3- 3-1 3-3 Ａヘッド ユニット（ 2/ 2 ） HEAD UNIT, A (2/2) 12 39 26 1 21 10 36 50 38 14 24 61 36 41 37 51 40 5 6 37 46 22 20 18 34 15 44 47 19 31 8 31 64 52 36 31 8 53 36 65 66 68 70 69 67 23 74 2 6 72 73 36 33 33 74 37
3-2-6
3-2
Ａヘッド ユニット（1/2）
HEAD UNIT, A (1/2)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
113 7-683-404-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X8
BOLT,HEXAGON SOCKET 3X8
6
3X8
114 4-187-213-01
ﾃｲﾄｳ
ﾛｯｶｸ
ﾎﾞﾙﾄ
ﾂｲｶｺｳ
(M3X9)
BOLT (PROCESSING) (M3X9)
12
M3X9
115 4-706-724-06
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X20SUS)
BOLT (M3X20SUS),HEXAGON SOCKET
2
3X20
116 7-683-423-04
6
ｶｸｱﾅﾂｷ
ﾎﾞﾙﾄ
4X16
BOLT,HEXAGON SOCKET 4X16
2
4X16
117 7-683-452-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
6X10
BOLT,HEXAGON SOCKET 6X10
1
6X10
118 7-683-481-34
6
ｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
2.5X8
BOLT, HEXAGON SOCKET 2.5X8
1
2.5X8
- 7-688-000-13
ｽﾌﾟﾘﾝｸﾞ
ﾜﾂｼﾔ
- 5, TYPE2
WASHER, SPRING 5, TYPE2
3
ＳＷ
5, TYPE2
120 7-688-003-01
W 3, SMALL
W 3, SMALL
15
W 3, SMALL
- 7-688-003-11
W 3, MIDDLE
W 3, MIDDLE
8
W 3, MIDDLE
122 7-688-004-11
W 4, MIDDLE
W 4, MIDDLE
4
W 4, MIDDLE
123 7-688-005-01
W 5, SMALL
W 5, SMALL
5
W 5, SMALL
- 7-688-006-01
W 6, SMALL
W 6, SMALL
4
W 6, SMALL
125 7-689-000-35
6
ｶｸｱﾅﾂｷ
ﾄﾒﾈｼﾞ
2.5X2
ﾋﾗｻｷ
SET-SCT, HEX. 2.5X2 FLAT POINT
48
2.5X2
- 7-689-000-36
6
ｶｸｱﾅﾂｷ
ﾄﾒﾈｼﾞ
2.5X2.5
ﾋﾗｻｷ
SET-SCT,HEX.2.5X2.5 FLAT POINT
24
2.5X2.5
127 2-594-336-01
ｴﾚﾒﾝﾄ
(EJXI610AS)
ELEMENT (EJXI610AS)
12
EJXI610AS,SMC
EA-4271
128 4-263-866-01
(S)
ｶﾞｽｹﾂﾄ
(MK5)
GASKET (MK5), (S)
12
129 2-176-600-01
ﾛｯｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X22 SUS)
BOLT (M3X22 SUS), SOCKET
2
130 4-187-212-01
C
ｶﾞﾀ
ﾒｶ
ﾊﾞﾙﾌﾞ
(FP10417-0A)
VALVE (FP10417-0A)
12
FP10474-0A, for Standard
130 4-273-156-01
C
ｶﾞﾀ
ﾒｶ
ﾊﾞﾙﾌﾞ
(
ﾊﾝｼｬﾎﾞｳｼ
)
VALVE (REFLECTION PREVENTION)
12
FP10474-1A, for Fixed Camera
3-3-1
3-3
Ａヘッド ユニット（2/2）
HEAD UNIT, A (2/2)
12
39
26
1
21
10
36
50
38
