30 リアカバー (トレイ) REAR COVER(T RAY) パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N610014721AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - S113 ( KN610014721AA-16 )
Ref
No.
Remarks
R
1
Q'ty
29-B
BRカバー (フィーダ)
BR COVER(FEEDER)
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610024212AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
COVER
1
1 N210026338AF
S
COVER
1
13 N210027713AA
BRACKET
1
14 N210027715AA
S
COVER
1
15 N210045669AA
PULL
1
18 KXF0DX62A00 AP-829-2
SCREW
2
26 N510018258AA
Cross recessed Truss head machine screw M4X10-4.8 A2S (Trivalent)
SCREW
12
34 N510018282AA
Cross recessed Truss head machine screw M4X8-4.8 A2J (Trivalent)
BOLT
2
35 N510001804AA SRBS-M4X25
WASHER
8
36 N510011899AA NN-0816-10
SPACER
8
37 N510019916AA CB-503E
SPACER
4
38 N510019894AA ASF-440E
GAS-SPRING
2
39 KXF0E1VCA00
S
KSF90-10M
SCREW
8
40 N510018303AA
Cross recessed Truss head machine screw M5X8-4.8 A2S (Trivalent)
WASHER
4
43 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
6
45 N510020100AA Thick washer for M5
NUT
2
47 N510017855AA
Hexagon nut Type-1 Best class M4-6H-4T A2J (Trivalent)
WASHER
8
51 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
12
53 N510013724AA TM-147-2V
BOLT
2
55 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
COVER
1
57 N210064063AA
BRACKET
1
58 N210064060AA
COVER
1
59 N210043289AA
BOLT
4
61 KXF09KJAA00 MSB10-10
WASHER
8
62 N510018506AA
Round finish plain washer (JIS B 1256:1978) 10 10H A2J (Trivalent)
NUT
2
65 N510017877AA
Hexagon nut Type-1 Best class M8-6H-4T A2J (Trivalent)
BAR
1
67 N210049616AA
STOPPER
1
68 N210049617AB
BRACKET
1
69 N210049615AC
SPACER
2
70 N510020966AA CB-512E
BOLT
8
71 N510017395AA
Hexagon socket head cap screw M5X16-10.9 A2J (Trivalent)
BOLT
2
72 N510017399AA
Hexagon socket head cap screw M5X25-10.9 A2J (Trivalent)
FRAME
1
73 N610049251AD
S
NUT-PLATE
1
74 N210066061AA
PLATE
1
75 N210066062AA
GROMMET
2
76 N510055131AA C-30-RK-10-EP-UL-Black
BOLT
2
77 N510017247AA
Hexagon socket head cap screw M2.5X8-10.9 A2J (Trivalent)
TRIM
2
78 N9866224-B98 62-24-B-5-Aluminium
SCREW
4
79 N510018291AA
Cross recessed Truss head machine screw M5X16-4.8 A2S (Trivalent)
NUT
2
87 N510017840AA
Hexagon nut Type-1 Best class M2.5-6H-4T A2J (Trivalent)
WASHER
2
88 N510018490AA
Round finish plain washer (JIS B 1256:1978) 2.5 10H A2J (Trivalent)
S112
--
( KN610024212AA-17-2 )
30
リアカバー (トレイ)
REAR COVER(TRAY)
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610014721AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S113
( KN610014721AA-16 )
Ref
No.
Remarks
R
1
Q'ty
30
リアカバー (トレイ)
REAR COVER(TRAY)
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610014721AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
COVER
1
1 N210027728AG
S
BRACKET
1
4 N210027716AA
BRACKET
1
5 N210063799AA
PULL
1
6 KXF0DX62A00 AP-829-2
BOLT
2
12 N510001804AA SRBS-M4X25
WASHER
8
13 N510011899AA NN-0816-10
SPACER
8
14 N510019916AA CB-503E
BOLT
2
17 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
WASHER
2
18 N510020100AA Thick washer for M5
WASHER
9
19 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
URETHANE
1
24 N510013788AA AXNHK20-40
SPACER
1
25 KXF09JSAA00 CU-540
GAS-SPRING
2
26 N510013496AA
S
KSF90-15M
SCREW
4
27 N510018303AA
Cross recessed Truss head machine screw M5X8-4.8 A2S (Trivalent)
BOLT
1
28 N510017409AA
Hexagon socket head cap screw M5X50-10.9 A2J (Trivalent)
NUT
1
29 N510017862AA
Hexagon nut Type-1 Best class M5-6H-4T A2J (Trivalent)
COVER
1
30 N210035369AA
SCREW
8
31 N510018282AA
Cross recessed Truss head machine screw M4X8-4.8 A2J (Trivalent)
WASHER
8
32 N510013724AA TM-147-2V
BOLT
6
34 N510017395AA
Hexagon socket head cap screw M5X16-10.9 A2J (Trivalent)
BOLT
4
37 KXF09KJAA00 MSB10-10
WASHER
8
38 N510018506AA
Round finish plain washer (JIS B 1256:1978) 10 10H A2J (Trivalent)
NUT
2
39 N510017877AA
Hexagon nut Type-1 Best class M8-6H-4T A2J (Trivalent)
WASHER
6
40 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
NUT
4
41 N510017855AA
Hexagon nut Type-1 Best class M4-6H-4T A2J (Trivalent)
FRAME
1
42 N610049031AF
S
NUT-PLATE
1
43 N210066061AA
PLATE
1
44 N210066062AA
GROMMET
1
45 N510055131AA C-30-RK-10-EP-UL-Black
BOLT
1
46 N510017247AA
Hexagon socket head cap screw M2.5X8-10.9 A2J (Trivalent)
TRIM
2
47 N9866224-B98 62-24-B-5-Aluminium
SCREW
4
48 N510018291AA
Cross recessed Truss head machine screw M5X16-4.8 A2S (Trivalent)
NUT
1
49 N510017840AA
Hexagon nut Type-1 Best class M2.5-6H-4T A2J (Trivalent)
WASHER
1
50 N510018490AA
Round finish plain washer (JIS B 1256:1978) 2.5 10H A2J (Trivalent)
S114
--
( KN610014721AA-16 )
