English 7
Installation
Installation site
10 cm 10 cm
behindbehind
20 cm 20 cm
aboveabove
10 cm on 10 cm on
the sidethe side
85 cm of the 85 cm of the
floorfloor
• Select a flat, level surface approx.
85 cm above the floor. The surface must
support the weight of the oven.
• Secure room for ventilation, at least
10 cm from the rear wall and both
sides, and 20 cm from above.
• Do not install the oven in hot or damp
surroundings, such as next to other
microwave ovens or radiators.
• Conform to the power supply
specifications of this oven. Use only
approved extension cables if you need
to use.
• Wipe the interior and the door seal with
a damp cloth before using your oven for
the first time.
Turntable
Remove all packing materials inside the
oven. Install the roller ring and turntable.
Check that the turntable rotates freely.
Installation
Accessories
Depending on the model that you have purchased, you are supplied with several
accessories that can be used in a variety of ways.
01
01 Roller ring, to be placed in the centre of
the oven.
The roller ring supports the turntable.
02
02 Turntable, to be placed on the roller
ring with the centre fitting to the
coupler.
The turntable serves as the main
cooking surface; it can be easily
removed for cleaning.
CAUTION
DO NOT operate the microwave oven without the roller ring and turntable.
8 English
Maintenance
Maintenance
Cleaning
Clean the oven regularly to prevent impurities from building up on or inside the
oven. Also pay special attention to the door, door sealing, and turntable and roller
ring (applicable models only).
If the door won’t open or close smoothly, first check if the door seals have built up
impurities. Use a soft cloth in soapy water to clean both the inner and outer sides
of the oven. Rinse and dry well.
To remove stubborn impurities with bad smells from inside the oven
1. With an empty oven, put a cup of diluted lemon juice on the centre of the
turntable.
2. Heat the oven for 10 minutes at max power.
3. When the cycle is complete, wait until the oven cools down. Then, open the
door and clean the cooking chamber.
To clean inside swing-heater models
To clean the upper area of the cooking
chamber, lower the top heating element by
45° as shown. This will help clean the upper
area. When done, reposition the top heating
element.
CAUTION
• Keep the door and door sealing clean and ensure the door opens and closes
smoothly. Otherwise, the oven’s lifecycle may be shortened.
• Take caution not to spill water into the oven vents.
• Do not use any abrasive or chemical substances for cleaning.
• After each use of the oven, use a mild detergent to clean the cooking chamber
after waiting for the oven to cool down.
Replacement (repair)
WARNING
This oven has no user-removable parts inside. Do not try to replace or repair the
oven yourself.
• If you encounter a problem with hinges, sealing, and/or the door, contact a
qualified technician or a local Samsung service centre for technical assistance.
• If you want to replace the light bulb, contact a local Samsung service centre. Do
not replace it yourself.
• If you encounter a problem with the outer housing of the oven, first unplug the
power cord from the power source, and then contact a local Samsung service
centre.
Care against an extended period of disuse
• If you don’t use the oven for an extended period of time, unplug the power
cord and move the oven to a dry, dust-free location. Dust and moisture that
builds up inside the oven may affect the performance of the oven.
English 9
Oven features
Oven features
Oven
01 02 04
09 100706
03
0805
01 Door handle 02 Door 03 Ventilation holes
04 Light 05 Door latches 06 Turntable
07 Coupler
08 Roller ring
09 Safety interlock holes
10 Control panel
Control panel
01
03
05
07
12
09
02
04
06
08
11
10
01 Auto Cook
02 Quick Defrost
03 Soften/Melt
04 Favorite
05 Microwave
06 Deodorization
07 Child Lock
08 Select/Clock
09 Down
10 Up
11 STOP/ECO
12 START/+30s
