Installation Manual, Station Software Version 605.03 10/2010 Edition 12 of 50 Machine type Subsystem Bios / application Version File name X2 X3 X4 D1 D2 D3 D4 CA3 CA4 BIOS 03.3F Q040033F.BHX X Application 1 01.27 Q041012…
Installation Manual, Station Software Version 605.03 10/2010 Edition
11 of 50
4.1.3 Embedded software
Machine type
Subsystem
Bios /
application Version File name
X2 X3 X4 D1 D2 D3 D4 CA3 CA4
BIOS 02.00 A0300200.bhx X X X
Application 1 02.13 A0310213.bhx X X X
Application 2 / X 02.4D A032024D.bhx X X X
Gantry axes
A363
Application 2 / Y 02.4D A032024D.bhx X X X
BIOS 03.3F A040033F.BHX X X X X X X X X X
Application 1 03.06 A0410306.bhx X X X X X X X X X
Application 2 / X 04.99 A0420499.bhx X X X X X X X X X
Gantry axes
A 364
Application 2 / Y 04.99 A0420499.bhx X X X X X X X X X
BIOS 02.00 A0300200.bhx X X X
Application 1 02.13 A0310213.bhx X X X
Application 2 / star 02.4D A032024D.bhx X X X
Application 2 / Z 02.4D A032024D.bhx X X X
C&P head
axes
A 363
Application 2 / DP 02.4D A032024D.bhx X X X
BIOS 03.3F A040033F.BHX X X X X X X X X X
Application 1 03.06 A0410306.bhx X X X X X X X X X
Application 2 / star 04.99 A0420499.bhx X X X X X X X X X
Application 2 / Z 04.99 A0420499.bhx X X X X X X X X X
C&P head
axes
A 364
Application 2 / DP 04.99 A0420499.bhx X X X X X X X X X
BIOS 02.00 A0300200.bhx X X X
Application 1 02.13 A0310213.bhx X X X
Application 2 / Z 02.4D A032024D.bhx X X X
TWIN Head
axes
A363
Application 2 / DP 02.4D A032024D.bhx X X X
BIOS 03.3F A040033F.BHX X X X X X X X
Application 1 03.06 A0410306.bhx X X X X X X X
Application 2 / Z 04.99 A0420499.bhx X X X X X X X
TWIN Head
axes
A 364
Application 2 / DP 04.99 A0420499.bhx X X X X X X X
BIOS 02.00 A0300200.bhx X X X
Application 1 02.13 A0310213.bhx X X X
Application 2 / star 02.4D A032024D.bhx X X X
Axes
C&P20 head
A 363
Applikation 2 / Z 02.4D A032024D.bhx X X X
BIOS 03.3F A040033F.BHX X X X X X
Application 1 03.06 A0410306.bhx X X X X X
Application 2 / star 04.99 A0420499.bhx X X X X X
Application 2 / Z 04.99 A0420499.bhx X X X X X
BIOS DP 01.04 J0400104.hex X X X X X
Axes
C&P20 head
A 364
Application 1 DP 03.07 J0410307.hex X X X X X
BIOS 03.3F O040033F.BHX X
Application 1 01.27 O0410127.bhx X
WPC 4
feed axis
Application 2 04.5E O042045E.bhx X
Installation Manual, Station Software Version 605.03 10/2010 Edition
12 of 50
Machine type
Subsystem
Bios /
application Version File name
X2 X3 X4 D1 D2 D3 D4 CA3 CA4
BIOS 03.3F Q040033F.BHX X
Application 1 01.27 Q0410127.bhx X
WPC 4
lifting axis
Application 2 04.5E Q042045E.bhx X
BIOS 03.D0 K06003D0.bhx X X X X X X
C&P head
(X-series, CA-
series)
Application 1 02.10 K0610210.bhx X X X X X
BIOS 03.D0 K07003D0.bhx
C&P head (D-
