Station Software 712.0 (R18-2) / Version Description 11/2018 Edition

8 Corrected Errors

712.0 Station Software

The 712.0 station software version contains all error corrections of the previous 7xx versions.

Additionally, the following errors have been corrected in this version:

Error no. Error description

D1-142591801 An incorrect conveyor width was set after reboot.

D1-145486748 Various conveyor errors.

D1-146654832 During the height reference run, a nozzle was expected that was missing. The

nozzle could not be provided at the current activity level.

D1-148088101 The CPP placement head removed a component that was already placed by

the Twin VHF placement head.

D1-148126901 Width adjustment was performed during running production on a SIPLACE

TX2i placement machine.

D1-149428701 Night run with cyclic board transport stopped: disturbed CAN communication,

channel 1. Error message Placement status is unknown: Gantry 1,

Segment 1

was displayed.

D1-152642401 The Tray view automatically jumped to level 1 after the WPTC was confirmed.

D1-152854501 The conveyor did not function during machine endurance run.

D1-153279801 The stations within one line displayed different states (productive/blocked).

D1-153508601 Errors could not be selected in the error statistics view.

D1-154092217 Undefined hardware error after downloading Application 1; 5 DP axes without

Application 1.

D1-154781809 Stop threshold = 0 was ignored.

D1-155009601 At error 33263 Connection between GigE interface card in the

PC and the camera interrupted (252), the GUI did not display which

camera or gantry was affected.

D1-155170101 Glass plate with fiducials could not be calibrated with the SST47 board

camera.

D1-155523201 X4 S placement machine: FCCS digital – in PA1, the stop position of the tray

had a 5 cm back shift. The fiducials could not be recognized.

D1-155597201 Location 2 could not be approached by position correction.

D1-155619501 Stopping the production took too long.

D1-156262534 The software hung up and the module had to be restarted.

D1-156809701 The machine stopped during the 2h run (first board) after about 4 minutes

without any error message.

Station Software 712.0 (R18-2) / Version Description 11/2018 Edition

D1-157648601 After the table was removed and inserted, the feeder speed of the Xi Feeder

changed automatically.

D1-158062753 Extended Vision dump file was not stored.

D1-158064501 After starting the FCCS, the gantry never moved to the FCCS plate to start the

calibration.

D1-158433701 The Leveling assistant could not be performed.

D1-158465849 Leveling assistant error.

D1-159122707 The ACT measurements were not successful, because the distance check

failed.

D18495-4001 The XML file generated by Traceability had the wrong start time.

Table 8-1: Corrected errors station software version 712.0

711.1 SP2

Error no. Error description

D1-155313201 When a new job was downloaded all the feeder signals were off.

D1-157668741 eSW: Error message 30470 Either collision of two gantries or

axis hit bumper at end of driving range

D1-157715301 When trying to inspect a placement position, no image was displayed.

D1-157719277 A splice was not detected.

D1-157830601

D1-157926708

eSW: Error when checking the motor current for width adjustment.

D1-157851214

D1-158056019

eSW: Sporadically, the error messages 30399 Table 1: Unexpected

reboot from subsystem detected or 34921 Feeder: Input

voltage too low

were displayed.

D17819-36801

D18551-2301

D18495-4701

D18526-6601

D1-58354825

After some days of production, teaching components or opening dump files

got very slow.

D18093-37005 The whispered data did not fit to the board.

Table 8-2: Corrected errors station software version 711.1 SP2

Station Software 712.0 (R18-2) / Version Description 11/2018 Edition

711.1 SP1

Error no. Error description

D1-140512109 Automatic program download via barcode: machine needed to be emptied

when using smart pins although the pins were in the same position in both

programs.

D1-144918301 The binder of the linear feeder did not open at the first pickup event.

D1-145486749 eSW: conveyor error messages 30007 Cannot open file and 35336 An

unknown conveyor control unit has been detected after machine

start.

D1-149326501 During production, there was a message that the "Application has to be

closed.

D1-150606549 In case of contactless pickup, the z height was not re-taught, and the feeder

pocket was not measured again after a foil torn.

D1-150924808 Improvement of the manual Pin 1 check to be able to recognize low-contrast

structures.

D1-151189122 eSW: Vacuum for vacuum tooling was not turned on automatically during

recovery placement mode.

D1-151304001

D1-151342257

D1-152045605

After having continued the mapping after a Vision error the mapping

component was lost, and the mapping could not be finished.

D1-151804201 In the Feeder Parameter view, the information "spacer is needed" was

displayed for components with contactless pick-up although current feeders

did no longer need a spacer.

D1-152045605 It was not possible to teach a pickup offset of more than 1 mm for a WPC tray.

D1-152513701 Picking up from 2 special feeders with undefined busy time led to performance

loss as the feeders did not answer quick enough.

D1-152745201

D1-153297807

D1-153360401

D1-154070049

Sporadic problems during the benchmark placement (SX2 with TH).

D1-152748201 Virtual PCB stack: a multi panel board could not be placed.

D1-152854543 After having moved to the nozzle changer position on location 2 in the teach

menu, the software stopped, and the machine had to be switched off.

D1-153217601 37800 [Twin Head, gantry 1] Machine stopped due to too many

repetitive errors.

D1-153325901 PPW 1_L could not be calibrated.

D1-153333101 TX2 V2 with CPP/C&P20 P2 (nozzle changer for CPP is 3.65 mm lower):

there was a warning during calibration of the nozzle changer that the 3 mm

border was exceeded.

D1-153360489 The virtual keyboard was in the background of the input window of the bug

reporter.

D1-153368126 Error message 32507 Product change: Finishing previous

product prior to setup change and no more boards got into the

machine.

D1-153466646 When adjusting the pickup offset, the gantry was moving 300 mm towards the

conveyor instead of going to the pickup position of the WPC.
