Station Software 712.0 (R18-2) / Version Description 11/2018 Edition

D1-153552201 There was a problem when synchronizing SMEMA and whispering data

between adjacent machines.

D1-153630802 Error message 30450 Unspecified hardware error was displayed for

each camera but there was no problem at the machine.

D1-153875301 eSW: there was a problem with the transition between the SIPLACE and

AYSY conveyors.

D1-153989601 Changing the conveyor width led to error message Unexpected software

malfunction - the application has to be closed

D1-154055101 The firmware update for the C&P20 pressure regulator could not be done.

D1-154075385 After having downloaded the conveyor BIOS, the subsystem could not be

activated.

D1-154379501 The service symbol was not active after the machine started.

D1-154598802 In stand-alone mode, old jobs could not be deleted any longer.

D1-154781809 Threshold = 0 had no effect: the machine stopped although no threshold was

defined within Setup Center.

D1-155170101 The fiducial plate position of the SST47 could not be calibrated.

D1-155177302 The machine reported a yellow board with an unknown placement state, but

this position could not be checked within the manual operations because just a

grey field was displayed.

D1-155243901 The calibration of the offset between SST47 and SST34 failed.

D1-155371401 Sporadically, the station software stopped during placement with error

message

32602 The software has stopped unexpectedly

D18199-16132 Better handling within the station software for the selection of component

shapes that shall be taught.

D18272-5888 eSW: A 440 mm board did not reach the placement area in an X4 S

placement machine with short input conveyor.

D18445-3801 Sporadically, the station software stopped during placement with error

message

32602 The software has stopped unexpectedly

D18459-1601 The machine displayed an X-axis error 30341: Position is out of

range

D18474-3601 Special FFI feeder brought error message 40007 out of components

although feeder was filled up with 1200 components.

D18505-3253 Sometimes component teaching slowed down the computer.

D18541-2515 Chuck fiducials CA4: If the vacuum tooling fiducials were not used for

recalibration, a dual gantry measurement must be done.

D18570-1501 The machine stopped during placement without error message.

D18585-2817 Moving a gantry to service position did not work and the error message

32535

Checking nozzle configuration: CPP Head, gantry1 was

displayed.

Table 8-3: Corrected errors station software version 711.1 SP1

Station Software 712.0 (R18-2) / Version Description 11/2018 Edition

711.1 Patch 2

Error no. Error description

D1-147902801

D1-151728101

eSW: the machine stopped during dry run with cyclic transport with the error

message

unknown placement state

D1-150565001

D1-153597901

D1-150820801

D1-153597901

After an eSW download we always got the information that heads had been

changed.

D1-150590901 Sporadically, the station software stopped during placement with the error

message

30016 Unhandled exception error

D1-153569301 For an alternative component shape, the dimensions of the original shape

were used. Thus, this function could not be used if the alternative shape had

different dimensions.

D1-153862701 Teaching of the component position did not always work.

D1-154709901

D1-154855101

The conveyor fiducials were checked after every board.

D18460-15207 Machine picked up 2 large components with the TH. The components

collided when being rotated.

D18537-2101 When a barcode was whispered to the next machine, a tabulator was

replaced by a space character.

Table 8-4: Corrected errors station software version 711.1 Patch 2

711.1 Patch 1

Error no. Error description

D1-127453301 E by SIPLACE, eSW: the feeders were in an undefined state after a restart of

the machine.

D1-151650901 The height for the CPP head within a TX2 V2 machine was wrong when the

CPP head was mounted in a low position.

D1-152039901 The WPC was not displayed correctly in the main view of the GUI.

D18581-2801 The machine stopped after 80 vision errors, although the repick count was set

to 100.

Table 8-5: Corrected errors station software version 711.1 Patch 1

Station Software 712.0 (R18-2) / Version Description 11/2018 Edition

9 Important Terms and Abbreviations

CA4

CA4 V2

Machine type of the Chip Assembly (CA)-series with 4 gantries

and 2 PAs

C&P Collect & Place

CPP Collect & Place & Pick & Place

DC Dual Conveyor

DX1/DX2 Machine type with 1 or 2 gantries and 1 PA

EDIF Electronic Design Interchange Format

eWLP embedded Wafer Level Process

FOPLP Fan-Out Panel Level Packaging

FCCS Field Camera Calibration System

GUI Graphical User Interface

HFH High Force Head

HW Hardware

MGCU Modular Gantry Control Unit

MHCU Modular Head Control Unit

MTC Matrix Tray Changer

OIS Operator Information System

PA Processing area

PCB Printed circuit board

Placement mode:

2-in-1

When a machine runs in I-Placement mode, it is possible to

perform manual operations for one side / gantry. This placement

mode is also called "independent".

Placement mode:

Alternating

Placement mode in a dual gantry placement area, in which both

gantries place components on both boards in a dual conveyor.

First, both gantries place all assigned components on the board

in lane one and then on the board in lane two.

Placement mode:

Borrow

Performance

A line runs in I-Placement mode and to get a balanced

throughput between the left and right conveyor lanes, e.g. the

last machine runs in Alternating mode and places components in

this placement area on the board of the other lane.

Placement mode:

I-Placement

Placement mode in a dual gantry placement area in which each

gantry only places components on the board of the assigned

conveyor lane.

SC Single Conveyor

SC SIPLACE Setup Center (external setup control system)

SW Software

SWS SIPLACE Wafer System

SX1/SX2 Machine type with 1 or 2 gantries and 1 PA

TH Twin Head

TH HF Twin Head High Force
