Page
5
SAMSUNG TECHWIN
8mm SMN Tape Feeder
Part List
0402 2P 4P 2P-L 4P-L
1 ..2 J70650948B LOCATION-FLANGE 1 1 1 1 1 ○ ○ SM1-MF08-006R1
2 ..2 J7065952A Y-ECCENTRIC-PIN 1 1 1 1 1 ○ ○ SM1-MF08-009
3 ..2 J7065953A STOP-PAWL 1 1 1 1 1 ○ ○ SM1-MF08-010
4 ..2 J72650152B DRAIN-GEAR 1 1 1 1 1 ○ ○ SM1-MF08-011R2
5 ..2 J70650954C DRAIN SHAFT-1 1 1 1 1 1 ○ ○ SM1-MF08-012R2
6 ..2 J70652570A DRAIN SHAFT-2 1 1 1 1 1 ○ ○ SM1-MF08-012-1
7 ..2 J7065959A LIMIT-SHAFT 1 1 1 1 1 ○ ○ SM1-MF08-017
8 ..2 J70650967C LOCKING-LIMIT 1 1 1 1 1 ○ ○ SM1-MF08-025R2
9 ..2 J70650969B SWING-LINK-SHAFT 1 1 1 1 1 ○ ○ SM1-MF08-027R1
10 ..2 J7065972A SPROCKET-SHAFT 1 1 1 1 1 ○ ○ SM1-MF08-031
11 ..2 J72650154B VINYL-ROLLER 2 2 2 2 2 ○ ○ SM1-MF08-036R1
12 ..2 J70650976B VINYL-ROLLER-SHAFT 2 2 2 2 2 ○ ○ SM1-MF08-037R1
13 ..2 J7065977A TAPE GUIDE SHAFT1 0 1 1 1 1 ○ ○ SM1-MF08-038R1
..2 J70661022A T-GUIDE SHAFT1 0402 1 0 0 0 0 ○ ○ SM1-MF08-038-1
14 ..2 J70650978C INSTALL-GUIDE1 1 1 1 1 1 ○ ○ SM1-MF08-040R2
15 ..2 J7065980A HANGER-SHAFT-GUIDE 1 1 1 1 1 ○ ○ SM1-MF08-042
16 ..2 J7065981A PROBER-COVER 1 1 1 1 1 ○ ○ SM1-MF08-043
17 ..2 J7065982A CABLE-COVER1 1 1 1 1 1 ○ ○ SM1-MF08-044
18 ..2 J70650988B LINK-SHAFT-COVER 2 2 2 2 2 ○ ○ SM1-MF08-051R1
19 ..2 J7065989A CABLE-COVER2 1 1 1 1 1 ○ ○ SM1-MF08-052
20 ..2 J70650990B CYL-BKT-SHAFT 1 1 1 1 1 ○ ○ SM1-MF08-053R1
21 ..2 J72650169D PCB-COVER 1 1 1 1 1 ○ ○ SM1-MF08-054R3
22 ..2 J7065992B BOTTOM-LOC-PIN 1 1 1 1 1 ○ ○ SM1-MF08-056R1
23 ..2 J70650993B DRAIN-BKT-SHAFT 1 1 1 1 1 ○ ○ SM1-MF08-057R1
24 ..2 J70650994B TOGGLE STOPPER 2 2 2 2 2 ○ ○ SM1-MF08-058R1
25 ..2 J70650995B TOGGLE SPG PIN 2 2 2 2 2 ○ ○ SM1-MF08-059R1
IT
Q'TY
Reference
NO.
LEVEL
PART NO.
PART NAME
TYPE
Non
-IT
Page
6
SAMSUNG TECHWIN
8mm SMN Tape Feeder
Part List
0402 2P 4P 2P-L 4P-L
26 ..2 J70660001C T-LINK4-SHAFT1 1 1 1 1 1 ○ ○ SM1-MF08-064R2
27 ..2 J70660008C T-LINK1-SHAFT1 1 1 1 1 1 ○ ○ SM1-MF08-071R2
28 ..2 J7066014A LOCKER-HINGE 2 2 2 2 2 ○ ○ SM1-MF08-076
30 ..2 J70660022B T-LINK5-SHAFT1 1 1 1 1 1 ○ ○ SM1-MF08-088R1
31 ..2 J7066024B COUPLER BKT1 1 1 1 1 1 ○ ○ SM1-MF08-090R1
32 ..2 J7066026A T-COVER 1 1 1 1 1 ○ ○ SM1-MF08-092
33 ..2 J7265159A SP-WASHER 3 3 3 3 3 ○ ○ SM1-MF08-104
34 ..2 J7066047A FLAT-HEAD-CAP-SCREW-H4 4 13 13 13 13 13 ○ ○ SM1-MF08-132
35 ..2 J71651332A MAIN FRAME 0 1 1 1 1 ○ ○ SM1-MF08-300
..2 J71651410A MAIN FRAME 0402 1 0 0 0 0 ○ ○ SM1-MF08-300-1
36 ..2 J70652410A DUMP BOX COVER 1 1 1 1 1 ○ ○ SM1-MF08-301
37 ..2 J72651139A CLEAR COVER 1 1 1 1 1 ○ ○ SM1-MF08-302
38 ..2 J70652174A X ECCENTRIC PIN 1 1 1 1 1 ○ ○ SM1-MF08-305
