13-1-4 13-1 台車（下部） CART (LOWER) ｲﾗｽﾄ番号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 53 1-835-702-11 ｶｾｯﾄ ID ｼﾞｬﾝﾊﾟ ｺﾈｸﾀ (1) CONNECTOR, CASSETTE ID JUMPER 1

100%1 / 190
13-1-3
13-1
台車（下部）
CART (LOWER)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
27 4-196-848-01
ｺﾈｸﾀ
ｶﾗｰ
(2)
COLLAR (2), CONNETOR
2
28 4-701-543-01
ｱｰｽ
ﾒｲﾊﾞﾝ
AMS-550
LABEL (AMS-550), GROUND
2
AMS-550
29 4-706-724-07
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X25SUS)
BOLT (M3X25SUS), HEXAGON SOCKET
1
M3X25 SUS
30 4-706-725-06
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X25SUS)
BOLT (M4X25SUS), HEXAGON SOCKET
2
M4X25 SUS
31 4-706-726-03
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X8SUS)
BOLT (M5X8SUS), HEXAGON SOCKET
6
M5X8 SUS
32 4-706-726-21
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X30)
BOLT (M5X30), HEXAGON SOCKET
1
M5X30
33 4-706-726-31
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X10)
BOLT (M5X10), HEXAGON SOCKET
2
M5X10
34 4-716-149-01
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M10X16SUS)
BOLT (M10X16SUS), HEXAGON SOCKET
2
M10X16 SUS
35 4-761-856-03
ﾒｲﾊﾞﾝ
ｼｰﾙ
(
ｺｳｶﾝ
ﾀﾞｲｼｬ
)
SEAL, LABEL (REPLACEMENT TRUCK)
1
36 4-761-960-01
ﾒｲﾊﾞﾝ
ﾎｺﾞ
ｼｰﾙ
(
ｺｳｶﾝ
ﾀﾞｲｼｬ
)
SEAL, LABEL PROTECTION
1
37 7-682-161-01
+P 4X8
SCREW +P 4X8
2
38 7-683-419-04
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X8)
BOLT (M4X8), HEXAGON SOCKET
4
M4X8
39 7-683-420-04
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X10)
BOLT (M4X10), HEXAGON SOCKET
8
M4X10
40 7-683-437-04
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X14)
BOLT (M5X14), HEXAGON SOCKET
2
M5X14
41 7-683-454-04
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M6X14)
BOLT (M6X14), HEXAGON SOCKET
12
M6X14
42 7-683-472-04
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M8X16)
BOLT (M8X16), HEXAGON SOCKET
8
M6X14
43 7-684-025-04
N 5, TYPE 2
N 5, TYPE 2
8
N 5, TYPE 2
44 7-684-026-04
N 6, TYPE 2
N 6, TYPE 2
6
N 6, TYPE 2
45 7-688-005-11
W5, MIDDLE
W5, MIDDLE
6
W5, MIDDLE
46 7-688-006-11
W6, MIDDLE
W6, MIDDLE
6
W6, MIDDLE
47 4-193-442-01
ﾀﾞｽﾄ
BOX
BOX, DUST
1
48 7-623-425-07
LW 6, TYPE B
LW 6, TYPE B
2
LW 6, TYPE B
49 4-000-229-01
ｹｰﾌﾞﾙ
ｸﾞﾗﾝﾄﾞ
(VG M20-1/K68)
GROUND (VG M20-1/K68), CABLE
1
VG M20-1/K68
50 4-113-108-01
ﾛｯｶｸ
ﾅｯﾄ
(SKMU M20-K GR)
NUT (SKMU M20-1/K68))
1
SKMU M20-K GR
51 4-263-176-01
U
ﾅｯﾄ
(M3X0.5 2
ｼｭ
)
NUT (M3X0.5 2 MAIN), U
1
M3X0.5 2 MAIN
52 4-706-724-08
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X30SUS)
BOLT (M3X30SUS), HEXAGON SOCKET
1
M3X30 SUS
13-1-4
13-1
台車（下部）
CART (LOWER)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
53 1-835-702-11
ｶｾｯﾄ
ID
ｼﾞｬﾝﾊﾟ
ｺﾈｸﾀ
(1)
CONNECTOR, CASSETTE ID JUMPER
1
13-2-1