14
24
61
36
41
37
51
40
5
6
37
46
22
20
18
34
15
44
47
19
31
8
31
64
52
36
31
8
53
36
65
66
68
70
69
67
23
74
2
6
72
73
36
33
33
74
37
3-3-2
3-3
Ａヘッド ユニット（2/2）
HEAD UNIT, A (2/2)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 1-489-133-12
アクチュエータ
（
FP10416-1A
）
ACTUATOR (FP10416-1A)
1
FP10416-1A
2 A-1775-171-A
G2A5
ｲﾄﾞｳ
ｷｮｳﾄｳ
ASSY
TUBE, MIRROR ASSY, G2A5 MOVE
1 QQJ-2193
3
4
5 X-2024-431-1
ﾚ
-
ﾙ
ﾎﾙﾀﾞ
ASSY
HOLDER ASSY, RAIL
1
6 A-1775-170-A
ｷﾊﾞﾝ
ｶﾒﾗ
ASSY
CAMERA ASSY, PC BOARD
1
8 1-479-869-21
(S)
ﾌｵﾄ
ｾﾝｻ
Ass’y (PM-L24)
SENSOR ASSY, (S)(PM-L24)
2
PM-L24, SUNX
for H axis CW, CCW
9 1-479-920-11
(S)
ｱﾝﾌﾟ
Ass’y (E3X-DA11-S-4)
AMPLIFIER (E3X-DA11-S-4)
1
E3X-DA11-S-4, OMRON
for BS-NZL(PDLS-2)
10 1-478-890-12
ﾌｱｲﾊﾞ
(E32-D24R-2)
FIBER (E32-D24R-2)
1
E32-D24R-2, OMRON
12 1-787-836-11
ｻ
-
ﾎﾞ
ﾓ
-
ﾀ
(SGMJV-01ADA21)
MOTOR, SERVO (SGMJV-01ADA21)
1
SGMJV-01ADA21
14 1-809-416-11
ﾌｵﾄ
ﾏｲｸﾛ
ｾﾝｻ
(EE-SY672)
SENSOR, PHOTO MICRO (EE-SY672)
1
EE-SY672, OMRON
15 2-109-430-01
H
ｼﾞｸ
ｾﾝｻ
ﾄﾞｸﾞ
DOG, H SHAFT SENSOR
1
16 4-187-211-01
ｲﾄﾞｳ
ｶﾒﾗ
ｼﾑ
(A)
SHIM (A), MOVE CAMERA
2
Choice
16 4-187-211-11
ｲﾄﾞｳ
ｶﾒﾗ
ｼﾑ
(B)
SHIM (B), MOVE CAMERA
1
Choice
16 4-187-211-21
ｲﾄﾞｳ
ｶﾒﾗ
ｼﾑ
(C)
SHIM (C), MOVE CAMERA
1
Choice
18 2-148-082-01
ﾐﾆﾁﾕｱ
ｶﾑ
ﾌｵﾛｱ
(CFS2.5)
FOLLOWER, MINIATURE CAM (CFS2*
1
CFS2.5
19 2-149-675-01
ﾗﾂｸ
(M0.5X26L)
RACK (M0.5X26L)
1
M0.5X26L
20 2-149-699-01
LM
ｶﾞｲﾄﾞ
(SRS9MUU+55LM)
GUIDE, LM (SRS9MUU+55LM)
1
SRS9MUU+55LM
21 4-187-218-02
ﾌｧｲﾊﾞｰ
ｺﾃｲ
ﾌﾞﾛﾂｸ
BLOCK, FIBER FIXED
1
22 2-178-939-01
H
ｼﾞｸ
ﾚﾊﾞ
-
ﾍﾞ
-
ｽ
BASE, H SHAFT LEVER
1
23 4-187-206-01
H
ｼﾞｸ
ﾍﾞ
-
ｽ
ﾌﾟﾚ
-
ﾄ
PLATE, H SHAFT BASE
1
24 2-320-775-02
ｾﾝｻ
ﾌﾞﾗｹﾂﾄ
(4)
BRACKET (4), SENSOR
1
25 2-693-798-01
ｱﾝﾌﾟ
ﾄﾘﾂｹ
ﾌﾞﾗｹﾂﾄ
BRACKET, AMPLIFIER FITTING
1
26 4-187-217-01
ｱｸﾁｭｴｰﾀ
ﾌﾟﾚｰﾄ
PLATE, ACTUATOR
1
31 3-681-308-02
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
M2X6
BOLT (M2X6), HOLE, HEXAGON
6
M2X6
32 4-706-151-11
ﾊｲｾﾝﾄﾞﾒ
(KR5G5)
CLAMP (KR5G5)
2
KR5G5
