7-1-1
7-1
架台 ユニット（1/2）
STAND UNIT (1/2)
7-1-2
7-1
架台 ユニット（1/2）
STAND UNIT (1/2)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 2-149-053-01
ｴｱ
-
ｺﾝﾋﾞﾈ
-
ｼﾖﾝ
(AC30D-02DG-R)
COMBINATION, AIR (AC30D-02DG-
1
AC30D-02DG-R, SMC
2 4-701-316-01
ｽﾄﾘ
-
ﾄ
ｴﾙﾎﾞ
ELBOW, STREET
1
3 4-703-607-02
ﾊｲ
ｶﾌﾟﾗ
- (20PM)
COUPLER, HIGH (20PM)
1
20PM, NITTO KOHKI
4 4-703-619-01
ﾊｲ
ｶﾌﾟﾗ
- (20SH)
COUPLER, HIGH (20SH)
1
20SH, NITTO KOHKI
5 4-706-740-06
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M6X16SUS)
BOLT (M6X16SUS),HEXAGON SOCKET
2
M6X16SUS
6 4-706-963-51
ﾂｷﾞﾃ
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQL12-02S)
UNION, JOINT ELBOW (KQL12-02S)
1
KQL12-02S, SMC
7 4-720-084-02
ｴｱ
ｾﾂﾄ
ﾌﾞﾗｹﾂﾄ
BRACKET, AIR SET
1
8 7-623-213-22
SW 6, TYPE 2
SW 6, TYPE 2
2
SW 6, TYPE 2
9 7-684-026-04
N 6, TYPE 2
N 6, TYPE 2
2
N 6, TYPE 2
10 7-688-006-01
W 6, SMALL
W 6, SMALL
2
W 6, SMALL
11 4-184-165-01
ﾍﾞ
-
ｽ
ｲﾀ
(B)
PLATE (B), BASE
1
13 4-184-166-01
ｿｸ
ﾊﾞﾝ
(E)
PLATE (E), SIDE
1
14 2-689-672-01
ｿｸ
ﾊﾞﾝ
(F)
PLATE (F), SIDE
1
15 2-689-673-01
ｿｸﾊﾞﾝ
(G)
PLATE (G), SIDE
1
16 4-184-167-01
ﾀﾅ
ｲﾀ
(C)
PLATE (C), RACK
1
17 2-689-689-01
ﾀﾅ
ｲﾀ
(D)
PLATE (D), RACK
2
18 2-689-690-01
ﾃﾝﾊﾞﾝ
(B)
PLATE (B), TOP
1
19 4-706-726-03
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X8SUS)
BOLT (M5X8SUS), HEXAGON SOCKET
39
M5X8SUS
20 7-688-005-11
W 5, MIDDLE
W 5, MIDDLE
39
W 5, MIDDLE
22 2-689-662-01
ﾃﾝﾊﾞﾝ
(A)
PLATE (A), TOP
1
23 2-689-664-02
ﾍﾞ
-
ｽ
ｲﾀ
(A)
PLATE (A), BASE
1
24 2-689-665-02
ｿｸ
ﾊﾞﾝ
(A)
PLATE (A), SIDE
1
25 4-184-163-01
ｿｸ
ﾊﾞﾝ
(B)
PLATE (B), SIDE
1
26 4-184-164-01
ｿｸ
ﾊﾞﾝ
(C)
PLATE (C), SIDE
1
27 2-689-668-01
ﾀﾅ
ｲﾀ
(A)
PLATE (A), RACK
3
28 4-706-726-03
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X8SUS)
BOLT (M5X8SUS), HEXAGON SOCKET
29
M5X8SUS
7-1-3
7-1
架台 ユニット（1/2）
