CM212-M.pdf - 第148页
4-A 軽量多機能 ヘ ッ ド Light W eight Multi-Functional Head パーツレイアウト Kit No. キット品 番 Kit N am e キット名称 KXFX03Y JA00 ｾｸｼｮﾝN o. PARTS LAYOUT Section No. - - S15 ( KKXFX03YJA00-56-1 )
Ref
No.
Remarks
R
1
Q't
y
3
ノズルチェンジャ(8ノズルヘッド):CM212-M
Nozzle Changer (8 Nozzle Head): CM212-M
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット品
番
Kit Name
キット名称
N610073596AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
SHUTTER
1
1 N210023876AB
HOLDER
1
2 N210023877AB
HOLDER
1
3 N210090974AC
BRACKET
1
4 N210046289AC
PIN
4
5 N210023891AC
COVER
1
6 N210095370AA
WASHER
4
7 N210088594AA
SHEET
1
8 N210088595AB
COLLAR
2
9 N210096662AA
BRACKET
1
10 N210090969AB
WASHER
1
11 N510037258AA 87FWSSB-D13.0-V6.0-T3.0
SPEED-CONTROLLER
2
12 KXF00YMAA00 AS1201F-M5-04
FLOATING-JOINT
1
13 N510031110AA 87FJT4-0.7-3
SPACER
4
14 N510019650AA MMSRB4.5-0.5
POST
2
15 N510041406AA LSBWRKT12-163
VALVE
1
16 KXF0A3RAA00 VQZ1220-5MO-C4
SILENCER
2
17 KXF00WCAA00 AN120-M5
JOINT
1
18 KXF02C3AA00 KQL06-M5
PIN
2
19 N510020597AA MMS4-8
POST
1
20 N510041407AA LSBCT12-173.5
PIN
1
21 N510025080AA 87STMH6
BOLT
8
22 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
3
23 N510017432AA
Hexagon socket head cap screw M6X15-10.9 A2J (Trivalent)
WASHER
2
24 N510018501AA
Round finish plain washer 6 10H A2J (Trivalent)
NUT
4
25 N510017849AA
Hexagon nut Type-1 Best class M3-6H-4T A2J (Trivalent)
WASHER
1
26 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
BOLT
4
27 N510017313AA
Hexagon socket head cap screw M3X16-10.9 A2J (Trivalent)
WASHER
2
28 N510018479AA
Small round-plain washer 4 10H A2J (Trivalent)
WASHER
2
29 N510018478AA
Small round-plain washer 3 10H A2J (Trivalent)
WASHER
4
30 N510018494AA
Round finish plain washer 3 10H A2J (Trivalent)
STOPPER-BOLT
2
31 KXF0CVEAA00 UNAH3-15(DA KXF0CVEAA00)
CYLINDER
1
33 N610029483AB
S14
4-A
軽量多機能
ヘ
ッ
ド
Light Weight Multi-Functional Head
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
KXFX03YJA00
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S15
( KKXFX03YJA00-56-1 )
Ref
No.
Remarks
R
1
Q'ty
4-A
軽量多機能
ヘ
ッ
ド
Light Weight Multi-Functional Head
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
KXFX03YJA00
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
PLATE
3
1 N210042809AA
HOUSING
3
2 N210016067AC
POST
9
3 KXFB0AU3A00
COUPLING
3
4KXFB0HBTA00
BRACKET
3
5 N210010130AF
PLATE
3
6 N210026983AA
STOPPER
6
7 N210016069AA
PLATE
3
8 N210026982AA
MOTOR
3
9 N510042740AA P50BA2002BXS3C
SCREW
3
10 N510018279AA
Cross recessed Truss head machine screw M4X6-4.8 A2J (Trivalent)
BOLT
6
11 N510017247AA
Hexagon socket head cap screw M2.5X8-10.9 A2J (Trivalent)
GROMMET
3
12 KXF0CUVAA00 G-68
PH-SENSOR
3
13 KXF0E1KUA00 PM-Y44(DA KXF0E1KUA00)
JOINT
3
14 N510066663AA KQ2L04-M6A
GREASE-NIPPLE
3
15 N510021518AA NGA-610S
SPACER
3
16 N510017047AA ASB-3100E
SPACER
3
17 N510063090AA CL-301.5BE
STEEL-BALL
3
18 KXF05PSAA00 3.5
SPACER
3
19 N510017073AA ASF-610E
SPACER
12
20 N510063089AA ASL-325BE
SPACER
9
21 N510063091AA CL-302BE
HEAD No.1
1
22 N610065885AA
HEAD No.2
1
23 N610065886AA
HEAD No.3
1
24 N610065887AA
S16
--
( KKXFX03YJA00-56-1 )
