MicroCoat MC800 Lubrication Systems
9www.nordsonefd.com info@nordsonefd.com +1-401-431-7000 Sales and service of Nordson EFD dispensing systems are available worldwide.
Nordson EFD Product Safety Statement (continued)
Important Disposable Component Safety Information
All Nordson EFD disposable components, including syringe barrels, cartridges, pistons, tip caps, end caps,
and dispense tips, are precision engineered for one-time use. Attempting to clean and re-use components will
compromise dispensing accuracy and may increase the risk of personal injury.
Always wear appropriate protective equipment and clothing suitable for your dispensing application and adhere to
the following guidelines:
• Do not heat syringe barrels or cartridges to a temperature greater than 38° C (100° F).
• Dispose of components according to local regulations after one-time use.
• Do not clean components with strong solvents (MEK, acetone, THF, etc.).
• Clean cartridge retainer systems and barrel loaders with mild detergents only.
• To prevent fluid waste, use Nordson EFD SmoothFlow
™
pistons.
Action in the Event of a Malfunction
If a system or any equipment in a system malfunctions, shut off the system immediately and perform the following
steps:
1. Disconnect and lock out system electrical power. If using hydraulic and pneumatic shutoff valves, close and
relieve pressure.
2. For Nordson EFD air-powered dispensers, remove the syringe barrel from the adapter assembly. For Nordson
EFD electro-mechanical dispensers, slowly unscrew the barrel retainer and remove the barrel from the actuator.
3. Identify the reason for the malfunction and correct it before restarting the system.
Disposal
Dispose of equipment and materials used in operation and servicing according to local codes.
MicroCoat MC800 Lubrication Systems
10 www.nordsonefd.com info@nordsonefd.com +1-401-431-7000 Sales and service of Nordson EFD dispensing systems are available worldwide.
Specifications
NOTE: Specifications and technical details are subject to change without prior notification.
MC800 Controller
Item Specification
Cabinet size 14.6
W x 19.1D x 27.6H cm (5.75W x 7.50D x 10.88H")
Weight 4.8 kg (10.6 lb)
Cycle rate Up to 60 per minute
Pressure switch rating 20VA, 240V
Input air pressure 4.1 bar (60 psi) minimum
Tank air pressure regulator 2.0bar (30psi) maximum
Nozzle air regulator 2.0bar (30psi) maximum
Approvals CE, UKCA
MC785M & MC785M-WF Valves
Item Specification
Size (with fittings) 66.3
L x 49.3DIA mm (2.61L x 1.94DIA")
Weight 206.4 g (7.3 oz)
Lubricant inlet hole 1/8 NPT
Mounting 6 mm tapped hole
Cycle rate Up to 60 per minute
Lubricant chamber Hard-coated anodized aluminum
Air cap 303 stainless steel
Diaphragm Viton
®
with PTFE coating
Needle and nozzle 303 stainless steel
Nozzle diameter 1.17 mm (0.046")
U.S. Patent No. D-398,705
MicroCoat MC800 Lubrication Systems
11www.nordsonefd.com info@nordsonefd.com +1-401-431-7000 Sales and service of Nordson EFD dispensing systems are available worldwide.
Specifications (continued)
MicroCoat Tank Reservoirs
Item Specification
Operating pressure 2.0bar (30psi) maximum
Safety relief pressure 2.8bar (40psi)
Low level switch rating 20VA, 240V
Capacity MC685M (P/N 7023843): 3.8 L (1.0 gal)
MC686M (P/N 7023846): 7.5 L (2.0 gal)
Construction Acrylic tank wall, anodized aluminum end caps
Weight MC685M (P/N 7023843): 4.1 kg (9.2 lb)
MC686M (P/N 7023846): 5.2 kg (11.6 lb)
4000FLT MC Filter Elements
Item Specification
Internal filter element Resin impregnated cellulose media
Micron filter size 10 micron nominal
