Find us at www.keysight.com Page 17
Zero Set
This specification applies to a ZERO performed when the sensor input is not connected to the POWER
REF.
Table 8. Zero set.
Sensor model Zero set (normal mode) Zero set (average only mode)
E9321A, E9325A
5 nW
0.17 nW
E9322A, E9326A
19 nW
0.5 nW
E9323A, E9327A
60 nW
0.6 nW
Zero Drift and Measurement Noise
Table 9. Zero drift and measurement noise.
Zero drift
1
Measurement noise
2
Sensor model Normal mode Average only mode Normal mode
3
Normal mode
4
Average only mode
E9321A, E9325A
< 5 nW
< 60 pW
< 6 nW
< 75 nW
< 165 pW
E9322A, E9326A
< 5 nW
< 100 pW
< 12 nW
< 180 nW
< 330 pW
E9323A, E9327A
< 40 nW
< 100 pW
< 25 nW
< 550 nW
< 400 pW
Effect of averaging on noise: Averaging over 1 to 1024 readings is available for reducing noise. Table 9
provides the measurement noise for a particular sensor. Use the noise multipliers in Table 10, for the
appropriate speed (normal or x 2) or measurement mode (normal or average only) and the number of
averages, to determine the total measurement noise value.
In addition, for x 2 speed (in normal mode) the total measurement noise should be multiplied by 1.2, and
for fast speed (in normal mode), the multiplier is 3.4.
Note that in fast speed, no additional averaging is implemented.
1 Within 1 hour after zero set, at a constant temperature, after a 24-hour warm-up of the power meter.
2 Measured over a one-minute interval, at a constant temperature, two standard deviations, with averaging set to 1
(for normal mode), 16 (for average only mode, normal speed) and 32 (for average only mode, x 2 speed).
3 In free run acquisition mode.
4 Noise per sample, video bandwidth set to OFF with no averaging (i.e. averaging set to 1) - see the note “Effect of
Video Bandwidth Setting” and Table 11.
Find us at www.keysight.com Page 18
Table 10. Noise multipliers.
Mode Number of averages 1 2 4 8 16 32 64 128 256 512 1024
Average-
only
Noise multiplier
(normal speed)
5.5 3.89 2.75 1.94 1.0 0.85 0.61 0.49 0.34 0.24 0.17
Noise multiplier
(x 2 speed)
6.5 4.6 3.25 2.3 1.63 1.0 0.72 0.57 0.41 0.29 0.2
Normal Noise multiplier
(normal speed; free
run acquisition)
1.0 0.94 0.88 0.82 0.76 0.70 0.64 0.58 0.52 0.46 0.40
Example
E9321A power sensor, number of averages = 4, free run acquisition, normal mode, x 2 speed.
Measurement noise calculation: (< 6 nW x 0.88 x 1.2) = < 6.34 nW
Effect of video bandwidth setting
The noise per sample is reduced by applying the meter video bandwidth reduction filter setting (High,
Medium or Low). If averaging is implemented, this will dominate any effect of changing the video
bandwidth.
Table 11. Effect of video bandwidth on noise per sample.
Sensor Noise multipliers
Low Medium High
E9321A, E9325A
0.32
0.50
0.63
E9322A, E9326A
0.50
0.63
0.80
E9323A, E9327A
0.40
0.63
1.0
Example
E9322A power sensor, triggered acquisition, video bandwidth = High. Noise per sample calculation:
(< 180 nW x 0.80) = < 144 nW
Effect of time-gating on measurement noise
The measurement noise will depend on the time gate length, over which measurements are made.
Effectively 20 averages are carried out every 1 us of gate length.
Find us at www.keysight.com Page 19
Settling Times
Average-only mode
In normal and x 2 speed, manual filter, 10 dB decreasing power step refer to Table 12.
Table 12. Settling time (average only mode).
Number of average 1 2 4 8 16 32 64 128 256 512 1024
Settling time(s) normal 0.08 0.13 0.24 0.45 1.1 1.9 3.5 6.7 14 27 57
Settling time(s) x 2 0.07 0.09 0.15 0.24 0.45 1.1 1.9 3.5 6.7 14 27
In fast speed, within the range –50 to +20 dBm, for a 10 dB decreasing power step, the settling time is
10 ms (for the E4416A) and 20 ms (for the E4417A).
When a power step crosses the power sensor’s auto-range switch point, add 25 ms.
Normal mode
In normal, free run acquisition mode, within the range –20 to +20 dBm, for a 10 dB decreasing power
step, the settling time is dominated by the measurement update rate and is listed in Table 13 for various
filter settings.
Table 13. Settling time (normal mode).
Number of averages 1 2 4 8 16 32 64 128 256 512 1024
Settling time free run
acquisition, normal speed (s)
0.1 0.15 0.25 0.45 0.9 1.7 3.3 6.5 13.0 25.8 51.5
Settling time free run
acquisition, X2 speed (s)
0.08 0.1 0.15 0.25 0.45 0.9 1.7 3.3 6.5 13.0 25.8
In normal mode, measuring in continuous or single acquisition mode, the performance of rise times, fall
times and 99% settled results are shown in Table 14. Rise time and fall time specifications are for a
0.0 dBm pulse, with the rise time and fall time measured between 10% to 90% points and upper range
selected.
