SMN Feeder_Technical Reference_Ver5.pdf - 第56页
SAMSUNG TECHWIN Page 56 24m m SMN T ape Fe ede r -Su b Probe Cable Ass'y-NONIT A-22 Probe Cable Ass'y-IT A-22 Drain Link Ass'y A-19 Indexing Sensor Ass'y-2488 A-20 Clamp Switch Cable Ass'y-2488 A…
SAMSUNG TECHWIN
Page
55
24mm SMN Tape Feeder -Sub
Reel Plate Ass'y
A-17
T-Link Ass'y
A-18
T-Link5 Ass'y
A-13
Pusher Link Ass'y
A-14
Stop Pawl Ass'y-2488
A-15
Reel Hanger Ass'y-2488
A-16
8
6
1
7
2
4
5
3
8
SAMSUNG TECHWIN
Page
56
24mm SMN Tape Feeder -Sub
Probe Cable Ass'y-NONIT
A-22
Probe Cable Ass'y-IT
A-22
Drain Link Ass'y
A-19
Indexing Sensor Ass'y-2488
A-20
Clamp Switch Cable Ass'y-2488
A-21
1
SAMSUNG TECHWIN
Page
57
24mm SMN Tape Feeder -Sub
NONIT PCB Ass'y
A-24
IT Slave PCB Ass'y
A-24
Feeding Switch Ass'y-NONIT
A-23
Feeding Switch Ass'y-IT
A-23
Solenoid Cable Ass'y
A-25
Reel Stopeer Ass'y
A-26
