YSC1_pl.pdf - 第10页
39 12 30 7 18 13 25 14 17 13 13 26 7 3 1 14 14 41 29 27 13 4 24 38 23 6 28 16 32 33 22 36 10 37 20 9 21 10 34 7 35 10 40 8 2 31 5 9 39 15 11 19 7 X-Axis Assy 2 Moving-axis Section KLD-1202 3-4 OLD NO Parts_No. Parts_Name…
11
32
13
8
20
14
5
18
3
8
24
5
21
15
12
3
5
1
8
4
19
31
12
1
4
10
16
34
35
23
28
8
7
29
7
5
33
5
25
5
18
26
22
8
9
5
5
27
36
1
4
30
2
5
6
X-Axis Assy 1(NEW)
Moving -axis Section
KLD-1202
3-3
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
16
2
90166-12JA06
SCREW, PAN HEAD
6
3
90990-01J032
BOLT HEX,SOCKET HEAD
8
4
90990-11J001
SCREW, PAN HEAD W/W
16
5
90990-12J001
SCREW, BIN. HEAD W/W
19
6
90990-46J006
BOLT, THIN HEAD
3
7
91312-04006
BOLT HEX,SOCKET HEAD
15
OK
MH00014-2012/1/11
8
91312-04008
BOLT HEX,SOCKET HEAD
15
9
91312-04022
BOLT HEX,SOCKET HEAD
1
10
91312-08025
BOLT HEX,SOCKET HEAD
14
11
KHN-M220F-04
CAMERA SELECTOR
1
12
98902-03006
SCREW BINDING HEAD
4
13
KHY-M2267-A0
GUIDE,X AXIS ASSY
1
14
KHY-M221A-A0
COVER,DUCT ASSY.
1
15
KGT-M2266-10
PLATE, NUT
1
16
KHN-M22F8-00
WASHER,SWR08
14
17
KLD-M22E0-00
GUIDE CABLE ASSY
1
18
KHY-M2265-00
JOINT
1
19
KHY-M2266-00
PLATE,NUT
1
20
KHY-M2268-00
BRACKET 1, TAPE
1
21
KHY-M2269-00
BRACKET 2,TAPE
1
22
KLD-M220E-00
TAPE, X-AXIS
3
23
KLD-M2213-S0
PLATE X AXIS SET
1
24
KLD-M223G-01
STAY,L HNS.
1
NG
MH00014-2012/1/11
25
KLD-M2251-00
BRACKET,CONNECTOR
1
26
KLD-M2292-00
COVER,HEAD SERVO
1
No outside I/O
27
KLD-M2292-10
COVER,HEAD SERVO
1
Outside I/O
28
KLD-M2294-01
STAY,DUCT 1
1
NG
MH00014-2012/1/11
29
KLD-M2295-01
STAY,DUCT 2
1
NG
MH00014-2012/1/11
30
KLD-M2297-00
COVER
1
31
KLD-M2298-00
COVER,R HNS
1
32
KLD-M2299-00
BRACKET,CABLE 1
1
33
KLD-M229A-00
BRACKET,CABLE 2
1
34
KLD-M22C5-00
COVER UNDER,X AXIS
1
35
KV7-M2231-00
SPACER R,NUT
4
36
KLD-M4554-00
TERMINAL BORD ASSY
1
39
12
30
7
18
13
25
14
17
13
13
26
7
3
1
14
14
41
29
27
13
4
24
38
23
6
28
16
32
33
22
36
10
37
20
9
21
10
34
7
35
10
40
8
2
31
5
9
39
15
11
19
7
X-Axis Assy 2
Moving-axis Section
KLD-1202
3-4
OLD
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KJX-M7192-00
HEAD I/O BOX
1
2
$NK-3N
NYLON CLIP
12
3
90563-03J160
SPACER
4
4
90990-01J037
BOLT HEX,SOCKET HEAD
6
5
90990-11J001
SCREW, PAN HEAD W/W
12
6
91312-04006
BOLT HEX,SOCKET HEAD
8
7
91312-04008
BOLT HEX,SOCKET HEAD
13
8
91312-05008
BOLT HEX,SOCKET HEAD
6
9
91312-05012
BOLT HEX,SOCKET HEAD
4
10
91312-05018
BOLT HEX,SOCKET HEAD
12
11
91312-06016
BOLT HEX,SOCKET HEAD
2
12
97602-03108
SCREW PAN HEAD W/WASHER
4
13
97602-03306
SCREW PAN HEAD W/WASHER
22
14
98702-03004
SCREW,FLAT HEAD
12
15
98902-04006
SCREW BINDING HEAD
4
16
99480-06018
PIN,PARALLEL
2
17
KJX-M7192-30
POST3
1
18
KJX-M7192-40
POST4
1
19
KGS-M2256-00
GRIP
1
20
KHN-M22F5-00
WASHER,SWR05
8
21
KHY-M2252-02
STOPPER
1
22
KHY-M2284-00
BRACKET,SENSOR
1
23
KHY-M652W-00
SENSOR
1
24
KHY-M652X-00
SENSOR
1
25
KHY-M5890-40
HEAD SERVO BOARD ASSY
3
26
KJX-M457R-01
HEAD I/O1 BOARD ASSY
1
27
KJX-M457W-01
HEAD I/O3 BOARD ASSY
1
28
KJX-M7191-10
FRAME,I/O BOX
1
29
KJX-M7196-00
BRACKET,FAN
1
30
KJX-M719A-00
PLATE 2,GUIDE HARNESS
1
31
KLD-M2237-00
BRACKET,HEAD SERVO
1
32
KLD-M2238-00
BRACKET,L
1
33
KLD-M2239-00
BRACKET,R
1
34
KLD-M223F-00
STAY,R HNS.
