Sampling Characteristics
Sampling rate
20 Msamples/second
Sampling technique
Continuous sampling
Rear Panel Inputs/Outputs
Recorder output(s) Analog 0 to 1 V, 1 kW output impedance, BNC connector. Two outputs are
available on E4417A (channels A and B).
Remote input/output
– TTL output
Used to signal when measurement has exceeded a defined limit
– TTL input
Initiates zero and calibration cycle
Connector type
RJ-45 series shielded modular jack assembly
– TTL output High = 4.8 V max;
Low = 0.2 V max.
– TTL input High = 3.5 V min, 5 V max;
Low = 1 V max, –0.3 V min
RS-232/422 interface Serial interface for communication with an external controller. Male plug 9-pin
D-subminiature connector.
Trigger in
Accepts a TTL signal for initiating measurements, BNC connector
Trigger out
Outputs a TTL signal for synchronizing with external equipment, BNC connector
Ground
Binding post accepts 4 mm plug or bare wire connection
Line power
Input voltage range
85 to 264 Vac, automatic selection
Input frequency range
47 to 440 Hz
Power requirement
Approximately 50 VA (14 Watts)
Remote Programming
Interface GPIB interface operates to IEEE 488.2 and IEC-625. RS-232 and RS-422 serial
interfaces supplied as standard
Command language
SCPI standard interface commands
GPIB compatibility
SH1, AH1, T6, TE0, L4, LE0, SR1, RL1, PP1, DC1, DT1, C0.
Environmental Specifications
Operating environment
Temperature
0 to 55 °C
Maximum humidity
95% at 40 °C, (non-condensing)
Maximum altitude
3,000 meters (9,840 feet)
Find us at www.keysight.com Page 7
Storage conditions
Storage temperature
–20 to +70 °C
Non-operating maximum humidity
90% at 65 °C (non-condensing)
Non-operating maximum altitude
15,420 meters (50,000 feet)
Regulatory Information
Electromagnetic compatibility
This product conforms with the protection requirements of European Council Directive 89/336/ EEC for
Electromagnetic Compatibility (EMC). The conformity assessment requirements have been met using
the technical Construction file route to compliance, using EMC test specifications EN 55011:1991
(Group 1, Class A) and EN 50082-1:1992. In order to preserve the EMC performance of the product,
any cable which becomes worn or damaged must be replaced with the same type and specification.
Product safety
This product conforms to the requirements of European Council Directive 73/23/EEC, and meets the
following safety standards:
•
IEC/ EN 61010-1
•
IEC 825-1 (1993) / EN 60825-1 (1994) Canada / CSA C22.2 No. 1010.1-93
Physical Specifications
Dimensions The following dimensions exclude front and rear panel protrusions:
212.6 mm W x 88.5 mm H x 348.3 mm D (8.5 in x 3.5 in x 13.7 in)
Weight
– Net
E4416A
4.0 kg (8.8 lbs) approximate
E4417A
4.1 kg (9.0 lbs) approximate
– Shipping
E4416A
7.9 kg (17.4 lbs) approximate
E4417A
8.0 kg (17.6 lbs) approximate
Ordering Information
Standard-shipped accessories
Power sensor cable
E9288A 1.5 meter (5 ft). One per E4416A, two per E4417A
Power cord One 2.4 meter (7.5 ft) cable. Power plug matches destination requirements.
Manuals
Product CD-ROM (contains English and localized User’s Guide and Programming Guide)
Find us at www.keysight.com Page 8
Power Meter Options
Connectors
E441xA-002 Parallel rear panel sensor input connector(s) and front panel reference calibrator
connector
E441xA-003 Parallel rear panel sensor input connector(s) and rear panel reference calibrator
connector
Calibration documentation
E441xA-A6J NSI/ NCSL Z540-1-1994 compliant calibration test data including measurement
uncertainties
E441xA-1A7 ISO/ IEC 17025:2005 compliant calibration test data including measurement
uncertainties
Power sensor cables
E441xA-004
E441xA-004
For operation with the E9320 power sensors
E9288A
E9288A
E9288B
E9288B
E9288C
E9288C
Note: The E9288A, B, and C sensor cables will also operate with 8480, N8480 and E-series power sensors.
