Find us at www.keysight.com Page 5
Table 2. Measurement speed for different sensor types.
Channel functions
A, B, A/B, B/A, A-B, B-A and Relative
Storage registers
10 instrument states can be saved via the Save/Recall menu
Predefined setups For common wireless standards (GSM900, EDGE, NADC, iDEN, Bluetooth
®
, IS-95
CDMA, W-CDMA and cdma2000
®
), predefined setups are provided
Trigger
Sources
Internal, External TTL, GPIB, RS232/422
Time resolution
50 ns
Delay range
± 1.0 s
Delay resolution
50 ns for delays < ± 50 ms; otherwise 200 ns
Hold-off
– Range
– Resolution
1 µs to 400 ms
1% of selected value (minimum of 100 ns)
Internal Trigger
Range
–20 to +20 dBm
Level accuracy
± 0.5 dB
Resolution
0.1 dB
Latency
500 ns ± 100 ns
Latency is defined as the delay between the applied RF crossing the trigger level and the meter
switching into the triggered state.
External trigger range High > 2.0 V, Low < 0.8 V; BNC connector; rising or falling edge triggered; input
impedance > 1 kW
Trigger out Output provides TTL compatible levels (high > 2.4 V, low < 0.4 V) and uses a BNC
connector
1 Fast speed is not available for 8480 and N8480 series sensors.
2 Maximum measurement speed is obtained by using binary output in free run trigger.
3 For E9320 sensors, maximum speed is achieved using binary output in free run acquisition.
Sensor type Measurement speed (readings/second)
Normal x 2
Fast
1, 2
E-Series E9320 peak and average sensors
Average only mode
20
40
400
Normal mode
3
20
40
1000
E-Series CW and E9300 average power sensors
20
40
400
8480 and N8480 Series sensor
20
40
NA

Find us at www.keysight.com Page 6
Sampling Characteristics
Sampling rate
20 Msamples/second
Sampling technique
Continuous sampling
Rear Panel Inputs/Outputs
Recorder output(s) Analog 0 to 1 V, 1 kW output impedance, BNC connector. Two outputs are
available on E4417A (channels A and B).
Remote input/output
– TTL output
Used to signal when measurement has exceeded a defined limit
– TTL input
Initiates zero and calibration cycle
Connector type
RJ-45 series shielded modular jack assembly
– TTL output High = 4.8 V max;
Low = 0.2 V max.
– TTL input High = 3.5 V min, 5 V max;
Low = 1 V max, –0.3 V min
RS-232/422 interface Serial interface for communication with an external controller. Male plug 9-pin
D-subminiature connector.
Trigger in
Accepts a TTL signal for initiating measurements, BNC connector
Trigger out
Outputs a TTL signal for synchronizing with external equipment, BNC connector
Ground
Binding post accepts 4 mm plug or bare wire connection
Line power
Input voltage range
85 to 264 Vac, automatic selection
Input frequency range
47 to 440 Hz
Power requirement
Approximately 50 VA (14 Watts)
Remote Programming
Interface GPIB interface operates to IEEE 488.2 and IEC-625. RS-232 and RS-422 serial
interfaces supplied as standard
Command language
SCPI standard interface commands
GPIB compatibility
SH1, AH1, T6, TE0, L4, LE0, SR1, RL1, PP1, DC1, DT1, C0.
Environmental Specifications
Operating environment
Temperature
0 to 55 °C
Maximum humidity
95% at 40 °C, (non-condensing)
Maximum altitude
3,000 meters (9,840 feet)

Find us at www.keysight.com Page 7
Storage conditions
Storage temperature
–20 to +70 °C
Non-operating maximum humidity
90% at 65 °C (non-condensing)
Non-operating maximum altitude
15,420 meters (50,000 feet)
Regulatory Information
Electromagnetic compatibility
This product conforms with the protection requirements of European Council Directive 89/336/ EEC for
Electromagnetic Compatibility (EMC). The conformity assessment requirements have been met using
the technical Construction file route to compliance, using EMC test specifications EN 55011:1991
(Group 1, Class A) and EN 50082-1:1992. In order to preserve the EMC performance of the product,
any cable which becomes worn or damaged must be replaced with the same type and specification.
Product safety
This product conforms to the requirements of European Council Directive 73/23/EEC, and meets the
following safety standards:
•
IEC/ EN 61010-1
•
IEC 825-1 (1993) / EN 60825-1 (1994) Canada / CSA C22.2 No. 1010.1-93
Physical Specifications
Dimensions The following dimensions exclude front and rear panel protrusions:
212.6 mm W x 88.5 mm H x 348.3 mm D (8.5 in x 3.5 in x 13.7 in)
Weight
– Net
E4416A
4.0 kg (8.8 lbs) approximate
E4417A
4.1 kg (9.0 lbs) approximate
– Shipping
E4416A
7.9 kg (17.4 lbs) approximate
E4417A
8.0 kg (17.6 lbs) approximate
Ordering Information
Standard-shipped accessories
Power sensor cable
E9288A 1.5 meter (5 ft). One per E4416A, two per E4417A
Power cord One 2.4 meter (7.5 ft) cable. Power plug matches destination requirements.
Manuals
Product CD-ROM (contains English and localized User’s Guide and Programming Guide)
