2. Preparing for maintenance tasks
2.1.2 Replaceable parts (during breakdowns)
The term “Replaceable parts” in this manual indicates parts that might cause a machine stoppage as these parts
lose their functions but do not require machine adjustment after replacement work. Methods for replacing the
following parts during a machine breakdown are described.
Replaceable parts
During a breakdown
Ejector valve
Conveyor unit valve
Feeder valve
43102-E5-00
Feeder valve
Ejector valve
Conveyor unit valve
For feeder drive
For vacuum generation
Main stopper, etc.
KGA-M73P1-00X
KGL-M7163-00X
KGL-M9134-00X
VALVE
VALVE
VALVE
Product Name NoteParts No.Parts List Designation
Replaceable parts list
During a breakdown
45102-E5-00
1-5
1
Maintenance
2.2 Maintenance tools
2.2.1 Cleaning tools
Cleaning tools
Parts supplied with machine
Spline shaft cleaner kit
Lens cleaner
Nozzle cleaning wire
Feeder plate cleaning brush
Lens blow brush
Cotton swab sticks
43103-E5-00
Spline shaft cleaner kit
Nozzle cleaning wire
Lens cleaner
Lens blow brush
Cotton swab sticks
Feeder plate cleaning brush
KV8-M8860-00X
KV8-M8883-A0X
KGA-M3801-00X
KGA-M3803-00X
KGA-M3802-00X
KV7-M8880-00X
CLEANING KIT
NEEDLE ASSY
CLEANER, LENS
BLOWER
SWAB
BRUSH, FEEDER
Product Name NoteParts No.Parts List Designation
Cleaning tools
Parts supplied with machine
45103-E5-00
2. Preparing for maintenance tasks
1-6
1
Maintenance
Cleaning tools
Optional parts
Nozzle cleaning wire handle
Air blow gun
43104-E5-00
Nozzle cleaning wire handle
Air blow gun
KV8-M8881-A0X
KU4-M8590-00X
NEEDLE CLEANER ASSY
AIR GUN ASSY
Product Name Note
Parts No.Parts List Designation
Cleaning tools
Optional parts
45104-E5-00
2. Preparing for maintenance tasks