39 ..2 J70652409A CABLE COVER-3 1 1 1 1 1 ○ ○ SM1-MF08-306
40 ..2 J70652415A REEL COVER 1 1 1 1 1 ○ ○ SM1-MF08-313
41 ..2 J6601132A ONEWAY-BEARING-8 1 1 1 1 1 ○ ○ OWC8-16-5.5-L
42 ..2 J6711249A COUPLER-PLUG 1 1 1 1 1 ○ ○ KS-4-M5-SA34268KR
43 ..2 J1301161 FLAT HEAD CAP SCREW 1 1 1 1 1 ○ ○ M2*3(SUS)
44 ..2 J6004300350 BUTTON-HEAD-CAP-SCREW-M3X3 4 4 4 4 4 ○ ○ M3*3 (SUS)
45 ..2 J6004300850 BUTTON-HEAD-CAP-SCREW-M3X8 2 2 2 2 2 ○ ○ M3*8 (SUS)
46 ..2 J1301023 E RING3 1 1 1 1 1 ○ ○ DIA3 (SUS)
47 ..2 J1301149 E RING4 1 1 1 1 1 ○ ○ DIA4 (SUS)
48 ..2 J1301448 FLAT HEAD CAP SCREW 7 7 7 4 4 ○ ○ M3*6 (SUS)
49 ..2 J6006300850 FLAT-HEAD-CAP-SCREW-M3X8 9 9 9 9 9 ○ ○ M3*8 (SUS)
50 ..2 J6012300650 TRUSS SCREW 2 2 2 2 2 ○ ○ M4*12 (SUS)
51 ..2 J6007301238 FLAT-HEAD-SOCKET-SCREW M3X12 3 3 3 3 3 ○ ○ M3*12 (BL/Zn)
IT
Q'TY
Reference
NO.
LEVEL
PART NO.
PART NAME
TYPE
Non
-IT
Page
7
SAMSUNG TECHWIN
8mm SMN Tape Feeder
Part List
0402 2P 4P 2P-L 4P-L
52 ..2 J1301304 M4-NUT-3 2 2 2 2 2 ○ ○ M4 (SUS)
53 ..2 J6044400050 M4-TEETH-WASHER 2 2 2 2 2 ○ ○ M4 (SUS)
54 ..2 J6010300438 SOCKET-SET-SCREW-M3X4 1 1 1 1 1 ○ ○ M3*4 (BL/Zn)
55 ..2 J6004300650 BUTTON HEAD CAP SCREW 2 2 2 2 2 ○ ○ M3*6 (SUS)
56 ..2 J6001401538 SOCKET HEAD CAP SCREW 2 2 2 2 2 ○ ○ M4*15 (BL/Zn)
57 ..2 J7066033B LOCKER SPG PIN2 1 1 1 1 1 ○ ○ SM1-MF08-101R1
58 ..2 J7066040A TOGGLE SPRING 1 1 1 1 1 ○ ○ SM1-MF08-125
59 ..2 J7066036A P-LEVER SPRING 2P 0 1 1 1 1 ○ ○ SM1-MF08-121
..2 J7066349A P-LEVER SPG 0402 1 0 0 0 0 ○ ○ SM1-MF08-121-1
60 ..2 J70652182A S-PAWL SPRING 0 1 1 1 1 ○ ○ SM1-MF08-317
..2 J7066350A S-PAWL SPG 0402 1 0 0 0 0 ○ ○ SM1-MF08-123-1
61 ..2 J7066043A LOCKER SPRING 0 1 1 1 1 ○ ○ SM1-MF08-128
..2 J70661016A LOCKER SPRING 0402 1 0 0 0 1 ○ ○ SM1-MF08-128-1
62 ..2 J7066046A LOCKER LIMIT SPRING 1 1 1 1 1 ○ ○ SM1-MF08-131
63 ..2 J70652553A TAPE GUIDE SPRING 0 1 1 1 1 ○ ○ SM1-MF08-129
..2 J7066351A TAPE GUIDE SPG 0402 1 0 0 0 0 ○ ○ SM1-MF08-129-1
64 ..2 J7066039A D-LEVER SPRING 1 1 1 1 1 ○ ○ SM1-MF08-124
65 ..2 J7066042A D-BKT SPRING 1 1 1 1 1 ○ ○ SM1-MF08-127
66 ..2 J7066041A LEVER2 SPRING 1 1 1 1 1 ○ ○ SM1-MF08-126
67 ..2 J7066025A COUPLER BKT2 1 1 1 1 1 ○ ○ SM1-MF08-091
68 ..2 J7066371A LOCKER PIN 1 1 1 1 1 ○ ○ SM1-MF08-097
69 ..2 J70652551A STOP PAWL LEVER SHAFT 1 1 1 1 1 ○ ○ SM1-MF08-314
70 ..2 J71651333A DRAIN GEAR COLLAR 1 1 1 1 1 ○ ○ SM1-MF08-315
71 ..2 J70652554A PUSH BUTTON SPRING 2 2 2 2 2 ○ ○ SM1-MF08-321
72 ..2 J7065744A TAPE SUPPORT 1 1 1 1 1 ○ ○ TF08-Q169R2
IT
Q'TY
Reference
NO.
LEVEL
PART NO.
PART NAME
TYPE
Non
-IT
