Page 35 SAMSUNG TECHWIN 16m m SMN T ape Fe ede r Part List 1 ..2 J7265 159A SP WASHE R 3 ○ ○ SM1-M F08-1 04 2 ..2 J6711 249A COU PLER PLUG 1 ○ ○ KS-4- M5-SA 34268 KR 3 ..2 J7065 0944B V LOC PIN 1 ○ ○ S M1-MF 08-00 2R1 4 …

100%1 / 104
Page
34
SAMSUNG TECHWIN
16mm SMN Tape Feeder (Rear)
Cylinder Ass'y
A-3
Drain Lever & Gear Ass'y
A-16
Forming Gear Ass'y
A-11
Drain BKT Ass'y
A-13
Reel Ass'y
A-10
Clamp Swich Cable Ass'y
A-9
Handle Ass'y
A-15
16
13
16
18
18
18
18
18
22
25
25
31
32
33
33
34
38
40
41
42
43
45
46
50
54
54
54
58
58
58
58
58
59
64
66
66
66
44
Page
35
SAMSUNG TECHWIN
16mm SMN Tape Feeder
Part List
1 ..2 J7265159A SP WASHER 3 ○ ○ SM1-MF08-104
2 ..2 J6711249A COUPLER PLUG 1 ○ ○ KS-4-M5-SA34268KR
3 ..2 J70650944B V LOC PIN 1 ○ ○ SM1-MF08-002R1
4 ..2 J70650948B LOCATION FLANGE 1 ○ ○ SM1-MF08-006R1
5 ..2 J70650956C LINK SHAFT COVER2 1 ○ ○ SM1-MF08-014R2
6 ..2 J70650978C INSTALL GUIDE 1 ○ ○ SM1-MF08-040R2
7 ..2 J7065981A PROBER COVER 1 ○ ○ SM1-MF08-043
8 ..2 J7065992B BOTTOM LOC PIN 1 ○ ○ SM1-MF08-056R1
9 ..2 J70650994B TOGGLE STOPPER 1 ○ ○ SM1-MF08-058R1
10 ..2 J70650995B TOGGLE SPG PIN 1 ○ ○ SM1-MF08-059R1
11 ..2 J70660001B T LINK4 SHAFT1 1 ○ ○ SM1-MF08-064R1
12 ..2 J70660008C T LINK1 SHAFT1 1 ○ ○ SM1-MF08-071R2
13 ..2 J70660022B T LINK5 SHAFT1 1 ○ ○ SM1-MF08-088R1
14 ..2 J7066024B COUPLER BKT1 1 ○ ○ SM1-MF08-090R1
15 ..2 J7066025A COUPLER BKT2 1 ○ ○ SM1-MF08-091
16 ..2 J7066026A T-COVER 2 ○ ○ SM1-MF08-092
17 ..2 J7066040A TOGGLE SPRING 1 ○ ○ SM1-MF08-125
18 ..2 J7066047A FLAT HEAD CAP SCREW-H4.4 26 ○ ○ SM1-MF08-132
19 ..2 J7065952A Y ECCENTRIC PIN 1 ○ ○ SM1-MF08-009
20 ..2 J6006301250 FLAT HEAD CAP SCREW 3 ○ ○ M3X12(SUS)
21 ..2 J7065959A LIMIT SHAFT 1 ○ ○ SM1-MF08-017
22 ..2 J70652290A REEL COVER 1 ○ ○ J70652290A
23 ..2 J70652593A LEVER SHAFT 3 1 ○ ○ J70652593A
24 ..2 J7066064A CYL BKT PIN 1 ○ ○ SM1-MF12-109
25 ..2 J70652273A LEVER SHAFT2 2 ○ ○ J70652273A
26 ..2 J70652526A TAPE SUPPORT 1 ○ ○ J70652526A
Q'TY
IT
Reference
PART NO.
PART NAME
TYPE
Non -
IT
Page
36
SAMSUNG TECHWIN
16mm SMN Tape Feeder
Part List
27 ..2 J70660070B LOCKER SPRING 1 ○ ○ SM1-MF12-118R7
28 ..2 J7066071A TAPE GUIDE SPRING 1 ○ ○ SM1-MF12-119-2
29 ..2 J61071066A FEEDING SPRING 1 ○ ○ J61071066A
30 ..2 J61071054A STOP PAWL SPRING 1 ○ ○ J61071054A
31 ..2 J61071053A DRAIN LEVER SPRING 1 ○ ○ J61071053A
32 ..2 J71650297C PCB COVER 1 ○ ○ SM1-MF12-128R5
33 ..2 J7066076A SPRING PIN 25 2 ○ ○ SM1-MF12-129
34 ..2 J7066088A FORMING BKT SHAFT 1 ○ ○ SM1-MF12-131-3
35 ..2 J70660083B LOCKING LIMIT 1 ○ ○ SM1-MF12-140R3
36 ..2 J70660313B TOGGLE STOPPER2 2 ○ ○ SM1-MF12-150R
37 ..2 J70661019A SPRING PIN 26 1 ○ ○ SM1-MF12-152
38 ..2 J7066089A DRAIN PAWL SPRING 1 ○ ○ SM1-MF12-153-4
39 ..2 J70661020A LOCKER HINGE 2 ○ ○ SM1-MF12-156
40 ..2 J72650164B VINYL ROLLER 1 ○ ○ SM1-MF16-036R
41 ..2 J70660087B VINYL ROLLER SHAFT 1 ○ ○ SM1-MF16-037R3
42 ..2 J70652049A VINYL REMOVE BKT 1 ○ ○ J70652049A
43 ..2 J70652527A CYLINDER CABLE COVER 1 ○ ○ J70652527A
44 ..2 J6012401550 TRUSS SCREW 2 ○ ○ M4*15 (SUS)
45 ..2 J70652598A VINYL ROLLER SHAFT 3 1 ○ ○ J70652598A
46 ..2 J72651136A VINYL ROLLER 3 1 ○ ○ J72651136A
47 ..2 J71651355A 16MM MAIN FRAME 1 ○ ○ J71651355A
48 ..2 J70652373A 16MM SPROCKET SHAFT 1 ○ ○ J70652373A
49 ..2 J70660058B TAPE GUIDE SHAFT 1 ○ ○ SM1-MF16-038R
50 ..2 J70652374A 16MM TAKE UP REEL SHAFT 1 ○ ○ J70652374A
51 ..2 J70660086B LOCKER LIMIT SPRING 1 ○ ○ SM1-MF16-148R
52 ..2 J6502008A LOW PROFILE MOUNTS 1 ○ ○ DALM5 (NYLON)
Q'TY
IT
Reference
PART NO.
PART NAME
TYPE
Non -
IT
