13 24 13 18 13 11 12 6 28 22 27 10 26 12 21 13 2 13 25 5 15 16 20 19 30 9 23 8 4 1 14 7 17 3 29 Ejector Head Section KLD-1202 4-5 NO Parts_No. Parts_Name Q_ty Remarks Compati Revision_No._date 1 $KM-05 MUFFLER 1 2 $SL8-0…
41
6
19
32
31
10
1
28
18
29
8
27
15
30
21
13
11
20
5
17
16
34
7
10
37,38
12
4
12
22
2
9
33
35
3
25
9
40
13
36
14
39
23.24
26
R1,R2 Axis
Head Section
KLD-1107
4-4
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KLD-M7AB0-00
SHAFT NOZZLE ASSY.
1
2
KLD-M713K-00
GEAR,MOTOR R
1
3
90152-03J03
SCREW SET
1
4
KLD-M7AF0-00
PULLEY R ASSY.
1
5
90185-01J000
NUT, U
1
6
KV7-M81D0-00
NOZZLE ARM ASSY.
2
7
KLD-M713J-00
PULLEY,SHAFT R
1
8
90933-01J804
BEARING
1
9
90933-03J688
BEARING
2
10
90990-19J024
NEEDLE PIN
2
11
90990-26J011
BEARING
1
12
90152-04J06
SCREW SET
4
13
91312-03012
BOLT HEX,SOCKET HEAD
8
14
91312-04008
BOLT HEX,SOCKET HEAD
2
15
91312-04010
BOLT HEX,SOCKET HEAD
2
16
91312-04025
BOLT HEX,SOCKET HEAD
2
17
91312-04040
BOLT HEX,SOCKET HEAD
4
18
91317-03008
BOLT HEX,SOCKET HEAD
4
19
KV7-M8171-00
PLATE,SPRING
2
20
92902-04200
WASHER,PLAIN
2
21
92902-04600
WASHER,PLAIN
4
22
KGR-M7176-00
BELT,N AXIS
1
23
KLD-M4880-00
AC SERVO MOTOR ASSY
1
R1 AXIS
24
KLD-M4880-10
AC SERVO MOTOR ASSY
1
R2 AXIS
25
90990-42J018
JOINT
1
26
KLD-M713C-00
BRKT,MOTOR R
1
27
KLD-M713E-00
HOUSING,SHAFT
1
28
KLD-M713F-00
SHAFT,MAIN
1
29
KLD-M713G-00
PLATE,BRG
1
30
KLD-M713H-00
STAY,R AXIS
1
31
90115-02J006
BOLT, HEX. SOCKET HEAD
2
32
90990-28J002
WASHER,PLAIN
2
33
KLD-M713L-00
GEAR,STOPER R
1
34
KLD-M713M-00
CANTILEVER PIN
1
35
KLD-M713N-00
COLLAR,DOG
1
36
KLD-M7154-00
BRKT,SENSOR
1
37
KLD-M654H-00
SENSOR R-ORG ASSY
1
R1 AXIS
38
KLD-M654H-10
SENSOR R-ORG ASSY
1
R2 AXIS
39
98502-03005
SCREW PAN HEAD
2
40
99009-08400
CIRCLIP
1
41
91317-03012
BOLT HEX,SOCKET HEAD
4
13
24
13
18
13
11
12
6
28
22
27
10
26
12
21
13
2
13
25
5
15
16
20
19
30
9
23
8
4
1
14
7
17
3
29
Ejector
Head Section
KLD-1202
4-5
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$KM-05
MUFFLER
1
2
$SL8-01
JOINT
1
3
$TL4-M5
JOINT
1
4
$TL6-M5M
JOINT
1
5
$TS4-M5
JOINT
2
6
$UT4M
JOINT
2
7
$USD8-6
JOINT
1
8
$UYD10-8
JOINT
1
9
$UY4
JOINT
1
10
90200-10J030
O-RING
2
11
90562-13J100
SPACER
2
12
91312-03006
BOLT HEX,SOCKET HEAD
4
13
91312-04006
BOLT HEX,SOCKET HEAD
10
14
91312-04030
BOLT HEX,SOCKET HEAD
2
15
K40-M8598-00
PLUG 1
1
16
KGA-M7111-H0
VALVE
2
17
KGS-M7176-00
VALVE
1
KW6-M711J-00(Spare)
18
KJH-M7111-A0
EJECTOR
2
19
KJH-M7111-G0
VALVE
2
20
KJH-M71G4-00
BIT
2
21
KLD-M7157-10
BRKT,HNS.
1
22
KLD-M7166-00
STAY,VACUUM SENSOR
1
23
KLD-M7166-10
BKT.VALVE
1
24
KLD-M7167-00
BKT.CAMERA CABLE
1
25
KLD-M7182-00
EJECTER
1
26
KM1-M4592-13
VAC SENSOR BOARD ASSY
2
27
KV7-M8167-00
JOINT,VACUUM SENSOR
2
28
95302-05600
NUT HEXAGON
2
29
91312-03016
BOLT HEX,SOCKET HEAD
2
30
$TL4-M3M
JOINT
2
