75
PISTON PUMPS
A Series
A
Series Variable Displacement Piston Pumps
Electro-Hydraulic Proportional Pressure & Flow Control Type
●A37
●A22
●A90
●A100
●A45
●A145
●A70
●A56●A16
0
8
16
24
32
1 2 3 4 5
1800r/min
1500r/min
0
120
100
80
60
40
20
1 2 3 4 5
1800r/min
1500r/min
0
10
20
30
40
45
1 2 3 4 5
1800r/min
1500r/min
0
150
125
100
75
50
25
1 2 3 4 5
1800r/min
1500r/min
0
20
40
60
80
1 2 3 4 5
1800r/min
1500r/min
0
150
175
125
100
75
50
25
1 2 3 4 5
1800r/min
1500r/min
0
160
180
120
80
40
1 2 3 4 5
1800r/min
1500r/min
0
80
90
60
40
20
1 2 3 4 5
1800r/min
1500r/min
0
40
80
120
160
200
240
280
1 2 3 4 5
1800r/min
1500r/min
Input Signal VDC Input Signal VDC
Output Flow L/min
Output Flow L/min
Input Signal VDC Input Signal VDC
Output Flow L/min
Output Flow L/min
Input Signal VDC
Input Signal VDC
Output Flow L/min
Output Flow L/min
Input Signal VDC
Input Signal VDC
Input Signal VDC
Output Flow L/min
Output Flow L/min
Output Flow L/min
■ Full Cut-off Pres. vs. Input Signal
21
20
16
12
8
21MPa
16MPa
8MPa
4
0
1 2
3
4 5
Input Signal V
Full Cut-off Pressure MPa
Specified Pressure
A＊＊
−
FR04E16M
A＊＊
−
FR04E21M
A＊＊
−
FR04E8M
■ Output Flow vs. Input Signal
Note: Pump characteristics at 1800 r/min is the same as those at
1500 r/min where frequency is compensated.
(Refer to page 74.)
Refer to page 35 to 42 for performance characteristics of pressure
compensator type excluding characteristics appeared on this catalogue.
As for A45, contact us for details.
76
A
Series Variable Displacement Piston Pumps
Electro-Hydraulic Proportional Pressure & Flow Control Type
Discharge Port
19 Dia.
M10 Thd. 17 Deep
8 Places
Suction Port
19 Dia.
★2
★2
Pressure Sensor Connector
Cable Departure
Cable Applicable :
Outside Dia. ...... 8 - 10 mm
Conductor Area ......Not Exceeding 1.5mm
2
Air Vent
3 Hex. Soc.
Filling Port
★1
(22 Hex. Head Plug Furnished)
Tilt Angle Sensor Connector
22.2
47.6
22.2
32.5 32.5
47.6
12
172
96
78
11
18
106
130
25
26.5
6.5
44.5241
162
145
151.5
R12
95 Dia.
Drain Port
Rc
3/8 Thd.
4.79
4.76
19.05
19.02
Dia.
21.24
21.08
82.55
82.50
Dia.
Flange Mtg. : A16-FR04E＊
A22-FR04E＊
● Foot Mounting Type
Mounting bracket is common to that of pressure compensator model.
Refer to page 44 for the dimensions of mounting bracket.
● Foot Mounting Type
Mounting bracket is common to that of pressure compensator model.
Refer to page 45 for the dimensions of mounting bracket.
Outboard Pump Position
M10 Thd. 19 Deep
4 Places
Discharge Port
32 Dia.
Hex. Hd. Screw
Plain Washer
End Cover
Seal Cover
Air Vent
3 Hex. Soc.
Suction Port
32 Dia.
Filling Port
★1
(22 Hex. Head Plug Furnished)
Pressure Sensor
Connector
Tilt Angle Sensor Connector
★2
★2
M10 Thd. 19 Deep
4 Places
12
178.5
252.5
30.2
58.7
9.530
274.5
146
14
25
174
178.5
30.2
86 86
151.5
R14
90
58.7
149
40
62
105
166
Drain Port
Rc
1/2 Thd.
7.97
7.94
X
120 Dia.
Cable Departure
★3
Cable Applicable :
Outside Dia. ...... 8 - 10 mm
Conductor Area ......Not Exceeding 1.5mm
2
31.75
31.70
Dia.
35.32
35.14
101.60
101.55
Dia.
Flange Mtg. : A37-FR04E＊
★1. Install the pump so that the “Filling Port” is at the top.
★2. Do not touch the screw because it is adjusted at the time of shipment.
★3. For cable connection with amplifiers, see page 81.
★1. Install the pump so that the “Filling Port” is at the top.
★2. Do not touch the screw because it is adjusted at the time of shipment.
★3. For cable connection with amplifiers, see page 81.
View Arrow X
DIMENSIONS IN
MILLIMETRES
DIMENSIONS IN
MILLIMETRES
77
PISTON PUMPS
A Series
A
Series Variable Displacement Piston Pumps
Electro-Hydraulic Proportional Pressure & Flow Control Type
Axial Port Type
Side Port Type
30.2
36 36
30.2
263.5
59
30
32
9.5
195
12
M10 Thd. 19 Deep
8 Places
Cable Departure
★3
Cable Applicable :
Outside Dia. ..... 8 - 10 mm
Conductor Area .....Not Exceeding 1.5mm
2
58.7
Tilt Angle Sensor Connector
58.7
105
Filling Port
★1
(
22 Hex. Head Plug Furnished)
Pressure Sensor Connector
Suction Port
32 Dia.
Discharge Port
32 Dia.
Drain Port
Rc
1/2 Thd.
Air Vent
3 Hex. Soc.
120Dia.
R14
146
151.5 149
174
25
14
90 166
6.38
6.35
X
★2
★2
22.23
22.20
Dia.
25.01
24.85
101.60
101.55
Dia.
Flange Mtg. : A45-FR04E＊
58.7
90 166
263.5 59
30.2
86 86
149151.5
178.5
Surface of Discharge Port
M10 Thd. 19 Deep
4 Places (Both Sides)
Suction Port 32 Dia.
Rear Side Discharge Port 32 Dia.
Surface of Suction Port
Flange Mtg. : A45-FR04E＊S
● For other dimensions, refer to “Axial Port Type”.
View Arrow X
● Foot Mounting Type
Mounting bracket is common to that of pressure compensator model.
Refer to page 46 for the dimensions of mounting bracket.
★1. Install the pump so that the “Filling Port” is at the top.
★2. Do not touch the screw because it is adjusted at the time of shipment.
★3. For cable connection with amplifiers, see page 81.
DIMENSIONS IN
MILLIMETRES
