YSC1_pl.pdf - 第14页
13 15 20 37 25 18 38 9 3 39 12 40 21 35 17 37 39 24 7 36 9 29 36 9 26 6 7 14 22 7 27 6 4 19 16 1 23 9 33 43 41 11 42 5 30 8 10 34 32 14 2 28 31 34 Camera Z axis Head Section KLD-1202 4-1 NO Parts_No. Parts_Name Q_ty Rema…
14
5
18
5
19
13
19
19
13
12
16
3
7
15
1
4
7
9
6
9
6
11
9
6
9
10
8
6
2
17
Y Axis Guide
Y Axis Section
KLD-1202
3-7
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
91312-06010
BOLT HEX,SOCKET HEAD
3
2
91312-06018
BOLT HEX,SOCKET HEAD
4
3
91312-04008
BOLT HEX,SOCKET HEAD
2
4
91312-05008
BOLT HEX,SOCKET HEAD
3
5
91312-05010
BOLT HEX,SOCKET HEAD
6
6
91312-05014
BOLT HEX,SOCKET HEAD
16
7
91312-05016
BOLT HEX,SOCKET HEAD
39
8
KGS-M2256-00
GRIP
1
9
KHN-M22F5-00
WASHER,SWR05
16
10
KHN-M22F6-00
WASHER,SWR06
4
11
KHY-M2666-00
HOLDER,NUT Y AXIS
1
12
KHY-M2682-00
DOG,ORIGIN
1
13
KHY-M2683-00
DOG,SECOND LIMIT
2
14
KHY-M2691-00
BRACKET,SENSOR
1
15
KHY-M26C2-01
COVER1,BALL SCREW
1
16
KHY-M26C4-00
COVER3,BALL SCREW
1
17
KV7-M7165-00
SEAL DON'T TOUCH
1
18
KV7-M2676-S2
Y-AXIS GUIDE SET
1
19
92902-05600
WASHER,PLAIN
6
13
15
20
37
25
18
38
9
3
39
12
40
21
35
17
37
39
24
7
36
9
29
36
9
26
6
7
14
22
7
27
6
4
19
16
1
23
9
33
43
41
11
42
5
30
8
10
34
32
14
2
28
31
34
Camera Z axis
Head Section
KLD-1202
4-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
1
2
90562-13J120
SPACER
2
3
90933-02J605
BEARING
1
4
90990-12J006
SCREW, BIN. HEAD W/W
1
5
90K24-034717
AC SERVO MOTOR
1
6
91312-03008
BOLT HEX,SOCKET HEAD
10
7
91312-03010
BOLT HEX,SOCKET HEAD
8
8
91312-03012
BOLT HEX,SOCKET HEAD
4
9
91312-03020
BOLT HEX,SOCKET HEAD
14
10
91312-04006
BOLT HEX,SOCKET HEAD
2
11
91312-05006
BOLT HEX,SOCKET HEAD
2
12
91312-05016
BOLT HEX,SOCKET HEAD
4
13
91312-05020
BOLT HEX,SOCKET HEAD
2
14
92012-04006
BOLT, BOTTON HEAD
6
15
92902-05200
WASHER,PLAIN
2
16
KHN-M712A-00
BEARING
1
17
KJX-M7106-10
DAMPER LOW
1
18
KJX-M711P-00
CIRCLIP 5
1
19
KJX-M712G-00
PLATE BRG.
1
20
KLD-M7102-00
PLATE HEAD
1
21
KLD-M7103-00
LM GUIDE
1
22
KLD-M7106-00
DAMPER
1
23
KLD-M7110-00
HOLDER Z
1
24
KLD-M7112-00
HOLDER NUT
1
25
KLD-M711N-00
HOLDER BRG
1
26
KLD-M7121-00
BALL SCREW
1
27
KLD-M713P-10
SPRING RETURN
1
28
KLD-M713R-00
SHEET,RUBBER
1
29
KLD-M7152-01
BRKT,SPRING CZ
1
30
KLD-M7156-00
BRKT,SENSOR STAY
1
31
KLD-M7158-00
BRKT,HNS.SUB
1
32
KLD-M7159-10
BRKT,HNS 2
1
33
KLD-M71H9-00
COUPLING
1
34
98902-03006
SCREW BINDING HEAD
4
35
99480-03008
PIN,PARALLEL
2
36
99480-04008
PIN,PARALLEL
2
37
99480-04010
PIN,PARALLEL
6
38
99480-06012
PIN,PARALLEL
2
39
90440-01J030
CIRCLIP
2
40
KLD-M7174-00
PIN,SPRING
1
41
KLD-M7171-00
BRKT,SPG Z
1
42
91312-05008
BOLT HEX,SOCKET HEAD
1
43
91312-04008
BOLT HEX,SOCKET HEAD
1
20
5
18
3
4
8
21
28
11
8
6
13
12
7
1
25
25
1
24
19
16
15
2
22
27
17
9
10
14
23
19
Camera
Head Section
KLD-1202
4-2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
3
2
90562-13J120
SPACER
2
3
90990-01J020
BOLT HEX,SOCKET HEAD
4
4
KHN-M7600-00
FIDUCIAL LIGHT ASSY
1
5
91312-03014
BOLT HEX,SOCKET HEAD
4
6
KJX-M71H7-00
BRACKET,FID.LIGHT
1
7
KJX-M7210-00
CCD CAMERA
1
8
91312-03020
BOLT HEX,SOCKET HEAD
4
9
91312-04006
BOLT HEX,SOCKET HEAD
2
10
91312-04008
BOLT HEX,SOCKET HEAD
4
11
91312-04016
BOLT HEX,SOCKET HEAD
4
12
91312-04025
BOLT HEX,SOCKET HEAD
2
13
KJX-M7211-00
LENS FID.
1
14
KLD-M66N5-10
HNS,CZ-FLEX FID(2V)
1
15
KLD-M713R-00
SHEET,RUBBER
1
16
KLD-M7158-00
BRKT,HNS.SUB
1
17
KLD-M7161-00
BRKT, HNS 3
1
18
KLD-M7181-00
MULTI MACS
1
19
98902-03006
SCREW BINDING HEAD
4
20
KLD-M71H2-00
BRKT,CCD CAMERA
1
21
KLD-M71H3-00
HOLDER,CCD CAMERA
1
22
KLD-M71HB-00
BRKT. CABLE
1
23
KV7-M7165-00
SEAL DON'T TOUCH
1
24
97602-03306
SCREW PAN HEAD W/WASHER
2
25
97602-04306
SCREW PAN HEAD W/WASHER
3
27
99480-04008
PIN,PARALLEL
2
28
99480-04012
PIN,PARALLEL
4