Serie)
Application 1 01.19 K0710119.bhx X X X
BIOS 03.D0 I01003D0.bhx X X X X X X
Twin Head
2nd processor
Application 1 02.07 I0110207.bhx X X X X X X
BIOS 03.D0 I03003D0.bhx X X X X X X
Twin Head
1st processor
Applikation 1 02.10 I0310210.bhx X X X X X X
BIOS 03.D0 H01003D0.bhx X X X X X
C&P20 head
Application 1 01.60 H0110160.bhx X X X X X
BIOS 02.01 B0000201.HEX X
Application 1 05.02 B0010502.hex X
BIOS 02.01 B0100201.HEX X
Component
table
CAN, 500 KB
Application 1 06.08 B0110608.hex X
BIOS 01.01 B0200101.hex X X X X X X X X
Component
table
CAN, 1 MB
Application 1 03.08 B0210308.hex X X X X X X X X
BIOS 02.00 B0500200.BHX X X X X X
Application 1 04.37 B0510437.bhx X X X X X
BIOS 00.09 B0600009.BHX X X X
Component
table
(X-table))
Application 1 01.29 B0610129.bhx X X X
BIOS 02.01 G0100201.HEX X
Tape cutter
CAN, 500 KB
Application 1 03.02 G0110302.HEX X
BIOS 01.00 G0200100.HEX X X X X X X X X
Tape cutter
CAN 1 MB
Application 1 01.00 G0210100.HEX X X X X X X X X
BIOS 01.02 G0300102.bhx X X X X X
Tape cutter
X-series, CA-
series
Application 1 01.0B G031010B.bhx X X X X X
BIOS 03.09 T0400309.HEX X X
PCB conveyor
TSP201
Application 1 06.31 T0410631.HEX X X
BIOS 03.09 T0500309.HEX X
PCB conveyor
TSP301
Application 1 06.31 T0510631.HEX X
BIOS 03.09 T0600309.HEX X X X X X X
PCB conveyor
X-series/CA-
series/D3
Application 1 06.31 T0610631.HEX X X X X X X
Installation Manual, Station Software Version 605.03 10/2010 Edition
13 of 50
Machine type
Subsystem
Bios /
application Version File name
X2 X3 X4 D1 D2 D3 D4 CA3 CA4
BIOS 03.41 E0100341.bhx X X X X X X
Application 1 03.C7 E01103C7.bhx X X X X X X
BIOS 03.24 E0200324.bhx X X X
Main /
subdistributor
Application 1 04.06 E0210406.bhx X X X
BIOS 03.D0 V05003D0.bhx X X X X X X X X X
VISION
modules
Application 1 03.03 V0510303.bhx X X X X X X X X X
BIOS 02.00 M0200200.BHX X X X X X X
MTC 2
Application 1 03.02 M0210302.BHX X X X X X X
BIOS 01.00 M0400100.bhx X X X X
WPC 4
Application 1 01.05 M0410105.BHX X X X X
BIOS 02.04 L0300204.hex X X X X X
Digital
pressure regu-
lation valve
Application 1 03.07 L0310307.hex X X X X X
BIOS 01.02 UA100102.HEX X X X X X
X-feeder
8 – 88 mm
Application 1 01.63 UA110163.HEX X X X X X
BIOS 01.01 UB200101.HEX X X X X X
X-feeder
adapter
Application 1 01.16 UB210116.HEX X X X X X
BIOS 01.00 UC300100.HEX X X X X X
LDU_X
module
Application 1 01.03 UC310103.HEX X X X X X
BIOS 01.00 UD400100.HEX X X X
X-feeder
2x8 mm
Application 1 01.02 UD410102.HEX X X X
The hardware status of a subsystem is identified by the 3rd digit in the file name.
The example below shows the file name of the BIOS for the main axes of the X-Series:
File name Hardware status
A0
300200.bhx A 363
A0
400309.bhx A 364
