Before starting work
1. About safety
Please comply with all safety rules and precautions described in this manual in order to use, inspect and
service the machine in a safe and correct manner. Also, please bear in mind that not all safety items can
be listed in detail in this manual, so that accurate judgment by the person handling the machine is
essential to ensure safety.
■ Safety precautions for maintenance work
The following are basic safety precautions you must observe during maintenance work.
1. Wear appropriate clothing or a uniform that matches the inspection and service work.
2. Turn off the power before inspecting the machine or replacing any parts.
3. Keep the air supply shut off when inspecting pneumatic units or replacing parts of a pneumatic unit.
4. When operating the machine be sure to keep all parts of the body such as the hands or the head away from moving
parts.
5. Make sure the interlock safety devices are maintained in an operable condition so that they will stop the machine
whenever needed.
6. Do not omit any steps in the specified procedure and do not attempt any work not listed in the instructions.
7. Do not place tools on the machine.
■ Operating notes and alert symbols
This manual uses the following symbols to indicate operating notes and precautions.
n
NOTE
Explains key points in the operation procedure or useful information on machine operation in a simple and clear manner.
c
CAUTION
Gives important safety information to prevent damage to the machine or data. Failure to follow this instruction may cause
damage to the machine or data.
w
WARNING
Gives safety information of utmost importance to ensure the safety of the operator and service personnel. Failure to follow
this instruction may cause serious bodily injury or death.
e
Indicates the emergency stop button must first be pressed before continuing the procedure. Failure to follow this instruction
may cause serious bodily injury or death.
ii
Before starting work
1. About safety
■ The following warning labels are affixed to the machine. Be sure to read the
instructions on the labels and observe them.
Warning labels
CLOSE COVER WHILE OPERATING
WARNING
DON'T
TOUCH
HOT!
Touching may cause burns!
Moving parts in the motor may reach
high temperatures so do not touch!
HIGH VOLTAGE!
Touching may cause electrical
shocks!
Touching or handling the power supply
inside the cover may cause electrical
shocks so use caution!
PROHIBITED!
Do not touch camera unit!
Touching, shaking or vibrating the
camera unit will badly affect
component mounting.
WARNING!
WARNING!
Do not operate with cover
removed!
Operating the unit with the cover still
open may cause moving parts to
come in contact with the body and
cause injuries.
Do not disable or remove
cover switch!
Operating the unit with the cover
switch disabled may cause moving
parts to come in contact with the body
and cause injuries.
23001-E0-00
iii
Before starting work
2. Warranty
The machine you have purchased is warranted against malfunctions as described below.
■ Warranty Coverage
If any failure or defects are found in this machine due to poor workmanship within the warranty period (one year or 2400
hours of operation whichever comes first), we will repair or replace the defective parts free of charge.
■ Warranty Period
The warranty period ends when any of the following applies:
1.After one year has elapsed from the time of incoming inspection of the machine.
2.After 2400 hours of operation.
■ Items not covered by the warranty
The warranty does not cover any of the following conditions:
1.Defects or trouble as a result of deterioration due to age or wear
Example: Normal discoloration of painted or plated surfaces, wear of consumable parts, etc.
2.Incidents associated with sensory perceptions which have no bearing on the quality or function of the machine
Example: Signal sounds emitted by the controller, rotating sounds of the motor, etc.
3.Damage as a result of user environment
Example: Impurities in the air supply, dust, debris and oil mist in the machine
■ Exception to warranty repairs
Warranty repairs shall not apply if failure or defects are caused by the following:
1.Earthquakes, typhoons, floods, lightning, accidents or fires and other natural or man-made disasters.
2.Modifications not approved by us or its distributors.
3.Use of non-genuine parts, greases or lubricants.
4.Lack of proper maintenance and inspection procedures.
5.Maintenance handled by anyone other than the approved distributors.
6.Change of the machine installation level due to poor foundations or harsh environment.
7.Machine was moved to another location after installation or modified to change specifications.
8.Defective parts replaced free of charge were not returned to the specified destination within 30 days.
■ Note on network connections
A precondition for surface mounter network connections is that such connections will be used in closed networks
comprised of a surface mounter and an off-line PC. The customer must take responsibility for connections to company in-
house networks and to external networks. Please acknowledge that we can bear absolutely no responsibility for networks
configured by other than just a surface mounter and off-line PC nor can accept responsibility for problems occurring due
to network settings and connections.
