SAMSUNG TECHWIN
24mm SMN Tape Feeder
Part List
1 ..2 J71651416A MAIN FRAME-24 1 ○ ○
2 ..2 J70652660A FRAME COVER-24 1 ○ ○
3 ..2 J70652659A EDGE SUPPORT-24 1 ○ ○
4 ..2 J70652658A SIDE PLATE-24 1 ○ ○
5 ..2 J71651420A PRESSING GEAR MOUNT-24 1 ○ ○
6 ..2 J72651163A VINYL BOX-24 1 ○ ○
7 ..2 J70652625A ROUND GUIDE-24 1 ○ ○
8 ..2 J70652647A FLAT GUIDE-24 1 ○ ○
9 ..2 J70652652A REEL BRAKE-24 1 ○ ○
10 ..2 J70652635A DRAIN GEAR FORK-24 1 ○ ○
11 ..2 J70652652A VINYL DOOR-24 1 ○ ○
12 ..2 J70652665A DRAIN GEAR POST-24 1 ○ ○
13 ..2 J70652678A ROLLER SHAFT-2432 1 ○ ○
14 ..2 J72651175A VINYL ROLLOR-24 1 ○ ○
15 ..2 J70652681A VINYL DOOR SHAFT-24 1 ○ ○
16 ..2 J70652687A REEL BRAKE SHAFT-24 1 ○ ○
17 ..2 J70652696A PRESSING LEVER SHAFT-2432 1 ○ ○
18 ..2 J70652699A TAPE GUIDE SHAFT-24 1 ○ ○
19 ..2 J70652734A MANUAL LEVER 1 ○ ○
20 ..2 J70652739A PROBER COVER 1 ○ ○
21 ..2 J70652749A VINYL CUTTER 1 ○ ○
22 ..2 J72651182A VINYL BOX COVER 1 ○ ○
23 ..2 J71651439A SECTION COVER 1 ○ ○
24 ..2 J70652710A Y ECCENTRIC PIN 1 ○ ○
25 ..2 J70652711A CYLINDER JOINT 1 ○ ○
26 ..2 J70652713A MANUAL LEVER SHAFT 1 ○ ○
Q'TY
IT
Reference
PART NO.
PART NAME
TYPE
Non -
IT
Page
50
SAMSUNG TECHWIN
24mm SMN Tape Feeder
Part List
27 ..2 J70652728A LOCKER LINK POST 1 ○ ○
28 ..2 J70652717A LOCKER SLOT PIN 1 ○ ○
29 ..2 J70652721A CYLINDER RETURN SPRING POST 1 ○ ○
30 ..2 J70652722A MAGNET LINK SHAFT 1 ○ ○
31 ..2 J70652725A GRIP NUT 1 ○ ○
32 ..2 J70652726A PRESSING GEAR SPRING POST 1 ○ ○
33 ..2 J70652727A T-LINK4 PIN 1 ○ ○
34 ..2 J72651184A HANDLE 1 ○ ○
35 ..2 J6039300050 FLANGE NUT 1 ○ ○ FRSNUT3
36 ..2 J61071065A FEEDING SPRING 1 ○ ○ AWU8-65
37 ..2 J6119061A FLAT BOLT 2 ○ ○ CBSS 3-6
38 ..2 J70652373A SPROCKET SHAFT 1 ○ ○
39 ..2 J70652593A LEVER SHAFT 1 1 ○ ○
40 ..2 J61071054A STOP PAWL SPRING 3 ○ ○
41 ..2 J70650994B TOGGLE STOPPER 3 ○ ○
42 ..2 J70650995B TOGGLE SPRING PIN 1 ○ ○
43 ..2 J70660001B T LINK4 SHAFT1 1 ○ ○
44 ..2 J70660008B T LINK 1 SHAFT 1 ○ ○
45 ..2 J7066159A LIMIT SHAFT 1 ○ ○
46 ..2 J7265159A SP WASHER 2 ○ ○
47 ..2 J70652273A LEVER SHAFT 2 2 ○ ○
48 ..2 J7066040A TOGGLE SPRING 1 ○ ○
49 ..2 J7066039A D LEVER SPRING 1 ○ ○
50 ..2 J7066239A REELl POST-24 1 ○ ○
51 ..2 J7065992B BOTTOM LO PIN 1 ○ ○
52 ..2 J70650978C INSTALL GUIDE 1 ○ ○
Q'TY
IT
Reference
PART NO.
PART NAME
TYPE
Non -
IT
Page
51
SAMSUNG TECHWIN
24mm SMN Tape Feeder
Part List
53 ..2 J7065944A V LOC PIN 1 ○ ○
54 ..2 J7065948A LOCATION FLANGE 1 ○ ○
55 ..2 J7066140A LOCKER SPRING 1 ○ ○
56 ..2 J70691006A REEL BRAKE SPRING 1 ○ ○
57 ..2 J7066079A REEL PLATE SHAFT 1 ○ ○
58 ..2 J90651490A FILTER ASSY 1 ○ ○
59 ..2 J7066315A DAMPER WASHER 1 ○ ○
60 ..2 J7265131A DAMPER 1 ○ ○
61 ..2 J6711249A COUPLER PLUG 1 ○ ○
62 ..2 J7066024B COUPLER BKT1 1 ○ ○
63 ..2 J7066025A COUPLER BKT2 1 ○ ○
64 ..2 J1301023 E-RING ○ ○ DIA3 (SUS)
65 ..2 J1301149 E-RING ○ ○ DIA4 (SUS)
66 ..2 J1301303 E-RING ○ ○ DIA5 (SUS)
67 ..2 J1301266 HEX NUT ○ ○ M3 (SUS)
68 ..2 J1301304 HEX NUT ○ ○ M4 (SUS)
69 ..2 J6044400050 STAR WASHER ○ ○ M4 (SUS)
70 ..2 J6007301238 FLAT HEAD SOCKET SCREW ○ ○ M3*12 (BL/ZN)
71 ..2 J6006254050 FLAT HEAD CAP SCREW ○ ○ M2.5*4 (SUS)
72 ..2 J6010400438 SOCKET SET SCREW ○ ○ M4*4 (BL/Zn)
73 ..2 J1301448 FLAT HEAD CAP SCREW ○ ○ M3*6 (SUS)
74 ..2 J2101083 FLAT HEAD TAPPING SCREW ○ ○ M3*8
75 ..2 J6012300650 TRUSS SCREW ○ ○ M3*6 (SUS)
76 ..2 J6006300850 FLAT HEAD CAP SCREW ○ ○ M3*8 (SUS)
77 ..2 J6006400850 FLAT HEAD CAP SCREW ○ ○ M4*8 (SUS)
78 ..2 J6009401250A SEMUS NABE SCREW ○ ○ M4*12 (SUS)
