1- 7 1 Maintenance 2.2.2 Oil filling tools and grease Oil filling and greasing tools Parts supplied machine Lithium-based grease (not for use on heads) Oil syringe applicator for nozzle holder 43105-E5-00 Lithium-based g…
1-6
1
Maintenance
Cleaning tools
Optional parts
Nozzle cleaning wire handle
Air blow gun
43104-E5-00
Nozzle cleaning wire handle
Air blow gun
KV8-M8881-A0X
KU4-M8590-00X
NEEDLE CLEANER ASSY
AIR GUN ASSY
Product Name Note
Parts No.Parts List Designation
Cleaning tools
Optional parts
45104-E5-00
2. Preparing for maintenance tasks
1-7
1
Maintenance
2.2.2 Oil filling tools and grease
Oil filling and greasing tools
Parts supplied machine
Lithium-based grease
(not for use on heads)
Oil syringe applicator for nozzle holder
43105-E5-00
Lithium-based grease
Oil syringe applicator for nozzle holder
LRL No.3 50g
Turbine oil VG32
K48-M3851-10X
KV8-M8870-00X
GREASE PACK
SYRYNGE OIL
Product Name Note
Parts No.Parts List Designation
Oil filling and greasing tools
Parts supplied machine
45105-E5-00
2. Preparing for maintenance tasks
1-8
1
Maintenance
Oil filling and greasing tools
Optional parts
Grease gun
43106-E5-00
Grease gun PH-100K48-M3852-00XGREASE GUN
Product Name NoteParts No.Parts List Designation
Oil filling and greasing tools
Optional parts
45106-E5-00
2. Preparing for maintenance tasks