1
35
KLD-M226B-00
COVER BACK, X AXIS
1
36
KLD-M227G-00
COVER,B.S.
1
37
KLD-M2291-00
PLATE,HEAD SERVO
1
38
KLD-M2A01-01
PLATE,HEAD
1
39
KLD-M2A02-00
STAY,HANDLE
1
39-1
KLD-M2A02-01
STAY,HANDLE
1
NG
MJ10011-2012/1/11
40
KV7-M7165-00
SEAL DON'T TOUCH
2
41
KLD-M220D-00
TAPE, X-AXIS
2
28
16
31
17
15
5
3
21
33
23
12
32
23
3
22
18
19
4
9
34
35
27
10
15
25
20
24
26
8
30
7
1
29
14
2
13
6
11
28
16
31
17
15
5
3
21
33
23
12
32
23
3
22
18
19
4
9
34
35
27
10
15
25
20
24
26
8
30
7
1
29
14
2
13
6
11
Y-axis Drive
Moving -axis Section
KLD-1202
3-5
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
3
2
90990-12J006
SCREW, BIN. HEAD W/W
2
3
90990-26J008
BEARING
2
4
KHY-M224A-A0
SUPPORT UNIT
1
5
90990-41J100
COLLAR
1
6
90K63-611404
AC SERVO MOTOR
1
7
91312-04008
BOLT HEX,SOCKET HEAD
2
8
$UB0425-C
URETHANE TUBE
1
L=180mm
9
91312-04025
BOLT HEX,SOCKET HEAD
2
10
91312-05014
BOLT HEX,SOCKET HEAD
4
11
91312-06018
BOLT HEX,SOCKET HEAD
4
12
91312-06020
BOLT HEX,SOCKET HEAD
4
13
91312-06035
BOLT HEX,SOCKET HEAD
4
14
92012-03005
BOLT BUTTON HEAD
2
15
92A08-04305
SCREW SET
2
16
KLD-M26G0-00
Y GREASE PIPE ASSY.
1
17
KG2-M9173-00
LOCK NUT
1
18
KHN-M224J-00
COLLAR A
2
19
KHN-M224K-00
COLLAR B
2
20
KHN-M22AD-00
GREASE NIPPLE
1
21
KHY-M2642-00
HOLDER,BRG.Y
1
22
KHY-M2648-00
DAMPER
1
23
KHY-M264L-00
SPACER,BRG SET
1
24
KHY-M266C-00
BLOCK,JOINT
1
25
KHY-M266D-00
JOINT
1
26
KHY-M266E-00
JOINT
1
27
KHY-M2671-00
BALL SCREW
1
28
KHY-M2671-A0
Y AXIS B.S.SUB ASSY
1
29
KLD-M2641-00
HOLDER,MOTOR Y
1
30
KLD-M266A-00
PLATE,PIPE
1
31
KM0-M2220-00
COUPLING, X-AXIS
1
32
99480-05010
PIN,PARALLEL
1
33
91312-03006
BOLT HEX,SOCKET HEAD
4
34
KHY-M652F-00
SENSOR,YOT ASSY
1
35
KHY-M652A-00
SENSOR,YORG ASSY
1
