SAMSUNG TECHWIN Page 100 56~ 88 mm SMN T ape Fe ed er -Su b NONIT PCB Ass'y A-24 IT Slave PCB Ass'y A-24 Feeding Switch Ass'y-NONIT A-23 Feeding Switch Ass'y-IT A-23 Solenoid Cable Ass'y A-25 Ree…
SAMSUNG TECHWIN
Page
99
56~88mm SMN Tape Feeder -Sub
Probe Cable Ass'y-NONIT
A-22
Probe Cable Ass'y-IT
A-22
Drain Link Ass'y
A-19
Indexing Sensor Ass'y-2488
A-20
Clamp Switch Cable Ass'y-2488
A-21
SAMSUNG TECHWIN
Page
100
56~88mm SMN Tape Feeder -Sub
NONIT PCB Ass'y
A-24
IT Slave PCB Ass'y
A-24
Feeding Switch Ass'y-NONIT
A-23
Feeding Switch Ass'y-IT
A-23
Solenoid Cable Ass'y
A-25
Reel Stopeer Ass'y
A-26
Page
101
SAMSUNG TECHWIN
56~88mm SMN Tape Feeder -Sub
Part List
56mm 72mm 88mm
A-1 ..2 J90651495A TAPE GUIDE ASSY-56 1 1 1 ○ ○
1 ...3 J70652616A TAPE GUIDE-56 1 0 0 ○ ○ J70652616A
2 ...3 J90651503A SHUTTER ASSY-56 1 0 0 ○ ○ J90651503A
3 ...3 J70652748A SHUTTER STOP NUT 1 0 0 ○ ○ J70652748A
4 ...3 J70652718A SHUTTER GUIDE WASHER 2 0 0 ○ ○ J70652718A
5 ...3 J1301448 FLAT HEAD CAP SCREW 2 0 0 ○ ○ M3*6 (SUS)
..2 J90651496A TAPE GUIDE ASSY-72 1 1 1 ○ ○
1 ...3 J70652617A TAPE GUIDE-72 0 1 0 ○ ○ J70652617A
2 ...3 J90651504A SHUTTER ASSY-72 0 1 0 ○ ○ J90651504A
3 ...3 J70652748A SHUTTER STOP NUT 0 1 0 ○ ○ J70652748A
4 ...3 J70652718A SHUTTER GUIDE WASHER 0 2 0 ○ ○ J70652718A
5 ...3 J1301448 FLAT HEAD CAP SCREW 0 2 0 ○ ○ M3*6 (SUS)
..2 J90651497A TAPE GUIDE ASSY-88 1 1 1 ○ ○
1 ...3 J70652618A TAPE GUIDE-88 0 0 1 ○ ○ J70652618A
2 ...3 J90651505A SHUTTER ASSY-88 0 0 1 ○ ○ J90651505A
3 ...3 J70652748A SHUTTER STOP NUT 0 0 1 ○ ○ J70652748A
4 ...3 J70652718A SHUTTER GUIDE WASHER 0 0 2 ○ ○ J70652718A
5 ...3 J1301448 FLAT HEAD CAP SCREW 0 0 2 ○ ○ M3*6 (SUS)
A-2 ..2 J90651499A DRAIN LEVER ASSY-3288 1 1 1 ○ ○
A-3 ..2 J90651507A PUSHER LEVER ASSY 1 1 1 ○ ○
A-4 ..2 J90651508A MAGNET LINK ASSY 1 1 1 ○ ○
1 ...3 J70652745A MAGNET LINK 1 1 1 ○ ○ J70652745A
2 ...3 J90651509A MAGNET ASSY 1 1 1 ○ ○ J90651509A
3 ...3 J6006164050 FLAT HEAD CAP SCREW 2 2 2 ○ ○ M1.6*4 (SUS)
A-5 ..2 J90651513A DRAIN GEAR ASSY-56 1 1 1 ○ ○
..2 J90651514A DRAIN GEAR ASSY-72 1 1 1 ○ ○
IT
Q'TY
Reference
NO.
LEVEL
PART NO.
PART NAME
TYPE
Non
-IT
