Contents
KLD-1107
1 Base Section
Base .....................................................................1-1
2 Cover Section
Top Cover .............................................................2-1
Acryl Door/LCD Stay/Bracket Keyboard ...............2-2
Base Cover ...........................................................2-3
3 Moving-axis Section
X-axis Sub Assy ...................................................3-1
X-axis assy 1 (OLD) .............................................3-2
X-axis assy 1 (NEW) ............................................3-3
X-axis assy 2 ........................................................3-4
Y-axis Drive ..........................................................3-5
Y-axis Frame/Duct/Stopper/Cover ........................3-6
Y-axis Guide .........................................................3-7
4 Head Section
Camera Z-axis ......................................................4-1
Camera .................................................................4-2
Z1,Z2 Axis ............................................................4-3
R1,R2 Axis ...........................................................4-4
Ejecter .................................................................4-5
5 Nozzle Section
Nozzle ...................................................................5-1
6 Conveyor Unit Section
Push UP assy .......................................................6-1
Stopper/sensor/Plate guide/Push up pin ..............6-2
Clamp Board .........................................................6-3
Transportation ......................................................6-4
Width Adjustment/Base ........................................6-5
7 Camera Section
Multi Camera Assy ...............................................7-1
8 Controller Section
Control Box ...........................................................8-1
9 Exterior, etc Section
Exterior, etc ...........................................................9-1
18
17
32
19
27
21
4
15
37
34
15
40
12
10
47
13
42
16
36
33
2
48
15
45
36
30
4
36
35
38
39
8
15
4
1
2
31
8
49
8
51
50
5
22
16
3
8
52
53
7
46
24
44
54
15
6
16
41
20
43
11
9
25
16
14
Base
Base Section
KLD-1202
1-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
4
2
90990-11J003
SCREW, PAN HEAD W/W
8
3
KHY-M11B0-00
AIR TAG
1
4
90990-12J004
SCREW, BIN. HEAD W/W
23
5
91312-03030
BOLT HEX,SOCKET HEAD
4
6
91312-04005
BOLT HEX,SOCKET HEAD
4
7
91312-04008
BOLT HEX,SOCKET HEAD
4
8
91312-05010
BOLT HEX,SOCKET HEAD
9
9
91312-06012
BOLT HEX,SOCKET HEAD
1
10
91312-06014
BOLT HEX,SOCKET HEAD
4
11
92902-06200
WASHER,PLAIN
1
12
92990-06200
WASHER,PLAIN
4
13
98902-03006
SCREW BINDING HEAD
8
14
98902-04006
SCREW BINDING HEAD
4
15
98902-05010
SCREW BINDING HEAD
16
16
$SL12-03
JOINT
4
17
KG7-M8501-00
AIR FILTER
1
18
KG7-M8502-00
MIST FILTER
1
19
KG7-M8503-00
MODULE ADAPTER
1
20
KLD-M6680-00
HNS,USB MEMORY 3M AS
1
21
KHM-M1397-00
BRACKET,FDD 3
1
22
KHW-M8582-40
VALVE
5
23
KHY-M1124-00
PLATE 24
1
24
KHY-M1129-00
PLATE 25-1
1
25
KHY-M8501-00
EXHAUST VALVE
1
26
KHY-M8504-00
REGULATOR
1
27
KHY-M8596-00
PRESSURE GAUGE
1
28
KJJ-M4554-00
TERMINAL BOARD ASSY
2
29
KKE-M1125-01
PLATE 25
1
30
KLD-M1130-00
PLATE 30
1
31
KLD-M1131-00
PLATE 31
1
32
KLD-M1133-00
PLATE 33
2
33
KLD-M1134-00
COVER,TERMINAL
2
34
KLD-M1151-00
PLATE SIDE L
1
35
KLD-M1152-00
PLATE SIDE R
1
36
KLD-M1383-00
BRACKET,FIX
4
37
KLD-M1384-00
BRACKET 2,FIX
4
38
KV7-M1125-00
PLATE,CLAMP
1
39
KHW-M8597-00
BRACKET,GAUGE
1
40
KGA-M1180-00
LEVELING BOLT ASSY.
