DEK高级培训资料.pdf - 第165页
Reference prin t height • Set in diagnostics • Saved to configuration file (config.cfg) • Rising table position to Print Height Issue 2: July 2007 Reference prin t height Home position • Rising table position to place bo…
Vision Height
• Set in diagnostics
• Saved to configuration
file (config.cfg)
•
Issue 2: July 2007
•
Rising table position to
allow camera to
capture board
fiducials...
Home position
Vision height
Reference print height
•
Set in diagnostics
•
Saved to configuration
file (config.cfg)
•
Rising table position to
Print Height
Issue 2: July 2007
Reference print height
Home position
•
Rising table position to
place board in contact
with stencil for printing.
Note: Set without board,
then when printing,
board thickness is
taken into account….
•
Carried out in
diagnostics
•
Entered in Set Prefers
•
Saved to configuration
file (config.cfg)
Board Stop X offset
Issue 2: July 2007
file (config.cfg)
•
Carried out when a
camera is replaced
•
Distance measured
from centre of optics to
board stop assembly ...
