Find us at www.keysight.com Page 7
Storage conditions
Storage temperature
–20 to +70 °C
Non-operating maximum humidity
90% at 65 °C (non-condensing)
Non-operating maximum altitude
15,420 meters (50,000 feet)
Regulatory Information
Electromagnetic compatibility
This product conforms with the protection requirements of European Council Directive 89/336/ EEC for
Electromagnetic Compatibility (EMC). The conformity assessment requirements have been met using
the technical Construction file route to compliance, using EMC test specifications EN 55011:1991
(Group 1, Class A) and EN 50082-1:1992. In order to preserve the EMC performance of the product,
any cable which becomes worn or damaged must be replaced with the same type and specification.
Product safety
This product conforms to the requirements of European Council Directive 73/23/EEC, and meets the
following safety standards:
•
IEC/ EN 61010-1
•
IEC 825-1 (1993) / EN 60825-1 (1994) Canada / CSA C22.2 No. 1010.1-93
Physical Specifications
Dimensions The following dimensions exclude front and rear panel protrusions:
212.6 mm W x 88.5 mm H x 348.3 mm D (8.5 in x 3.5 in x 13.7 in)
Weight
– Net
E4416A
4.0 kg (8.8 lbs) approximate
E4417A
4.1 kg (9.0 lbs) approximate
– Shipping
E4416A
7.9 kg (17.4 lbs) approximate
E4417A
8.0 kg (17.6 lbs) approximate
Ordering Information
Standard-shipped accessories
Power sensor cable
E9288A 1.5 meter (5 ft). One per E4416A, two per E4417A
Power cord One 2.4 meter (7.5 ft) cable. Power plug matches destination requirements.
Manuals
Product CD-ROM (contains English and localized User’s Guide and Programming Guide)
Find us at www.keysight.com Page 8
Power Meter Options
Connectors
E441xA-002 Parallel rear panel sensor input connector(s) and front panel reference calibrator
connector
E441xA-003 Parallel rear panel sensor input connector(s) and rear panel reference calibrator
connector
Calibration documentation
E441xA-A6J NSI/ NCSL Z540-1-1994 compliant calibration test data including measurement
uncertainties
E441xA-1A7 ISO/ IEC 17025:2005 compliant calibration test data including measurement
uncertainties
Power sensor cables
E441xA-004
E441xA-004
For operation with the E9320 power sensors
E9288A
E9288A
E9288B
E9288B
E9288C
E9288C
Note: The E9288A, B, and C sensor cables will also operate with 8480, N8480 and E-series power sensors.
Find us at www.keysight.com Page 9
For operation with 8480, N8480, E-series CW and E9300 power sensors
11730A
Power sensor and SNS noise source cable, length 5 ft (1.5 m)
11730B
Power sensor and SNS noise source cable, length 10 ft (3 m)
11730C
Power sensor and SNS noise source cable, length 20 ft (6.1 m)
11730D
Power sensor cable, length 50 ft (15.2 m)
11730E
Power sensor cable, length 100 ft (30.5 m)
11730F
Power sensor cable, length 200 ft (61.0 m)
Other sensor cable lengths can be supplied on request
Accessories
E441xA-908
Rack mount kit (one instrument)
E441xA-909
Rack mount kit (two instruments)
34131A
Transit case for half-rack 2U high instruments
34141A
Yellow soft carry/operating case
34161A
Accessory pouch
Service Options
Calibration
1
R-50C-011-3
R-50C-011-3 Keysight Calibration Upfront Plan 3-year coverage
R-50C-011-5
R-50C-011-5 Keysight Calibration Upfront Plan 5-year coverage
E-Series E9320 Power Sensor Specifications
The E9320 peak and average power sensors are designed for use with the EPM-P series power
meters. The E9320 sensors have two measurement modes:
Normal mode
Default mode for E9320 sensors for peak, average and time-related measurements
Average only mode
Designed primarily for average power measurements on low-level signals. This mode is
the only mode used with 8480 and N8480 series sensors, E-series CW sensors and E-
series E9300 sensors.
The following specifications are valid after zero and calibration of the power meter.
Note: E9320 power sensors MUST be used with an E9288A, B or C cable.
1 Options not available in all countries.
