16 17 12 3 11 31 4 1 18 5 15 31 1 4 32 8 38 28 8 5 35 7 37 36 30 19 39 5 29 13 8 7 20 8 8 33 10 5 5 7 26 34 21 5 5 1 4 23 5 2 22 27 25 5 6 14 24 9 X-Axis Assy 1(OLD) Moving -axis Section KLD-1 107 3-2 NO Parts_No. Parts_…
27
34
33
11
31
28
3
17
30
8
16
32
15
20
4
20
24
29
25
1
2
7
6
21
31
3
6
21
9
22
26
6
14
26
26
6
36
6
7
23
25
24
36
29
6
13
12
18
15
35
19
27
11
5
10
X-Axis Sub Assy
Moving -axis Section
KLD-1202
3-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
12
2
90990-11J001
SCREW, PAN HEAD W/W
12
3
90990-11J003
SCREW, PAN HEAD W/W
6
4
90990-26J008
BEARING
1
5
90K63-511403
AC SERVO MOTOR
1
6
91312-04014
BOLT HEX,SOCKET HEAD
38
7
92012-04025
BOLT,BUTTON HEAD
4
8
91312-05014
BOLT HEX,SOCKET HEAD
4
9
91312-05018
BOLT HEX,SOCKET HEAD
4
10
91312-06018
BOLT HEX,SOCKET HEAD
4
11
91312-06025
BOLT HEX,SOCKET HEAD
8
12
KHN-M2221-00
SUPPORT UNIT
1
13
91317-04012
BOLT HEX,SOCKET HEAD
4
14
KLD-M2261-A0
HOLDER,HEAD R ASSY.
1
15
92A08-04304
SCREW SET
2
16
KG2-M9173-00
LOCK NUT
1
17
KGK-M2276-S0
X-AXIS GUIDE SET
1
18
KGS-M2628-00
LOCK NUT
1
19
KHN-M2241-00
HOLDER,MOTOR X
1
20
KHN-M2248-00
SPACER
2
21
90K81-200006
CAP M4
22
22
KLD-M2271-00
BALL SCREW
1
23
KHN-M224D-00
SPACER
1
24
KHN-M224J-00
COLLAR A
4
25
KHN-M224K-00
COLLAR B
4
26
KHN-M22F4-00
WASHER,SWR04
16
27
KHN-M22F6-00
WASHER,SWR06
8
28
KHY-M2240-00
SLEEVE,BRG.
1
29
KHY-M224H-00
DAMPER
2
30
KHY-M2282-00
DOG.ORIGIN
1
31
KHY-M2283-00
DOG,SECOND LIMIT
2
32
KLD-M220D-00
TAPE, X-AXIS
2
33
KLD-M2211-00
FRAME R, X AXIS
1
34
KLD-M2242-00
HOLDER,BRG.
1
35
KM0-M2220-00
COUPLING, X-AXIS
1
36
99480-06018
PIN,PARALLEL
2
16
17
12
3
11
31
4
1
18
5
15
31
1
4
32
8
38
28
8
5
35
7
37
36
30
19
39
5
29
13
8
7
20
8
8
33
10
5
5
7
26
34
21
5
5
1
4
23
5
2
22
27
25
5
6
14
24
9
X-Axis Assy 1(OLD)
Moving -axis Section
KLD-1107
3-2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
23
2
90166-12JA06
SCREW, PAN HEAD
6
3
90990-01J032
BOLT HEX,SOCKET HEAD
8
4
90990-11J001
SCREW, PAN HEAD W/W
23
5
90990-12J001
SCREW, BIN. HEAD W/W
25
6
90990-46J006
BOLT, THIN HEAD
3
7
91312-04006
BOLT HEX,SOCKET HEAD
17
8
91312-04008
BOLT HEX,SOCKET HEAD
15
9
91312-04022
BOLT HEX,SOCKET HEAD
1
10
92902-04200
WASHER,PLAIN
2
11
KGT-M2266-10
PLATE, NUT
1
12
KHY-M221A-A0
COVER DUCT ASSY.
