3.6.8 Saving a control data file
This command saves the basic control data, which is used to control the machine,
onto a floppy disk. The data to be saved here is very important to:
operate the EPU (External Program Editing Unit) according to the specifications of the
main unit, and
find out the conditions unique to the machine when a trouble occurs.
To save a control data file, use the Wizard as shown below. Follow the
instructions displayed on the screen.
3.6.8.1 Selecting a task
Normally, you can select the task “File backup” only.
To save the control data, click the <Next> button.
When you click the <Cancel> button, the system cancels the control data save
operation.
3.6.8.2 Selecting where to save the control data
Select the radio button “Floppy disk”.
)
Please select work.
Back Next Cancel
Please select the place of the backup.
Back Next Cancel
3 − 29
3.6.8.3 Starting the save operation
When you click the <Action> button, the system starts saving the control data on a
floppy disk.
3.6.8.4 Finishing the save operation
When the system finishes saving a control file, the following dialog box appears on
the screen. Click the <Finish> button, then eject the floppy disk and store it at a safe
place.
The backup is executed. Please push the action button when you can.
Back Finish Cancel
The backup is executed. Please push the action button when you can.
Back Finish Cancel
3 − 30
3.6.9 Exit
This command executes the shut-down process to quit the system.
See Page 3-13 (3-4 " Starting up or Terminating the System").
Figure 3.6.9 Shut-down confirmation dialog box
CAUTION
If you turn off the machine without performing the shut-down process,
you may not be able to restart the machine. Be sure to perform the
shut-down process to terminate the system.
