YSC1_pl.pdf - 第20页
27 7 25 29 31 51 10 41 5 7 1 22 26 50 46 45 8 8 6 34 28 8 8 12 35 8 16 12 24 33 46 7 8 47 11 48 15 40 32 13 43 42 14 17 3 3 36 11 7 44 18 9 2 4 47 39 11 21 49 23 20 19 2 52 13 8>53 30 11 11 38 11 37 7 Push up assy Con…
27
7
25
29
31
51
10
41
5
7
1
22
26
50
46
45
8
8
6
34
28
8
8
12
35
8
16
12
24
33
46
7
8
47
11
48
15
40
32
13
43
42
14
17
3
3
36
11
7
44
18
9
2
4
47
39
11
21
49
23
20
19
2
52
13
8>53
30
11
11
38
11
37
7
Push up assy
Conveyor Section
KLD-1202
6-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90440-01J090
CIRCLIP
2
2
90933-01J001
BEARING
2
3
90933-01J007
BEARING
4
4
90933-01J300
BEARING
2
5
90990-28J079
WASHER,PLAIN
1
6
91312-03005
BOLT HEX,SOCKET HEAD
2
7
91312-04006
BOLT HEX,SOCKET HEAD
18
8
91312-04010
BOLT HEX,SOCKET HEAD
20
9
91312-04020
BOLT HEX,SOCKET HEAD
1
10
91312-04030
BOLT HEX,SOCKET HEAD
8
11
91312-05010
BOLT HEX,SOCKET HEAD
18
12
91312-05016
BOLT HEX,SOCKET HEAD
8
13
91312-05020
BOLT HEX,SOCKET HEAD
9
14
91312-05025
BOLT HEX,SOCKET HEAD
8
15
91312-08025
BOLT HEX,SOCKET HEAD
4
16
KGA-M921T-00
BOLT
4
17
KLD-M9B00-00
BALL SCREW PU
2
18
90KA0-131512
AC SERVO MOTOR
1
19
KHW-M9215-00
PULLEY:P60-3GT
2
20
KHW-M921B-00
STAY,ADJUST
1
21
KHW-M921C-00
SHAFT 1
1
22
KHW-M921K-00
BRKT.,SENSOR
1
23
KHW-M9223-00
PULLEY:P40-3GT
1
24
KHY-M921G-01
BRKT.,DOG
1
25
KHY-M921M-01
WASHER
2
26
KLD-M9217-00
BALL BUSH & SHAFT
2
27
KLD-M921A-00
PLATE A
1
28
KLD-M921B-00
PLATE B
1
29
KLD-M921C-00
BRKT.,MOTOR
1
30
KLD-M921D-00
BRKT.,TENSIONER
1
31
KLD-M921E-00
BELT 291-3GT-15
1
31-1
KKE-M921D-00
BELT 291-3GT-15
1
OK
MH70040-2011/7/15
32
KLD-M921F-00
BELT 693-3GT-15
1
33
KLD-M921G-00
PLATE,DOG
1
34
KLD-M921H-00
JOINT H
2
35
KLD-M921J-00
DAMPER
2
36
KLD-M921K-00
POST
1
37
KLD-M921L-00
COVER,PU MOTOR
1
38
KLD-M921M-00
PULLEY 1:P36-3GT
1
39
KLD-M921N-00
PLATE N
1
40
KLD-M921R-00
PLATE R
1
41
KLD-M921S-00
SPACER BUSH
2
42
KLD-M921T-00
HOLDER,BRG.
2
43
KLD-M921U-00
HOLDER,BRG. 2
2
44
KLD-M921V-00
PLATE V
2
45
KHY-M652E-00
SENSOR,PUORG
1
46
92902-04200
WASHER,PLAIN
4
47
92902-05200
WASHER,PLAIN
6
48
92902-08200
WASHER,PLAIN
4
49
95302-04600
NUT HEXAGON
1
50
95602-10100
NUT, U
4
51
99009-10400
CIRCLIP
1
52
99009-12400
CIRCLIP
1
53
91312-04012
BOLT HEX,SOCKET HEAD
8
OK
MH70101-2011/7/29
4
15
24
14
7
8
1
13
7
25
3
2
11
9
1
4
1
5
17
12
15
6
3
7
2
9
1
22
15
3
2
21
18
16-->26
26
19
20
1
18
4
5
12
10
16-->27
19
23
22
13
4
15
24
14
7
8
1
13
7
25
3
2
11
9
1
4
1
5
17
12
15
6
3
7
2
9
1
22
15
3
2
21
18
16-->26
26
19
20
1
18
4
5
12
10
16-->27
19
23
22
13
Stopper / Sensor / Plate-Edge / Push-Up Pin
Conveyor Section
KLM-1206
7-2
[ Left-Entry case ]
[ Right-Entry case ]
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
91312-04010
BOLT HEX,SOCKET HEAD
10
2
91312-05010
BOLT HEX,SOCKET HEAD
6
3
91312-05012
BOLT HEX,SOCKET HEAD
6
4
92902-04200
WASHER,PLAIN
6
5
97602-03310
SCREW PAN HEAD W/WASHER
4
6
KHY-M9238-A0
CYLINDER,SUB.ASSY.
1
7
KHW-M9274-A0
SPEED CONTROLLER
6
8
KHW-M9272-00
STOPPER,EXIT
1
9
KHW-M9282-00
STOPPER,SUB
2
10
KHY-M652J-00
SENSOR,ENT ASSY
1
11
KHY-M652M-00
SENSOR,EXT ASSY
1
12
KHY-M912A-01
BRKT.,SENSOR
2
13
KHY-M9271-00
PLATE,STOPPER
1
14
KHY-M9273-00
CYLINDER
1
15
KHY-M9284-00
PLATE,STOPPER
3
16
KLD-M652L-00
SENSOR,POS.1 ASSY
1
With sub stopper
16-1
KLD-M652L-01
SENSOR,POS.1 ASSY
1
With sub stopper
OK
MJ50137-2012/6/18
16-2
KLD-M652N-01
SENSOR,POS.1 ASSY
1
Common 26-1
ML30038-2014/3/25
17
KLD-M9161-01
BRKT.,CYLINDER
1
18
98702-03005
SCREW,FLAT HEAD
12
19
98502-03004
SCREW PAN HEAD
4
20
KHY-M9135-00
PLATE,EDGE 2
5
21
KHY-M9135-10
PLATE,EDGE 3
1
22
KLD-M9161-10
BRKT.,CYLINDER
1
23
KLD-M9181-00
BRKT.,CYLINDER
1
24
KGT-M920D-01
PUSH UP PIN UNIT
1
25
KHY-M9166-A0
CYLINDER,MAIN ASSY.
1
26
KLD-M652N-00
SENSOR,POS.1 ASSY
1
No sub stopper
26-1
KLD-M652N-01
SENSOR,POS.1 ASSY
1
No sub stopper
OK
MJ50137-2012/6/18
26-2
KLD-M652N-02
SENSOR,POS.1 ASSY
1
Common
NG
MTX0051-2020/12/7
27
KLD-M652K-00
SENSOR,WAIT ASSY
1
With sub stopper
ML30038-2014/3/25
27-1
KLD-M652K-01
SENSOR,WAIT SET
1
With sub stopper
NG
MTX0051-2020/12/7
