Power Meter Options
Connectors
E441xA-002 Parallel rear panel sensor input connector(s) and front panel reference calibrator
connector
E441xA-003 Parallel rear panel sensor input connector(s) and rear panel reference calibrator
connector
Calibration documentation
E441xA-A6J NSI/ NCSL Z540-1-1994 compliant calibration test data including measurement
uncertainties
E441xA-1A7 ISO/ IEC 17025:2005 compliant calibration test data including measurement
uncertainties
Power sensor cables
E441xA-004
E441xA-004
For operation with the E9320 power sensors
E9288A
E9288A
E9288B
E9288B
E9288C
E9288C
Note: The E9288A, B, and C sensor cables will also operate with 8480, N8480 and E-series power sensors.
Find us at www.keysight.com Page 9
For operation with 8480, N8480, E-series CW and E9300 power sensors
11730A
Power sensor and SNS noise source cable, length 5 ft (1.5 m)
11730B
Power sensor and SNS noise source cable, length 10 ft (3 m)
11730C
Power sensor and SNS noise source cable, length 20 ft (6.1 m)
11730D
Power sensor cable, length 50 ft (15.2 m)
11730E
Power sensor cable, length 100 ft (30.5 m)
11730F
Power sensor cable, length 200 ft (61.0 m)
Other sensor cable lengths can be supplied on request
Accessories
E441xA-908
Rack mount kit (one instrument)
E441xA-909
Rack mount kit (two instruments)
34131A
Transit case for half-rack 2U high instruments
34141A
Yellow soft carry/operating case
34161A
Accessory pouch
Service Options
Calibration
1
R-50C-011-3
R-50C-011-3 Keysight Calibration Upfront Plan 3-year coverage
R-50C-011-5
R-50C-011-5 Keysight Calibration Upfront Plan 5-year coverage
E-Series E9320 Power Sensor Specifications
The E9320 peak and average power sensors are designed for use with the EPM-P series power
meters. The E9320 sensors have two measurement modes:
Normal mode
Default mode for E9320 sensors for peak, average and time-related measurements
Average only mode
Designed primarily for average power measurements on low-level signals. This mode is
the only mode used with 8480 and N8480 series sensors, E-series CW sensors and E-
series E9300 sensors.
The following specifications are valid after zero and calibration of the power meter.
Note: E9320 power sensors MUST be used with an E9288A, B or C cable.
1 Options not available in all countries.
Find us at www.keysight.com Page 10
Table 3. Sensor specification.
Sensor
model
Video
bandwidth
Frequency range Power range Maximum power Connector type
Average only mode Normal mode
1
E9321A
E9325A
300 kHz 50 MHz to 6 GHz
50 MHz to 18 GHz
–65 dBm to
+20 dBm
–50 dBm to
+20 dBm
+23 dBm average;
+30 dBm peak
(< 10 µsec duration)
Type N (m)
E9322A
E9326A
1.5 MHz 50 MHz to 6 GHz
50 MHz to 18 GHz
–60 dBm to
+20 dBm
–45 dBm to
+20 dBm
E9323A
E9327A
5 MHz 50 MHz to 6 GHz
50 MHz to 18 GHz
–60 dBm to
+20 dBm
–40 dBm to
+20 dBm
The E9320 power sensors have two measurement ranges (lower and upper) as detailed in Table 4.
Table 4. Lower and upper measurement ranges.
E9321A/E9325A E9322A/E9326A E9323A/E9327A
Normal Average only Normal Average only Normal Average only
Lower range
(min. power)
–50 dBm –65 dBm –45 dBm –60 dBm –40 dBm –60 dBm
Lower range
(max. power)
+0.5 dBm –17.5 dBm
1
–5 dBm –13.5 dBm
2
–5 dBm –10.5 dBm
2
Lower to upper
auto range point
Upper to lower
auto range point
–9.5 dBm –18.5 dBm –15 dBm –14.5 dBm –15 dBm –11.5 dBm
Upper range
(min. power)
–35 dBm –50 dBm –35 dBm –45 dBm –30 dBm –35 dBm
Upper range
(max. power)
+20 dBm +20 dBm
1
+20 dBm +20 dBm
2
+20 dBm +20 dBm
2
1 For average power measurements, free run acquisition.
2 Applies to CW and constant amplitude signals only above –20 dBm.
