YSC1_pl.pdf - 第19页
5 4 3 6 7 2 1 Nozzle Nozzle Section KLD-1202 5-1 NO Parts_No. Parts_Name Q_ty Remarks Compati Revision_No._date 1 KV7-M7730-00 NOZZLE 63A 1 2 KV7-M7741-00 BODY ,NOZZLE 64A 1 3 90990-17J013 O-RING 1 4 KV7-M7751-00 BODY ,N…
13
24
13
18
13
11
12
6
28
22
27
10
26
12
21
13
2
13
25
5
15
16
20
19
30
9
23
8
4
1
14
7
17
3
29
Ejector
Head Section
KLD-1202
4-5
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$KM-05
MUFFLER
1
2
$SL8-01
JOINT
1
3
$TL4-M5
JOINT
1
4
$TL6-M5M
JOINT
1
5
$TS4-M5
JOINT
2
6
$UT4M
JOINT
2
7
$USD8-6
JOINT
1
8
$UYD10-8
JOINT
1
9
$UY4
JOINT
1
10
90200-10J030
O-RING
2
11
90562-13J100
SPACER
2
12
91312-03006
BOLT HEX,SOCKET HEAD
4
13
91312-04006
BOLT HEX,SOCKET HEAD
10
14
91312-04030
BOLT HEX,SOCKET HEAD
2
15
K40-M8598-00
PLUG 1
1
16
KGA-M7111-H0
VALVE
2
17
KGS-M7176-00
VALVE
1
KW6-M711J-00(Spare)
18
KJH-M7111-A0
EJECTOR
2
19
KJH-M7111-G0
VALVE
2
20
KJH-M71G4-00
BIT
2
21
KLD-M7157-10
BRKT,HNS.
1
22
KLD-M7166-00
STAY,VACUUM SENSOR
1
23
KLD-M7166-10
BKT.VALVE
1
24
KLD-M7167-00
BKT.CAMERA CABLE
1
25
KLD-M7182-00
EJECTER
1
26
KM1-M4592-13
VAC SENSOR BOARD ASSY
2
27
KV7-M8167-00
JOINT,VACUUM SENSOR
2
28
95302-05600
NUT HEXAGON
2
29
91312-03016
BOLT HEX,SOCKET HEAD
2
30
$TL4-M3M
JOINT
2
27
7
25
29
31
51
10
41
5
7
1
22
26
50
46
45
8
8
6
34
28
8
8
12
35
8
16
12
24
33
46
7
8
47
11
48
15
40
32
13
43
42
14
17
3
3
36
11
7
44
18
9
2
4
47
39
11
21
49
23
20
19
2
52
13
8>53
30
11
11
38
11
37
7
Push up assy
Conveyor Section
KLD-1202
6-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90440-01J090
CIRCLIP
2
2
90933-01J001
BEARING
2
3
90933-01J007
BEARING
4
4
90933-01J300
BEARING
2
5
90990-28J079
WASHER,PLAIN
1
6
91312-03005
BOLT HEX,SOCKET HEAD
2
7
91312-04006
BOLT HEX,SOCKET HEAD
18
8
91312-04010
BOLT HEX,SOCKET HEAD
20
9
91312-04020
BOLT HEX,SOCKET HEAD
1
10
91312-04030
BOLT HEX,SOCKET HEAD
8
11
91312-05010
BOLT HEX,SOCKET HEAD
18
12
91312-05016
BOLT HEX,SOCKET HEAD
8
13
91312-05020
BOLT HEX,SOCKET HEAD
9
14
91312-05025
BOLT HEX,SOCKET HEAD
8
15
91312-08025
BOLT HEX,SOCKET HEAD
4
16
KGA-M921T-00
BOLT
4
17
KLD-M9B00-00
BALL SCREW PU
2
18
90KA0-131512
AC SERVO MOTOR
1
19
KHW-M9215-00
PULLEY:P60-3GT
2
20
KHW-M921B-00
STAY,ADJUST
1
21
KHW-M921C-00
SHAFT 1
1
22
KHW-M921K-00
BRKT.,SENSOR
1
23
KHW-M9223-00
PULLEY:P40-3GT
1
24
KHY-M921G-01
BRKT.,DOG
1
25
KHY-M921M-01
WASHER
2
26
KLD-M9217-00
BALL BUSH & SHAFT
2
27
KLD-M921A-00
PLATE A
1
28
KLD-M921B-00
PLATE B
1
29
KLD-M921C-00
BRKT.,MOTOR
1
30
KLD-M921D-00
BRKT.,TENSIONER
1
31
KLD-M921E-00
BELT 291-3GT-15
1
31-1
KKE-M921D-00
BELT 291-3GT-15
1
OK
MH70040-2011/7/15
32
KLD-M921F-00
BELT 693-3GT-15
1
33
KLD-M921G-00
PLATE,DOG
1
34
KLD-M921H-00
JOINT H
2
35
KLD-M921J-00
DAMPER
2
36
KLD-M921K-00
POST
1
37
KLD-M921L-00
COVER,PU MOTOR
1
38
KLD-M921M-00
PULLEY 1:P36-3GT
1
39
KLD-M921N-00
PLATE N
1
40
KLD-M921R-00
PLATE R
1
41
KLD-M921S-00
SPACER BUSH
2
42
KLD-M921T-00
HOLDER,BRG.
2
43
KLD-M921U-00
HOLDER,BRG. 2
2
44
KLD-M921V-00
PLATE V
2
45
KHY-M652E-00
SENSOR,PUORG
1
46
92902-04200
WASHER,PLAIN
4
47
92902-05200
WASHER,PLAIN
6
48
92902-08200
WASHER,PLAIN
4
49
95302-04600
NUT HEXAGON
1
50
95602-10100
NUT, U
4
51
99009-10400
CIRCLIP
1
52
99009-12400
CIRCLIP
1
53
91312-04012
BOLT HEX,SOCKET HEAD
8
OK
MH70101-2011/7/29