STAND UNIT (1/2)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
29 7-688-005-11
W 5, MIDDLE
W 5, MIDDLE
29
W 5, MIDDLE
30 4-720-082-03
ｽﾀﾝﾄﾞ
ﾎﾞﾙﾄ
BOLT, STAND
4
31 4-720-083-03
ﾊﾟﾂﾄﾞ
PAD
4
32 7-626-323-31
ｽﾌﾟﾘﾝｸﾞ
ﾋﾟﾝ
4X14
SPRING PIN 4X14
12
4X14
33 7-684-000-26
6
ｶｸﾅﾂﾄ
M30, TYPE3
NUT, HEXAGON M30, TYPE3
4
M30, TYPE3
34 2-697-047-07
G200
ｶﾀﾞｲ
G200 STAND
1
35 4-701-347-01
ﾍｲｺｳ
ﾋﾟﾝ
(MST6-20)
PIN, PARALLEL (MST6-20)
9
MST6-20
36 4-720-203-01
ｼﾞｸﾞ
ﾖｳ
ｲﾁｷﾞﾒ
ﾋﾟﾝ
(JPDPA10-14)
PIN, TOOL POSITIONING
2
JPDPA10-14
37 1-200-136-11
ﾉｲｽﾞ
ﾌｲﾙﾀ
(HF3030C-SZC)
FILTER, NOISE (HF3030C-SZC)
1
HF3030C-SZC, Choice
37 1-234-517-11
ﾉｲｽﾞ
ﾌｲﾙﾀ
(ZRCT4030-ME)
FILTER, NOISE (ZRCT4030-ME)
1
ZRCT4030-ME, Choice
38 1-245-712-11
ｶｲｾｲ
ﾃｲｺｳ
(CAN750S L=300 20
ｵ
-
ﾑ
RES (CAN750S L=300 20 OHM J)
2
CAN750S L=300 20 OHM J
39 1-694-624-11
ﾀﾝｼﾀﾞｲ
(UK35-3J-SH2076)
TABLE,TERMINAL(UK35-3J-SH2076)
1
UK35-3J-SH2076
41 1-780-254-11
ﾀﾝｼﾀﾞｲ
(UK15-15J-SQ3064)
TERMINAL BOARD (UK15-15J-SQ3*)
1
UK15-15J-SQ3064
42 1-787-208-11
ﾄﾞﾗｲ
ﾎﾟﾝﾌﾟ
(KHB200-303-G1)
POMP ,DRY (KHB200-303-G1)
1
KHB200-303-G1, ORION
43 2-108-797-02
ﾎﾟﾝﾌﾟ
ｶﾞｲﾄﾞ
GUIDE, POMP
2
44 2-108-802-02
ﾎﾟﾝﾌﾟ
ｶﾍﾞ
ｶﾊﾞ
-
COVER, POMP PARTITION
1
45 2-659-164-01
ｱｲﾎﾞﾙﾄ
(M20)
EYEBOLT (M20)
4
M20
- 2-665-007-01
ｶﾊﾞ
-
ﾎﾙﾀﾞ
(2)
HOLDER (2), COVER
1
47 2-689-658-03
ｶﾊﾞ
-
ﾄﾘﾂｹ
ｽﾃ
- (
ﾐｷﾞ
)
STAY (RIGHT), COVER FITTING
2
48 2-689-659-03
ｶﾊﾞ
-
ﾄﾘﾂｹ
ｽﾃ
- (
ﾋﾀﾞﾘ
)
STAY (LEFT), COVER FITTING
2
49 2-689-660-02
ﾃｲｺｳ
ﾄﾘﾂｹ
ﾌﾞﾗｹﾂﾄ
BRACKET, RESISTOR FITTING
1
50 4-197-607-02
I/O
ﾎﾞ
-
ﾄﾞ
ﾌﾞﾗｹﾂﾄ
BRACKET, I/O BOARD
2
51 2-698-101-01
ﾃﾞﾝｿｳ
ﾄﾘﾂｹ
ﾌﾞﾂｼﾕ
BUSHING, ELECTRICAL FITTING
4
- 2-887-483-01
ｶﾊﾞ
-
ﾎﾙﾀﾞ
- (
ﾘｱ
)
HOLDER (REAR), COVER
1
53 4-705-238-11
ﾏﾆﾎ
-
ﾙﾄﾞ
(KM11-08-12-10)
MANIFOLD (KM11-08-12-10)
1
KM11-08-12-10, SMC
55 4-706-725-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X8)
BOLT (M4X8), HEXAGON SOCKET
24
M4X8
