This manual describes installation of the "Input and Output Conveyor Extension incl. Hand Guard" in the

SIPLACE® X series S machines.

1.1

1.1 Safety Instructions

Safety Instructions

1.1.1

1.1.1 Conventions for the use of safety instructions

Conventions for the use of safety instructions

This manual contains notes that must be observed to guarantee your personal safety and to avoid dam-

age to equipment. These notes are highlighted by warning triangles and are indicated as follows accord-

ing to the level of risk:

DANGER

Nonobservance of these safety instructions may cause injury to personnel and damage to the

machine!

► Please observe the safety instructions in the user manual of the relevant machine for all

work!

DANGER

Definition

For the purposes of this manual, this indicates that fatal or severe injuries or considerable dam-

age to property will occur if this hazard warning is not observed.

WARNING

Definition

For the purposes of this manual, this indicates that fatal or severe injuries or considerable dam-

age to equipment may occur if these warning instructions are not followed.

CAUTION

Definition

For the purposes of this manual, this indicates that minor injuries or damage to property may

occur if this caution is not observed.

NOTICE

Definition

For the purposes of this manual, this note provides information about the product or indicates

a part of the manual that requires particular attention.

Introduction

Safety Instructions 1.1.2 Safety Instructions for Working with Strong Magnetic Fields

44 Extension Input/Output Conveyor and Hand Guard Ein-/

1.1.2

1.1.2 Safety Instructions for Working with Strong Magnetic Fields

Safety Instructions for Working with Strong Magnetic Fields

1.1.3

1.1.3 Safety Instructions for the Power Supply

Safety Instructions for the Power Supply

▪ This means that some parts of the system carry potentially lethal voltages - even when switched off

at the main power switch.

▪ Incorrect handling of the placement system can therefore result in fatal injuries, severe injuries or

considerable damage to equipment.

▪ Measurements and maintenance work must always be carried out by appropriately qualified person-

nel.

▪ Always follow the applicable accident prevention and DIN regulations (particularly DIN EN 60 204,

part 1) or the regulations specific to your country.

▪ Before starting any maintenance work, switch the machine off at the main switch and disconnect it

from the main power supply.

▪ Always secure the machine against unauthorized reactivation. If these instructions are not followed,

you may be able to touch live parts, which could result in fatal or severe injuries.

Maintaining or Replacing Assemblies

► End all placement operations on the machine.

► Shut down the Windows operating system correctly, otherwise problems may occur when restarting

or data may be lost.

► Switch the machine off at the main switch.

► Disconnect the machine from the main power supply.

► Switch off the machine and attach warnings signs to indicate that service work is in progress.

DANGER

Strong permanent magnet fields

Fatal hazard: persons with active implants (e.g. pacemakers, defibrillators, insulin pumps etc.)

are at risk from strong permanent magnetic fields inside the machine.

Persons at risk should avoid the immediate vicinity of the machine.

CAUTION

Danger of crushing

Danger of crushing for persons with passive metal implants (e.g. plates, screws).

► Do not reach or lean over into the machine when the protective covers are open.

► Do not bring any metal objects into the hazard area.

CAUTION

Strong permanent magnet fields

There is a risk that the strong magnetic fields could corrupt data on data media or check cards.

► Keep sensitive data supports away from the permanent magnets.

WARNING

Hazardous Voltages!

The machine is supplied with 3 x 400 V~ (or. 3 x 204 V~ / 3 x 220 V~ / 3 x 230 V~ / 3 x 380 V~

/ 3 x 415 V~) ± 5 %, 50/60 Hz mains voltages.

► Observe the safety instructions in the user manual during all service work!