1
13
KHY-M2236-00
STAY,DUCT
1
14
KHY-M2265-00
JOINT
1
15
KHY-M2266-00
PLATE,NUT
1
16
KHY-M2267-A0
GUIDE,X AXIS ASSY
1
17
KHY-M2268-00
BRACKET 1, TAPE
1
18
KHY-M2269-00
BRACKET 2,TAPE
1
19
KLD-M220E-00
TAPE, X-AXIS
3
20
KLD-M2292-00
COVER,HEAD SERVO
1
21
KLD-M2294-00
STAY,CONNECTOR
1
22
KLD-M2295-00
STAY,HEAD HNS
1
23
KLD-M2296-00
STAY,HEAD HNS
1
24
KLD-M2297-00
COVER
1
25
KLD-M2299-00
BRACKET,CABLE 1
1
26
KLD-M229A-00
BRACKET,CABLE 2
1
27
KLD-M4554-00
TERMINAL BORD ASSY
1
28
KLD-M223H-00
STAY,R HNS
1
29
KLD-M2251-00
BRACKET,CONNECTOR
1
30
KLD-M2293-00
STAY,HEAD SERVO
1
31
98902-03006
SCREW BINDING HEAD
4
32
KLD-M2298-00
COVER,R HNS
1
33
KHN-M220F-04
CAMERA SELECTOR
1
34
KLD-M2292-10
COVER,HEAD SERVO
1
35
KLD-M223G-00
STAY,L HNS.
1
36
KLD-M2213-S0
PLATE X AXIS SET
1
37
91312-08025
BOLT HEX,SOCKET HEAD
14
38
KLD-M22C5-00
COVER UNDER,X AXIS
1
39
KV7-M2231-00
SPACER R,NUT
4
11
32
13
8
20
14
5
18
3
8
24
5
21
15
12
3
5
1
8
4
19
31
12
1
4
10
16
34
35
23
28
8
7
29
7
5
33
5
25
5
18
26
22
8
9
5
5
27
36
1
4
30
2
5
6
X-Axis Assy 1(NEW)
Moving -axis Section
KLD-1202
3-3
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
16
2
90166-12JA06
SCREW, PAN HEAD
6
3
90990-01J032
BOLT HEX,SOCKET HEAD
8
4
90990-11J001
SCREW, PAN HEAD W/W
16
5
90990-12J001
SCREW, BIN. HEAD W/W
19
6
90990-46J006
BOLT, THIN HEAD
3
7
91312-04006
BOLT HEX,SOCKET HEAD
15
OK
MH00014-2012/1/11
8
91312-04008
BOLT HEX,SOCKET HEAD
15
9
91312-04022
BOLT HEX,SOCKET HEAD
1
10
91312-08025
BOLT HEX,SOCKET HEAD
14
11
KHN-M220F-04
CAMERA SELECTOR
1
12
98902-03006
SCREW BINDING HEAD
4
13
KHY-M2267-A0
GUIDE,X AXIS ASSY
1
14
KHY-M221A-A0
COVER,DUCT ASSY.
1
15
KGT-M2266-10
PLATE, NUT
1
16
KHN-M22F8-00
WASHER,SWR08
14
17
KLD-M22E0-00
GUIDE CABLE ASSY
1
18
KHY-M2265-00
JOINT
1
19
KHY-M2266-00
PLATE,NUT
1
20
KHY-M2268-00
BRACKET 1, TAPE
1
21
KHY-M2269-00
BRACKET 2,TAPE
1
22
KLD-M220E-00
TAPE, X-AXIS
3
23
KLD-M2213-S0
PLATE X AXIS SET
1
24
KLD-M223G-01
STAY,L HNS.
1
NG
MH00014-2012/1/11
25
KLD-M2251-00
BRACKET,CONNECTOR
1
26
KLD-M2292-00
COVER,HEAD SERVO
1
No outside I/O
27
KLD-M2292-10
COVER,HEAD SERVO
1
Outside I/O
28
KLD-M2294-01
STAY,DUCT 1
1
NG
MH00014-2012/1/11
29
KLD-M2295-01
STAY,DUCT 2
1
NG
MH00014-2012/1/11
30
KLD-M2297-00
COVER
1
31
KLD-M2298-00
COVER,R HNS
1
32
KLD-M2299-00
BRACKET,CABLE 1
1
33
KLD-M229A-00
BRACKET,CABLE 2
1
34
KLD-M22C5-00
COVER UNDER,X AXIS
1
35
KV7-M2231-00
SPACER R,NUT
4
36
KLD-M4554-00
TERMINAL BORD ASSY
1
