16-A 固 定 フィー ダ Fixed Feeder パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N610024045AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - S61 ( KN610024045AA-19-1 )
Ref
No.
Remarks
R
1
Q't
y
15-B
リア
側
ダイレクトトレイフィーダ対応
Tray Feeder:Rear Side
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット品
番
Kit Name
キット名称
N610013807AB
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BLOCK
1
8 N210037137AB
BLOCK
1
9 KXFB05DRA01
BLOCK
1
10 KXFB05J1A00
PLATE
1
12 N210026451AA
COVER
1
15 KXFB05J2A00
BRACKET
1
16 N210086861AA
COVER
1
17 N210040716AE
COVER
1
18 N210064064AA
CAP
1
28 KXF0DWHXA00 SFA-001
FRAME
1
29 KXF0DYW9A00 SFF-304 L=173
NUT
4
30 KXF0ATGAA00 SFB-002
BRACKET
2
31 KXF0DTWAA00 SFJ-N03
PACKING
1
32 N510016439AA 209-1301
SCREW
6
35 N510018303AA
Cross recessed Truss head machine screw M5X8-4.8 A2S (Trivalent)
BOLT
4
38 N510017495AA
Hexagon socket head cap screw M8X90-10.9 A2J (Trivalent)
BOLT
2
41 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
2
42 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
2
43 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
2
44 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
BOLT
4
46 N510017435AA
Hexagon socket head cap screw M6X20-10.9 A2J (Trivalent)
BOLT
2
47 N510017437AA
Hexagon socket head cap screw M6X25-10.9 A2J (Trivalent)
BOLT
2
48 N510017442AA
Hexagon socket head cap screw M6X40-10.9 A2J (Trivalent)
WASHER
2
51 N510018494AA
Round finish plain washer 3 10H A2J (Trivalent)
WASHER
4
53 N510020099AA Thick washer for M4
WASHER
6
54 N510020100AA Thick washer for M5
WASHER
7
55 N510020101AA Thick washer for M6
WASHER
4
56 N510020102AA Thick washer for M8
PLATE
1
64 N210040914AA
POST
1
67 N510028341AA ETKGT20-250-M10-N10-SC50
POST
1
67 N510021024AA ETKGRF20-250-SC10
TRIM
2
69 N9866208-E28 62-08-B-3-Aluminium
WASHER
2
72 N510018501AA
Round finish plain washer 6 10H A2J (Trivalent)
BOLT
3
92 N510017433AA
Hexagon socket head cap screw M6X16-10.9 A2J (Trivalent)
BRACKET
1
94 N210066224AA
STOPPER
1
95 N210066225AA
S60
16-A
固
定
フィーダ
Fixed Feeder
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610024045AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S61
( KN610024045AA-19-1 )
Ref
No.
Remarks
R
1
Q'ty
16-A
固
定
フィーダ
Fixed Feeder
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610024045AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BASE
1
1 N610030089AC
FILM
5
2 N610056681AB
STOPPER
1
3 N210129516AB
STOPPER
1
4 N210129517AB
GUIDE
21
5 N210092714AA
GUIDE
21
6 N210092715AA
COVER
1
10 N210077260AB
BRACKET
2
11 N210059710AA
BRACKET
1
12 N210064292AA
CHUTE
1
18 N210035437AA
CHUTE
1
19 N210047426AA
PIN
4
20 KXF02YTAA00 MS6-25
PIN
84
21 KXF0CXLAA00 1017003-30010
WASHER
8
28 N210143841AB
PIN
21
29 N510013852AA 1017003-60025
BOLT
42
31 N510017316AA
Hexagon socket head cap screw M3X20-10.9 A2J (Trivalent)
BOLT
6
32 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
3
33 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
BOLT
4
35 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
BOLT
8
36 N510017438AA
Hexagon socket head cap screw M6X30-10.9 A2J (Trivalent)
BOLT
6
37 N510017476AA
Hexagon socket head cap screw M8X35-10.9 A2J (Trivalent)
SCREW
4
39 N510018258AA
Cross recessed Truss head machine screw M4X10-4.8 A2S (Trivalent)
WASHER
4
41 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
4
42 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
7
43 N510020099AA Thick washer for M4
NUT
4
45 N510017855AA
Hexagon nut Type-1 Best class M4-6H-4T A2J (Trivalent)
COVER
1
46 N210051459AA
WASHER
4
47 N510013724AA TM-147-2V
SCREW
4
48 N510018282AA
Cross recessed Truss head machine screw M4X8-4.8 A2J (Trivalent)
POST
1
54 N510017148AA LSBGT13-105-M8-N4
COVER
1
57 N210060009AD
SCREW
2
58 N510018104AA Pan head machine screw Cross recessed M2X4
S62
--
( KN610024045AA-19-1 )
