Station Software 712.0 (R18-2) / Version Description 11/2018 Edition
28
Modules from 3
rd
party suppliers
– FFI feeders:
HanSan LED feeder
Top Engineering LED feeder
Data IO RoadRunners
– IPTE Multi Stick Feeder:
IPTE Multistick 60 AX
IPTE Multistick XL80 AX
– SEMO CRF80 tape feeder
Restrictions:
– For larger feeders, the camera is positioned very close to the edge of the travel range.
Therefore, only a part of the component might be visible during pickup position teaching.
5.2 Camera Systems and Component Ranges
Detailed information on the used camera systems and component ranges for the placement heads
can be found in the respective machine specifications and/or User Manuals of the placement
machines.
Station Software 712.0 (R18-2) / Version Description 11/2018 Edition
29
6 ASM Software Environment
6.1 SIPLACE Pro Programming System Version 16.0
The SIPLACE Pro programming system version 16.0 supports the SIPLACE X-series, X-series S,
SX-series, DX-series, CA-series and TX-series placement machines with the 711.1 station
software version.
Compatible mode: SIPLACE Pro 15.x
NOTICE
For a detailed description of the programming system, see the SIPLACE Pro version
description and the online help system.
6.2 ASM OIS Version 16.0
Software version 16.0 of the ASM OIS monitoring system supports the SIPLACE X-series,
X-series S, SX-series, DX-series, CA-series and TX-series placement machines.
NOTICE
A detailed description can be found in the software description "Getting started with OIS"
and the online help system for OIS.
6.3 ASM Setup Center Version 10.0
Software version 10.0 of the ASM Setup Center supports the SIPLACE X-series, X-series S,
SX-series, DX-series, CA-series and TX-series placement machines.
Compatible mode: ASM Setup Center 9.x
NOTICE
A detailed description can be found in the software description "Getting started with
Setup Center" and the online help system for Setup Center.
Station Software 712.0 (R18-2) / Version Description 11/2018 Edition
30
6.4 ASM Traceability Version 5.5
Software version 5.5 of ASM Traceability supports the SIPLACE X-series, X-series S,
SX-series, DX-series, CA-series and TX-series placement machines.
Compatible mode: SIPLACE Traceability 4.x
NOTICE
A detailed description can be found in the "Traceability User Guide".