4
41
$KM-22
MUFFLER
1
42
$KM-31
MUFFLER
1
43
90990-42J008
JOINT
1
44
90990-42J006
JOINT
1
45
$SLY10-03
JOINT
1
46
90K41-000540
LABEL,ALERT
1
47
KG2-M669R-11
HNS, BUZZER
1
48
$SL4-M5
JOINT
1
49
$SL8-01
JOINT
1
50
$KM-11
MUFFLER
1
51
KLD-M8582-00
VALVE
1
52
KG7-M8501-40
FILTER ELEMENT
1
53
KG7-M8502-40
MIST FILTER ELEMENT
1
54
KG7-M8501-50
BOWL SET (AD300)
2
39
25
30
37
35
4
4
4
29
16
4
4
4
19
9
4
34
38
10
23
4
8
18
10
34
30
4
8
4
21
8
17
10
36
4
8
4
41
4
31
42
10
11
8
19
31
24
4
5
28
8
4
32
4
22
19
8
12
8
10
10
5
4
4
6
7
9
45
1
3
46
49
4
44
43
40
15
48
47
33
4
4
14
2
13
Top Cover
Cover Section
KLD-1202
2-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
1
2
90172-00J040
WASHER, EXTL, TOOTHED
4
3
90990-11J005
SCREW, PAN HEAD W/W
1
4
90990-12J001
SCREW, BIN. HEAD W/W
94
5
90990-12J006
SCREW, BIN. HEAD W/W
4
6
90990-41J138
COLLAR
4
7
90990-46J006
BOLT, THIN HEAD
6
8
91312-04008
BOLT HEX,SOCKET HEAD
48
9
91312-05010
BOLT HEX,SOCKET HEAD
4
10
92902-04200
WASHER,PLAIN
48
11
98902-03005
SCREW BINDING HEAD
4
12
98902-03008
SCREW BINDING HEAD
3
13
98902-04010
SCREW BINDING HEAD
4
14
KH1-M1396-00
WASHER
4
15
KH1-M13A9-00
BUSH
1
16
KHU-M1117-00
PULL
1
17
KHY-M1318-00
BRACKET R,COVER18
1
18
KHY-M1319-00
BRACKET L,COVER18
1
19
KKJ-M1317-00
BRACKET,COVER 16
3
20
KLD-M1301-00
COVER 1
1
21
KLD-M1302-00
COVER 2
1
22
KLD-M1303-00
COVER 3
1
23
KLD-M1304-00
COVER 4
1
24
KLD-M1306-00
COVER 6
1
25
KLD-M130B-00
COVER 6-1
1
26
KLD-M1316-00
COVER 16
2
27
KLD-M1317-00
BRACKET,COVER 16
1
28
KLD-M1329-00
COVER 29
1
29
KLD-M1331-00
BRKT. 31,SIDE COVER
2
30
KLD-M1356-00
PLATE 1,JOINT
2
31
KLD-M1358-00
PLATE 3,JOINT
2
32
KLD-M1379-00
COVER BACK 2
1
33
KLD-M1382-00
COVER 1-2
1
34
KLD-M1385-00
BRKT., COVER BACK 3
2
35
KLD-M138A-00
COVER BACK 3
1
36
KLD-M13A3-00
COVER 3-1
1
37
KLD-M13A5-00
COVER A5
1
38
KLD-M13A6-00
COVER A6
1
39
KLD-M13A7-00
COVER A7
1
40
KLD-M13M1-00
PLATE M1
1
41
KM0-M1332-01
BRACKET,MAGNET
2
42
KV5-M1130-00
CATCH MG.
2
43
KLD-M1309-A0
COVER 9 ASSY
1
44
90K41-000380
LABEL,ALERT
1
45
90K41-001090
LABEL,ALERT
1
46
90990-23J023
GROMMET
1
47
KGA-M1392-00
PLUG
1
48
KGA-M1318-00
COVER 18
1
49
90K41-000350
LABEL,ALERT
1
