is any doubt as to the composition

of materials, they must not be loaded into the appliance. Potentially explosive gas-air

mixtures must not form, neither in the working chamber nor in the direct vicinity of

the appliance.

Additional for ICO & ICOmed

Only feed distilled water as well as CO2 and N2 into the chamber through the media

connections on the rear of the appliance. Introducing other liquids or gases is not per-

mitted. The incubator may not be used for sterilisation purposes. It is not a steriliser

according to the German Law on Medical Products. Sterilisation programmes that are

saved in the appliance only serve to sterilise the appliance itself. Do not use them to

sterilise medical devices.

GmbH+Co.KG D-91126 Schwabach FRG

Äußere

Rittersbacher Str. 38 Made in Germany

memmert

Schutzart DIN EN 60529 - IP 20

Typ: IN260

230 V~ 50/60 Hz

DIN12880-2007-Kl.: 1

F-Nr.: B618.3008

7,4 A 1700 W

Nenntemp.: 300 °C

CONSTRUCTION AND DESCRIPTION

memmert

Appliance overview

Designation (nameplate)

Connections and interfaces

1 ControlCOCKPIT

2 On/Off switch

3 Door handle

1 Type designation

2 Operating voltage

3 Applied standard

4 Protection type

5

4 Nameplate (Door frame inside)

5

6 USB interface (TwinDisplay)

6 Address of manufacturer

7 Disposal note

8 Temperature range

9 Connection / power ratings

10 Appliance number



Water connection (only HCP)

Optional interfaces

(e.g. option H5)

CO

Conncection (only ICOx)

N2 connection (Option T6)

Power connection

DELIVERY, TRANSPORT AND SETTING UP

CAUTION

≤ 260 L > 260 L

You could be injured due to the weight of the device if you try to lift

it alone. Observe the required number of people to carry equipment.

Larger equipment must not be carried, but only transported with a lift

truck or forklift.

≤ 75 L

Setting up

Due to its centre of gravity, the appliance can fall over to the front and

injure you or other people. Always attach the appliance to a wall with

the tilt protection.

WARNING

The distance between the wall and the rear of the appliance must be at least 15 cm.

The clearance from the ceiling must not be less than 20 cm and the side clearance



in the vicinity of the appliance must be guaranteed at all times.

Putting into operation



reached the steady state.

-

nection and power ratings (see nameplate and Technical data). Make sure to establish



Lay the power cable so that

X no one can trip over it;

X it does not come into contact with any hot parts;

X it is always accessible and within reach so it can be disconnected quickly in the

event of failure or emergencies.

≥ 15 cm

You may get your hands or feet squashed when transporting and in-

stalling the appliance. Wear protective gloves and safety boots. When

grasping the bottom of the appliance, grasp it only on the sides.

CAUTION

The appliance could fall over and seriously injure you. Never tilt the ap-

pliance and transport it in upright position and without load only (except

for standard accessories such as steel grids or shelves). Appliances

with castors always have to be moved by two people.

CAUTION

NOTICE

Condensation might cause a short circuit. After transport or storage

at high humidity conditions, the appliance shall be stored unpacked at

normal conditions for at least 24 hours. During this period of time the

appliance shall not be connected to the power supply.

WARNING
