Ref No. Remark s R 1 Q'ty 2-C X 軸 ユニ ッ ト X-Axi s Un it ｲﾗｽﾄ No. Part No. 品 名 品番 数量 R 2 パーツリスト Kit N o . キット 品 番 Kit Name キット名称 N610012218AA Part Nam e 備 考 ｾｸｼｮﾝN o. PARTS LIST Section No. R 3 SHEET 1 9 N210068092AA …
2-C
X
軸
ユニ
ッ
ト
X-Axis Unit
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610012218AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M23
( KN610012218AA-16-3 )
Ref
No.
Remarks
R
1
Q'ty
2-C
X
軸
ユニ
ッ
ト
X-Axis Unit
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610012218AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
SHEET
1
9 N210068092AA
BRACKET
1
13 N210029088AB
BRACKET
1
16 N210009911AA
JOINT
1
43 KXF02DNAA00 KQU06-00
JOINT
5
49 KXF0CSCAA00 KQ2E04-01
CABLE-BEAR
1
50 N510009577AA 25.3-055BB-11-23B
VALVE
1
51 KXF0A1RAA00 VQZ115R-5MO-M5-PR
JOINT
4
52 KXF02C3AA00 KQL06-M5
JOINT
1
53 KXF0CSDAA00 KK3S-06L
JOINT
1
54 KXF0CSEAA00 KK4S-10L
PULL
1
55 KXF00RAAA00 A-1075-7
GREASE-NIPPLE
5
56 KXF0CSHAA00 GPB1
WASHER
1
57 KXF0CXGAA00 WTAB12-4-5
SCREW
1
58 N510018282AA
Cross recessed Truss head machine screw M4X8-4.8 A2J (Trivalent)
SPACER
2
59 N510014379AA CB-325E
BOLT
2
60 N510017329AA
Hexagon socket head cap screw M3X40-10.9 A2J (Trivalent)
JOINT
1
61 KXF0CVQAA00 KK3S-06E
CLIP
1
63 KXF031SAA00 NK-3N
BOLT
2
66 N510017554AA
Hexagon socket button head screw M6X10-10.9 A2J (Trivalent)
BOLT
2
67 N510017557AA
Hexagon socket button head screw M6X16-10.9 A2J (Trivalent)
BOLT
2
69 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
3
72 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
1
75 N510017354AA
Hexagon socket head cap screw M4X20-10.9 A2J (Trivalent)
BOLT
2
76 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
BOLT
16
78 N510017398AA
Hexagon socket head cap screw M5X20-10.9 A2J (Trivalent)
BOLT
2
79 N510017428AA
Hexagon socket head cap screw M6X12-10.9 A2J (Trivalent)
WASHER
4
83 N510018494AA
Round finish plain washer 3 10H A2J (Trivalent)
WASHER
4
84 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
2
85 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
1
92 N510020099AA Thick washer for M4
WASHER
16
93 N510020100AA Thick washer for M5
WASHER
6
94 N510020101AA Thick washer for M6
WASHER
1
95 N510018330AA Spring lock washer No.2 4 S A2J (Trivalent)
WASHER
4
99 N510024069AA MMSRB8-0.5
M24
--
( KN610012218AA-16-3 )
3-A
X
軸接続
ユニット
X-Axis Connection Unit
パーツレイアウト
Kit No.
キット
品番
Kit Name
キット名称
N610012219AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
M25
