Ref No. Remark s R 1 Q'ty 9-C 一 括 交 換 台車 Feeder Cart ｲﾗｽﾄ No. Part No. 品 名 品番 数量 R 2 パーツリスト Kit N o . キット品 番 Kit Name キット名称 N610012627AA Part Name 備 考 ｾｸｼｮﾝNo. PARTS LIST Section No. R 3 BASE 1 14 N210021946AB PLATE…
9-C
一
括
交
換
台車
Feeder Cart
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610012627AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S37
( KN610012627AA-21-3 )
Ref
No.
Remarks
R
1
Q'ty
9-C
一
括
交
換
台車
Feeder Cart
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610012627AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BASE
1
14 N210021946AB
PLATE
1
15 N210021947AA
PLATE
1
16 N210021948AA
SHAFT
1
17 N210021949AA
COLLAR
21
18 KXFB02EEA00
GUIDE
21
22 N210092715AA
BRACKET
8
46 KXFB02F4A00
COVER
1
49 N210021957AA
COVER
1
50 N210022420AA
COVER
1
51 N210022421AA
COVER
1
56 N210022095AA
PIN
4
101 KXF0CXHAA00 1017003-40008
PIN
2
102 KXF0CXJAA00 1017003-50010
SPACER
8
103 N510016261AA BSF-425E
SPACER
4
105 N510016262AA BSF-480E
PIN
2
106 KXF0CXKAA00 1017003-60012
JOINT
1
108 KXF08GBAA00 KQLE06-00
PIN
42
109 KXF0CXLAA00 1017003-30010
GROMMET
2
110 KXF007TAA00 C-30-SG-32A
WASHER
1
113 XWC4BFN
Toothed lock washer 4 External toothed Steel Nickel plating
BOLT
7
116 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
21
117 N510017316AA
Hexagon socket head cap screw M3X20-10.9 A2J (Trivalent)
BOLT
18
118 N510017376AA
Hexagon socket head cap screw M4X6-10.9 A2J (Trivalent)
BOLT
13
119 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
4
120 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
2
123 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
BOLT
6
125 N510017399AA
Hexagon socket head cap screw M5X25-10.9 A2J (Trivalent)
BOLT
4
128 N510017438AA
Hexagon socket head cap screw M6X30-10.9 A2J (Trivalent)
WASHER
8
132 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
9
136 N510018479AA
Small round-plain washer 4 10H A2J (Trivalent)
WASHER
2
137 N510020100AA Thick washer for M5
WASHER
1
138 N510018330AA Spring lock washer No.2 4 S A2J (Trivalent)
SCREW
1
143 N510018282AA
Cross recessed Truss head machine screw M4X8-4.8 A2J (Trivalent)
BOLT
1
145 N510017305AA
Hexagon socket head cap screw M3X10-10.9 A2J (Trivalent)
WASHER
1
146 N510020098AA Thick washer for M3
GUIDE
1
148 N210029161AA
GUIDE
2
155 KXFB02F5A00
COVER
1
156 KXFB02F6A00
GUIDE
1
157 N210021950AA
COVER
1
158 N210021959AA
BAND
1
162 KXF0290AA00 KCA-34
S38
--
( KN610012627AA-21-3 )
9-D
一
括
交
換
台車
Feeder Cart
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610012627AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S39
( KN610012627AA-21-4 )
